- Page 1 E N A R C O , S . A . ELECTRONIC FRECUENCY BATTERY CONVERTER Instruction manual MX-810-2011...
-
Page 3: Table Of Contents
4.7 TRANSPORTATION 4.8 WASTE DISPOSAL 4.9 MAINTENANCE OF THE VIBRATING POKERS 5 LOCATING MALFUNCTIONS 6 INSTRUCTIONS TO ORDER SPARE PARTS 6.1 INSTRUCTIONS TO ORDER SPARE PARTS 6.2 INSTRUCTIONS TO REQUEST WARRANTIES 7 USAGE RECOMMENDATIONS BATTERY POWERED ELECTRONIC CONVERTER BOXEL E-BATT... -
Page 4: Introduction
INTRODUCTION Thank you for trusting the ENAR brand. For the maximum performance of the equipment, we recommend to read carefully the safety recommendations, maintenance, and usage listed in this manual. Defective parts must be replaced immediately to avoid major problems. -
Page 5: Characteristics
- FUNCTION Supply a three phase voltage of 42V at a frequency of 200Hz to the vibrators with internal motor ref. ENAR M38AFP, M5AFP, M6AFP, M7AFP and M8AFP and other vibrators working at this voltage and frequency. - TYPE OF BATTERY Non-detachable 16Ah 68,4V Li-ion type. -
Page 6: Battery Description
¡ATENTION!: The battery is not detachable. 2.3 CHARGER DESCRIPTION The BOXEL E-BATT charger has a connector for the battery and a cable that connects the charger to the mains. It includes a LED indicator to check the status of the charge; red in charge and green when the battery is fully charged. -
Page 7: Usage Conditions
BATTERY STATUS LED BOXEL E-BATT CHARGER CONNECTOR (2) POWER CABLE WITH SCHUKO PLUG (1) WARNING! If the converter is not going to be used, charge the battery once a month. USAGE CONDITIONS WARNING! Read all safety warnings, instructions, illustrations, and specifications supplied with this power tool. -
Page 8: Personal Safety
Use of the power tool for operations different from intended could result in a hazardous situation. BATTERY POWERED ELECTRONIC CONVERTER BOXEL E-BATT... -
Page 9: Service
3.6 ELECTRICAL SAFETY OF THE BATTERY Never handle or remove the battery from the device. Charge the battery only with the charger 104517 supplied by ENAR. Make a full charge of the battery before using it. Do not overcharge the battery. Once the charger LED indicator changes to GREEN, disconnect the charger from the mains and then remove the connector from the converter. -
Page 10: Specific Safety Rules
Charge only the battery of the BOXEL E-BATT by ENAR. Do not overload the charger of the battery. Once the charger LED indicator change their status to green, disconnect the charger from the mains and then remove the connector converter. The battery display should indicate 100%. -
Page 11: Operation And Maintenance
The battery life for the connected pokers will depend on the power of the vibrator motor and the type of work to be carried out. See table of battery life for ENAR pokers. 4.3 CONNECTION OF THE CHARGER TO THE MAINS The charger of the converter must be connected for charging to single phase current form 110 to 230V 1Ph 50-60Hz. -
Page 12: Storage
Proceed to recycle the rest of the electrical and mechanical components according to the current regulations for each type of waste in your country. 4.9 MAINTENANCE OF THE VIBRATING POKERS Check the instruction manual of the high frequency vibrating pokers (AF_x_mu_01) BATTERY POWERED ELECTRONIC CONVERTER BOXEL E-BATT... -
Page 13: Locating Malfunctions
3.- Let us to know the right shipping instructions, including the wished route, the address and the consignee complete name. 4.- Do not return the parts without authorisation, the return is done with freight prepaid. BATTERY POWERED ELECTRONIC CONVERTER BOXEL E-BATT... -
Page 14: Instructions To Request Warranties
10.- Follow the maintenance instructions for the vibrator. 11.- To achieve a good concrete structure we must start from the appropriate components and perform a vibration of the concrete mass throughout the structure. BATTERY POWERED ELECTRONIC CONVERTER BOXEL E-BATT... - Page 15 FOR ANY REQUIREMENT ABOUT THE PART LIST OF OUR MACHINES CONSULT OUR WEB PAGE. POUR CONSULTER TOUS LES RENSEIGNEMENTS DES PIÈCES DETACHEES OU LA LISTE DE NOS MACHINES VOIR NOTRE SITE. UM DIE VERSCHIEDENE EXPLOSIONSZEICHNUNGEN SO WIE DIE ERSATZTEILLISTEN EINZUSEHEN, BESUCHEN SIE BITTE UNSERE INTERNET-SEITE. www.enar.es...
- Page 16 Technical documentation responsible ~ Responsable of the Documentation Technnique ~ zuständigen technishen Dokumentation Zaragoza, 26.10.2020 David Gascón General Manager ENARCO,S.A. ENARCO, S.A. Tfno. (34) 976 464 090 Plataforma Logística PLAZA e-mail: enar@enar.es (34) 976 464 091 C/Burtina, 16 Web: http://www.enar.es (34) 976 471 470 50197 ZARAGOZA (SPAIN)
