OHAUS Defender 2500 Quick Start Manual

Quick Start Guide
For safe and dependable operation of this product, please comply with the following safety
precautions:
⚫ Before connecting power, verify that the equipment's input voltage range and plug type are compatible
with the local AC mains power supply.
⚫
Do not position the equipment such that it is difficult to reach the power connection.
⚫
Make sure that the power cord does not pose a potential obstacle or tripping hazard.
⚫
Operate the equipment only under ambient conditions specified in these instructions.
⚫
The equipment is for indoor use only.
⚫
Do not operate the equipment in hazardous or unstable environments.
⚫
Do not allow liquids to enter the equipment.
⚫
Use only approved accessories and peripherals.
⚫
Disconnect the equipment from the power supply when cleaning.
⚫
Service should only be performed by authorized personnel.
WARNING: Never work in an environment subject to explosion hazards! The housing of the instrument is
not gas tight. (Explosion hazard due to spark formation, corrosion caused by the ingress of gases).
WARNING: Electrical shock hazards exist within the housing. The housing should only be opened by
authorized and qualified personnel. Remove all power connections to the unit before opening.
INTENDED USE
This instrument is intended for use in pharmacies, schools, businesses and light industry. It must only be used for
measuring the parameters described in these operating instructions. Any other type of use and operation beyond
the limits of technical specifications, without written consent from OHAUS, is considered as not intended. This
instrument complies with current industry standards and the recognized safety regulations; however, it can
constitute a hazard in use. If the instrument is not used according to these operating instructions, the intended
protection provided by the instrument may be impaired.
MENU NAVIGATION
Press and hold Menu until
Use Yes, No, Back, and Exit to navigate:
-
Yes allows entry into the displayed menu. Accepts the displayed setting and advances to the next menu item.
-
No skips by the displayed menu. Rejects the displayed setting or menu item and advances to the next
available item.
-
Back moves backwards through the upper and middle level menus. Backs out of a list of selectable items to
the previous middle level menu.
-
Exit exits from menu directly to the active weighing mode.
MENU SETUP
C.A.L S.E.t.u.P r.E.A.d
ZErO reset reset
SpaN C.Unit Stable
LIN CAP ZErO
GEO Grad FIltEr
C.test P.ZerO AZt
ENd P.UNIt B.LIGHt
A.tare SCreeN
ENd A.Off
P.SaUer
ENd
Ohaus Corporation www.ohaus.com
SAFETY PRECAUTIONS
mM.E.N.U
appears.
mM.O.d.E U.N.I.t
reset reset
wWeIGH g
COUNt kg
PkHd lb
tOtAL oz
tAble lb:oz
dyNamM t
d.typE ENd
d.start
d.tImME
A.tImME
ENd
Defender
r.s.2.3.2 P.r.i.n.t U.S.B
reset reset reset
BAud ASSIGN type
PAritY DEmMAN HID
StOP ON.StAb CDC
H.SHAKE ON.ACEP ALt.P
ALt.P INtEr ALt.t
ALt.t mMt.Con ALt.Z
ALt.Z OH.Con ENd
ENd SICS
Stable
CONtNt
LAYOUt
ENd
i
™
2500
P.r.i.n.t.U L.o.c.k E.n.d
reset reset
ASSIGN L.ALL
DEmMAN L.OFF
ON.StAb L.ZErO
ON.ACEP L.Print
INtEr L.Unit
mMt.Con L.mModE
OH.Con L.mMeNU
SICS L.tArE
Stable ENd
CONtNt
LAYOUt
ENd
™
Defender 2500
