INSTRUCTION BULLETIN
NOTE: DO NOT DISCARD the Parts List from the Instruction Bulletin. Place the
Parts List in the appropriate place in the machine manual for future
reference. Retaining the Parts List will make it easier to reorder
individual parts and will save the cost of ordering an entire kit.
NOTE: Numbers in parenthesis ( ) are reference numbers for parts listed in Bill of Materials.
Installation instructions for kit number 377393
SYNOPSIS / PROBLEM:
This kit contains the parts needed to install a battery tray modification kit on 7100/EZ Rider scrubbers.
Please follow step-by-step instructions.
SPECIAL TOOLS / CONSIDERATIONS: NONE
(Estimated time to complete: 1/2 hour)
PREPARATION:
1. Park the machine on a clean level surface.
2. Turn off machine, remove key, and set parking
brake.
FOR SAFETY: Before leaving or servicing
machine, stop on level surface, turn off
machine, and remove key.
INSTALLATION:
Refer to Fig. 1
1. Lower the scrub head.
2. Using a 1/4--18 NPT tap, thread the existing
hole in the left battery tray as shown.
3. Install the brass fitting (1) supplied with kit up
into the threaded hole from the previous step.
Apply a small amount of sealant onto the brass
fitting before threading it into the battery tray.
4. Install the hose (2) onto the brass fitting (1).
5. Secure hose with clamp (3) provided. Use
existing hardware to attach clamp to machine
frame in location shown. This will prevent fluids
draining from the battery tray from spilling onto
electrical components.
IB 340720 (05- -2007)
No. 340720
Machine: 7100/EZ Rider
Published: 05- -2007
Rev. 02
1
