L310/L610
Inspiroy Frego S/M
Thanks for choosing HUION Inspiroy Frego pen tablet (Inspiroy Frego S/M).
Inspiroy Frego is a new Bluetooth pen tablet with a borderless, buttonless, and seamless exterior
design, bringing the best of minimalist aesthetic to life. With HUION Inspiroy Frego pen tablet, you
can enjoy a free and natural drawing experience, and immerse yourself in a world of boundless
creativity.
To ensure that you fully understand and efficiently use this product, we strongly recommend that
you read this user manual carefully.
Note: The pictures in the manual are for reference only and are intended to assist you in understanding the
design and function of the product. A change in design or specification may occur without notice.
www.huion.com
1 / 36

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Inspiroy Frego S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Huion Inspiroy Frego S

Summary of Contents for Huion Inspiroy Frego S

  • Page 1 Inspiroy Frego is a new Bluetooth pen tablet with a borderless, buttonless, and seamless exterior design, bringing the best of minimalist aesthetic to life. With HUION Inspiroy Frego pen tablet, you can enjoy a free and natural drawing experience, and immerse yourself in a world of boundless creativity.
  • Page 2 L310/L610 1. Accessories After unpacking, make sure you receive the following items: Pen Tablet*1 Battery-free Digital Pen*1 Pen Nib*10 Pen Nib Clip*1 USB-C Cable*1 Quick Start Guide*1 www.huion.com 2 / 36...

  • Page 3: Product Overview

    Press twice in a row: Switch the working area mode from full area mode  to 18:9 mode and calibrate the aspect ratio. Use the included USB-C cable to connect the pen tablet to your device. ④ USB-C Port www.huion.com 3 / 36...

  • Page 4: Wired Connection

    L310/L610 3. Connection Take out the Inspiroy Frego S/M from the box and connect it to your computer as follows. You can also refer to the Quick Start Guide included in the box for detailed instructions. 3.1. Wired Connection Use the included USB-C cable to connect the pen tablet to your computer.

  • Page 5: Bluetooth Connection

    L310/L610 3.2. Bluetooth Connection If your computer or Android phone has a built-in Bluetooth, you can connect Inspiroy Frego S/M to it via Bluetooth. Please follow the steps below: Turn on Bluetooth on your computer or Android device. Press the power button of Inspiroy Frego S/M to start it.

  • Page 6: Driver Installation

    In this case please reinstall the driver and your pen display will return to its default settings. Driver Installation Instruction: 1.Connect the pen tablet to your computer. 2.Click Driver-Inspiroy Frego S/M to get the latest driver for your device. 3.Double-click the driver and click “OK” to proceed. www.huion.com...
  • Page 7 4.Check the box to agree with the User Agreement and click “Install Now”. 5.After the installation has been completed, click on “Try it now”. 6.A picture of Inspiroy Frego S/M will appear on the driver interface to indicate a successful connection. Now you can use your tablet.
  • Page 8 In this case please reinstall the driver and your pen display will return to its default settings. Driver Installation Instruction: Connect the pen tablet to your computer. Click Driver-Inspiroy Frego S/M to get the latest driver for your device. Unzip the driver file and drag the “HuionTablet” icon into the “Applications” folder. www.huion.com...
  • Page 9 Go to Security & Privacy > Privacy > Accessibility settings and click the lock icon to unlock the settings. Tick the checkbox on the left of the HuionTablet driver application to enable accessibility. Then click the lock icon to lock the settings. www.huion.com 9 / 36...
  • Page 10 L310/L610 A picture of Inspiroy Frego S/M will appear on the driver interface to indicate a successful connection. Now you can use your tablet. www.huion.com 10 / 36...
  • Page 11 Please remember to close the command window and reboot your Linux device after installing the driver, or the driver will not be useful. After rebooting the device, you can access the system main menu to find the Huion Tablet driver and then open it to finish some settings.
  • Page 12 L310/L610 to make your Linux device execute it. Enter the user password to complete the installation. Please reboot your Linux device to run the driver, or the driver will not be useful. www.huion.com 12 / 36...
  • Page 13 L310/L610 A picture of Inspiroy Frego S/M will appear on the driver interface to indicate a successful connection. Now you can use your tablet. www.huion.com 13 / 36...
  • Page 14 Open the command window in the folder of the driver. Input the following command in the command window: “sudo sh uninstall.sh”, and press the enter key on the keyboard to make your Linux device execute it. www.huion.com 14 / 36...
  • Page 15 Linux operating systems supported:Ubuntu 4.3.2.1. Steps to Install: Open the folder and double-click the driver file in deb format to enter the system default interface of installing the driver on the application store, then click to install. www.huion.com 15 / 36...
  • Page 16 L310/L610 Enter the user password to complete the installation. www.huion.com 16 / 36...
  • Page 17 Tip: Please ensure that your Linux device has been connected to the internet when installing the driver, or the installation will fail when entering the application store interface. A picture of Inspiroy Frego S/M will appear on the driver interface to indicate a successful connection. Now you can use your tablet.
  • Page 18 2.Find the driver and click to uninstall it. Tip: If you can't access the system’s built-in application store, you can search out the driver file, huiontablet_xxx.deb, then double-click it to enter the installation interface, and click the remove button to uninstall it. www.huion.com 18 / 36...
  • Page 19 Pressure Sensitivity Adjustment, and Pressure Test. See Section Store Huion Store is where you can get the latest information about the product such as its FAQ or sales promotion. In addition, you can also purchase Huion’s other products or accessories here. Add Programs 1) Some programs which have already been opened will appear for you to choose from after clicking Add a Program on the screen.

  • Page 20: Working Area Setting

    5.2.1. Working Area Setting Define the active working area of Inspiroy frego S/M that will be mapped to the monitor. Three modes on the driver can be chosen: www.huion.com...
  • Page 21 You can adjust the working area of the pen tablet by changing the outlines of the smaller rectangle (see picture 1). You can also drag the two blue rectangles to select the active areas of the digital pen on the screen and the pen tablet. (see picture 2 and 3). www.huion.com 21 / 36...
  • Page 22 L310/L610 Picture 1 Picture 2 www.huion.com 22 / 36...
  • Page 23 0°, 90°, 180°or 270°. 5.3. Digital Pen Setting 5.3.1. Press Key You can use this digital pen to interact with your device, including drawing, writing, moving files, or activating the functions of pen press keys. www.huion.com 23 / 36...
  • Page 24 For the Linux OS, the key functions can be set as: Lock the Screen, Sleep, and Power Off. You can apply these functions to press keys: Previous Song, Next Song, Multimedia Play/Pause,Volume up, Volume down, and Muted. www.huion.com 24 / 36...
  • Page 25 By clicking “Fix” once the menu will be fixed on the desktop while after a second try the “Fix” button changes to “Close” and the menu disappears (see picture 3). Put the cursor on the menu to drag it. www.huion.com 25 / 36...
  • Page 26 Click the drop-down button to set its activity. In Valid mode, the pen can complete specified actions such as clicking, double-clicking, and dragging when you tap the pen on the screen. In Invalid mode, the pen can control the movement of the cursor, but cannot complete specified actions. www.huion.com 26 / 36...
  • Page 27 Microsoft Windows provides extensive support for pen input. When the “Enable Windows Ink” option is ticked, pen features are supported in software such as Microsoft Office, Windows Whiteboard, Adobe Photoshop CC, SketchBook 6, etc. Note: macOS and Linux OS do not support this feature. www.huion.com 27 / 36...
  • Page 28 Click the “Delete” button above to remove the lines, reset the pressure sensitivity level and test it until you find the appropriate pressure sensitivity level. A steep curve means a more sensitive response.  www.huion.com 28 / 36...

  • Page 29: Driver Setting

    L310/L610 5.4. Driver Setting 5.4.1. Device You can view the information of the firmware, the connected product, sleep time, and Device Diagnosis here. www.huion.com 29 / 36...
  • Page 30 If it is opened with administrator privilege, this item will not be displayed. If it is not opened with administrator privilege, this item will be displayed. www.huion.com 30 / 36...
  • Page 31 Click "Feedback" to send a feedback email if you have any question about the driver; Click "Uninstall" to delete the current driver. If you can't click or draw or there is no pressure sensitivity under the software, click "Software Diagnosis" to find out cause.For specific operation,Please click here. www.huion.com 31 / 36...
  • Page 32 Android, iOS, iPadOS, etc., and the aspect ratio of the pen tablet’s working area automatically matches that of the connected mobile device. Note:When mapping, Inspiroy Frego S supports both horizontal and vertical use, and Inspiroy Frego M supports only horizontal use, as shown below.
  • Page 33 3. Download the HiPaint app, enter the canvas interface and click the “ ” button. 4. Go to the settings menu, select “My Devices” and click “Connect Device”. 5. Select your pen tablet (“Inspiroy Frego S/M-xxx”) from the search results to connect. www.huion.com...
  • Page 34 6. After a successful connection, you can start to use the pen tablet and set the function of the digital pen buttons. Note: When working with other apps, Inspiroy Frego S/M is only compatible with Android OS. System Connection Guide: For Android 6.0-13.0:...
  • Page 35 Follow the steps below to replace the pen nib: Tilt the pen, and pull out the worn nib through the included nib clip. Insert a replacement nib straight into the barrel of the pen until the nib stops moving forward. www.huion.com 35 / 36...

  • Page 36: Troubleshooting

    The pen tablet cannot sense the Huion driver. It is suggested to restart your computer after pen pressure while the cursor can finishing the installation. In addition, if the application is move.
