Summary of Contents for OHAUS Dial-O-Gram
- Page 1 Ohaus Corporation Ohaus Corporation Ohaus Corporation Ohaus Corporation Ohaus Corporation 29 Hanover Road Florham Park NJ 07932-0900 Harvard Trip Balance Dial-O-Gram ® Model 2060 Instruction manual...
- Page 2 The Ohaus Dial-O-Gram Balance is a precision weighing instruments, designed ® to provide years of service with virtually no maintenance. Dial-O-Gram Balance employs a two-pan design based on the classic Roberval balance principle. It has the additional advantages of magnetic damping and integral dial for direct weighing.
- Page 3 UNPACKING UNPACKING UNPACKING UNPACKING UNPACKING ® Dial-O-Gram Model 2060 Balances are shipped as follows: • Completely assembled Balance • Instruction manual • Warranty card Your new precision Balance has been packed in a carton specifically designed to protect it during shipment. Follow these instructions and your Balance will be operational in just a few minutes.
- Page 4 Since the capacity of the Balance far exceeds the Dial capacity, the use of additional masses is necessary to take advantage of the full capacity. Ohaus recommends Mass set No. 213-16 (1000g x 1g).
- Page 5 Specific Gravity Determination Specific Gravity Determination A Clamp and Rod Support, Ohaus part number 183-00, is an accessory used to elevate the Balance for suspending a specimen in water. The rod is inserted into the 1/2 inch recess on the underside of the base. By means of a fine wire or thread, the specimen is attached to the check pin which connects the platform loop to the check rod.
- Page 6 SERVICE INFORMATION SERVICE INFORMATION SERVICE INFORMATION SERVICE INFORMATION SERVICE INFORMATION For service assistance in the United States, please call Ohaus Corporation toll- free at (800) 526-0659. An Ohaus Product Service Specialist will be available to help you. SPECIFICATIONS SPECIFICATIONS SPECIFICATIONS SPECIFICATIONS...
- Page 7 During the warranty period Ohaus will repair, or, at its option, replace any component(s) that proves to be defective at no charge, provided that the product is returned, freight prepaid, to Ohaus.
- Page 8 Ohaus Corporation 29 Hanover Road, Florham Park, NJ 07932, USA Tel: (973) 377-9000, Fax: (973) 593-0359 With offices worldwide. P/N 1348 R0500 © Ohaus Corporation 2000 all rights reserved.
