Fike Cheetah Xi Operating Instructions

Local, Auxiliary, Remote Station (PPU), Central Station (PPU), and Releasing Service
These instructions must be framed and displayed next to the panel in accordance with NFPA 72, National Fire Alarm Code
for Local Fire Alarm System.
The key to open the panel can be found at this location:
____________________________________________
1.0 OPERATING INFORMATION
Normal Standby
1. Green AC Power LED lit steady.
2. All notification appliances off.
System Alarm
1. Red Alarm LED flashes.
2. Local panel sounder (piezo) emits slow pulse pattern.
3. Alarm notification appliances on.
4. Alarm information visible on LCD (liquid crystal display).
5. DO NOT press the RESET key at this time.
6. Press the ACKNOWLEDGE key to turn off the local piezo.
Flashing LEDs will illuminate steady after key press.
7. Press the SILENCE key to turn off local piezo and silence
active notification appliances programmed for silence.
8. Press the F1 key to display the source of the event on the
top line of the LCD (liquid crystal display).
9. Investigate the source of the alarm condition and take
appropriate actions.
10. After correcting the Alarm condition, press the RESET key
to restore the system to normal operation.
System Trouble/Supervisory
1. Yellow Trouble and/or Supervisory LED flashes.
2. Local panel sounder (piezo) emits constant tone for
System Trouble.
3. Local panel sounder (piezo) emits fast pulse pattern for
Supervisory events.
4. Trouble and/or Supervisory notification appliances on.
5. Trouble and/or Supervisory information visible on LCD
(liquid crystal display).
6. DO NOT press the RESET key at this time.
7. Press the ACKNOWLEDGE key to turn off local panel
sounder. Flashing LEDs will be lit steady after key press.
8. Press SILENCE key to turn off local piezo and silence
active notification appliances programmed for silence.
9. Press the F1 key to display the source of the event on the
top line of the LCD (liquid crystal display).
10. Investigate the source of the Trouble/Supervisory condition
and take appropriate actions.
11. After correcting the Trouble/Supervisory condition, press
the RESET key to restore the system to normal operation.
OPERATING INSTRUCTIONS
Cheetah Xi Control System
(P/N 10-068)
Commercial Protected Premises Control Unit
Trouble Condition – Activation of a trouble signal under
normal operation indicates a problem with the system (not an
alarm) requiring immediate attention.
service representative. In most trouble conditions, the fire
suppression system continues to provide protection to the
building and its occupants; however, trouble conditions should
not be allowed to remain. Investigate and remedy as soon as
possible to ensure proper system operation.
Memory Fault – If panel experiences memory failure, local
panel sounder emits a constant tone, onboard trouble relay
transfers, and panel buttons do not respond to user input.
Under this condition, the panel is no longer providing protection
to the building and its occupants. Panel is to be replaced
immediately.
2.0 HISTORY AND CONTROL BUTTONS
Step Alarm – Steps through the current ALARM events stored
in the panel's Alarm history buffer. Available only if there are
active alarm events present on the system.
Step Super – Steps through the current SUPERVISORY
events stored in the panel's Supervisory history buffer.
Available only if active supervisory events are present.
Step All - Steps through ALL events stored in the panel's
current event history buffer.
between current events and the panel's entire 3,200 event
history buffer.
Drill – Manually activates all outputs and notification appliances
circuits assigned for drill operation in the configuration. Press
the RESET key to clear the drill activation.
activation on LCD (liquid crystal display).
Acknowledge – Silences the local piezo sounder and changes
all flashing LEDs to steady. All outputs remain active. Creates
an acknowledge event in the panel history buffer.
Silence – Silences the local piezo sounder and all silenceable
circuits. Illuminates the Yellow SILENCE LED steady and
creates a silence event in the panel history buffer.
Reset – Resets the control panel to normal operation.
active control functions (relays and NACs) will deactivate. All
display LEDs will illuminate steady until reset is complete. If
events are still present on the system, control functions will
immediately activate.
Enter – Saves and enters the current configuration settings.
Use navigation buttons to change variables at the blinking
cursor position.
Escape – Toggles event display from OFF-NORMAL (events
present) to SYSTEM NORMAL (no events present) to TOP
LEVEL menu.
Function Keys (F1 – F6) – Used to navigate through the
control panel's menu system during system operation,
maintenance and configuration.
Contact your local
Press the F5 key to toggle
Displays drill
P/N 06-653, Rev. 1
All
