Specification Handleiding 600C
Product:
APT Model:
Client Model:
Client:
Client Check:
Supplier：
Email
Approval:
August 2023
TFT LCD Display
600C
R|A|T Holland
www.rat-holland.nl
APT(Tianjin) Development Co., Ltd.
1001, Building 5 HuaDing, No.1 HuaKe 3
Road,
Binhai
Development Zone, Tianjin, China
TEL: 86 22 26345859
FAX: 86 22 83719955
info@rat-holland.nl
hi-tech
Industrial
Advertisement
Table of Contents
Related Manuals for APT 600C
Summary of Contents for APT 600C
- Page 1 Specification Handleiding 600C August 2023 Product: TFT LCD Display APT Model: 600C Client Model: R|A|T Holland www.rat-holland.nl Client: Client Check: Supplier： APT(Tianjin) Development Co., Ltd. 1001, Building 5 HuaDing, No.1 HuaKe 3 Road, Binhai hi-tech Industrial Development Zone, Tianjin, China...
-
Page 2: Table Of Contents
APT (Tianjin) Development Co., Ltd. Content Product model ............................3 Suppliers ..............................3 Specifications ............................3 Dimensions and Material ........................3 Features ..............................4 Main page ............................5 Functional Description .......................... 6 Power On/Off ..........................6 Assist levels ..........................6 Screen Switching ........................ - Page 3 APT (Tianjin) Development Co., Ltd. 8.5.1 Product Infor ......................... 19 8.5.2 Battery Infor ........................19 Errors code ............................19 10 Assembly instructions ......................... 20 11 Install and use precautions ........................ 20 12 Copyright Notice ..........................21 2 / 21...
-
Page 4: Product Model
APT (Tianjin) Development Co., Ltd. Product model Model: 600C Suppliers APT (Tianjin) Development Co., Ltd. Specifications 2.4inch TFT screen(IPS 240*320 pixel) Battery supply:24V/36V/48V/52V Multi-language support(6 languages) Maximum output current to controller: 200mA, off-leakage current <5μA Operating temperature: -15～40℃, Storage temperature -20～50℃... -
Page 5: Features
APT (Tianjin) Development Co., Ltd. Features 2.4inch TFT screen. Ergonomic external button design, easy to operate, vibration function is provided during button operation. 6 languages: Czech, German, French, English, Italian, Spanish are supported. Speed indicator: Speed (Real-time), AVG Speed, MAX Speed. -
Page 6: Main Page
APT (Tianjin) Development Co., Ltd. 6km walking. Firmware upgrade: Upgrade the Logo individually. Main page Power/Trip A/ Battery voltage Clock/Current Speed indication Speed value Battery indication Assist level Headlight LOGO/Error Modern mode C lock Power Battery voltage Speed indication... -
Page 7: Functional Description
APT (Tianjin) Development Co., Ltd. Classics page: TRIPA (Data reset after shutdown), TRIPB (Data is saved after shutdown), Odometer, Range(if Battery supports), TIMEA (Data reset after shutdown), TIMEB (Data is saved after shutdown). Speed Value: Real-time Speed, KM/H or MPH. -
Page 8: Screen Switching
APT (Tianjin) Development Co., Ltd. 7.3 Screen Switching Press button to switch the screen, including Main Page, Basic information POWER Page and Information Page(The Main Page can be set，refer to 8.1.5 ‘Scenes’). Main Page –Modern mode Main Page –Classics mode... -
Page 9: Walking Mode (6Km)
APT (Tianjin) Development Co., Ltd. * The brightness of the Display can be set according to the user's needs，Refer 8.1.3 Brightness. * The motor does not work when the battery voltage is low, Display still can keep the headlight on for a while when E-bike is in riding. -
Page 10: Display Settings
APT (Tianjin) Development Co., Ltd. 8.1 Display settings Display settings include several items：Language, System, Brightness, Auto off, Scenes, Clock, Focus. 8.1.1 Language 6 languages are supported: Czech, German, French, English, Italian, Spanish. Default is English. Select language then click “Back” to confirm. -
Page 11: Auto Off
APT (Tianjin) Development Co., Ltd. The light is turned on Display setting The light is turned off 8.1.4 Auto off This item enables to set the automatic shutdown time of the display, from 1 to 10min. Default value is 5 minutes, represents display shut down when there was no operation and riding for 5 minutes. -
Page 12: Clock
APT (Tianjin) Development Co., Ltd. 8.1.6 Clock This item can set date and time. You can choose Show-12 hour, Show-24 hour on Main Page. Show-12 hour Show-24 hour * Note: When display was powered off, internal Button Battery can keep clock running. When display is power on, Button Battery will be charged by external battery. -
Page 13: E-Bike Settings
APT (Tianjin) Development Co., Ltd. 8.2 E-bike Settings E-bike settings include several items：Start password, Assist levels, Wheelsize, Battery voltage, Battery Indexes, Pow Indexes, Pow range. 8.2.1 Start password The start password includes two parameter settings, Start password, OFF/ON. If you had set start password ON, you must input right password before power on. -
Page 14: Assist Levels
APT (Tianjin) Development Co., Ltd. The boot page after setting the start password * Display will automatically shut down if the correct password is not entered within 30S. Press and hold the button to shut down while entering the password. -
Page 15: Battery Indexes
APT (Tianjin) Development Co., Ltd. 8.2.5 Battery Indexes This item can select battery Indexes setting, including OFF, Percent, Voltage. Note: The voltage is the Voltage Percent remaining voltage or percentage of the battery. 8.2.6 Pow Indexes Main Page can be set to display Power(W) , Current(A), Trip A, Range, Clock. -
Page 16: Pow Range
APT (Tianjin) Development Co., Ltd. 8.2.7 Pow range Support Output power range Settings: 250W/500W/750W/1000W/1250W/1500W/1750W/2000W. 8.3 Advanced setting Advanced settings have password to prevent illegal modification, default password is ‘1919’, password may be different according to request. Advanced settings include Speed Limit, Current Limit, Poles In motor, Start after poles, Clockwise Start, Throttle 6km, Throttle Level, Start mode, and the error code messages of the last 10 times. -
Page 17: Speed Limit
APT (Tianjin) Development Co., Ltd. 8.3.1 Speed Limit Select range 10km/h ~ 41km/h（6.2Mile/h ~ 25.4Mile/h）. Note：The maximum speed is limited by the motor and controller, and it is not necessarily possible to reach the speed limit setting value. 8.3.2 Current Limit Select range 0 ~ 25 A. -
Page 18: Clockwise Start
APT (Tianjin) Development Co., Ltd. 8.3.5 Clockwise Start This parameter represent speed sensor turn direction, support front or reverse. 8.3.6 Throttle 6km Support OFF or ON, OFF represents max speed，ON represents 6Km. 8.3.7 Throttle Level This parameter is functional when Throttle 6KM set OFF. Support OFF or ON, OFF represent throttle start max speed, ON represent throttle’s speed is accorded to the... -
Page 19: Start Mode
APT (Tianjin) Development Co., Ltd. 8.3.8 Start mode Support three modes of STD/Eco/Pow. Pow mode means use maximum current when speed up, Eco mode means use minimum current. 8.4 Factory Setting Select ‘YES’ will restore all setting to factory defaults. -
Page 20: Battery Infor
APT (Tianjin) Development Co., Ltd. 8.5.2 Battery Infor Battery Information can show Voltage, Capacity, Cycle times, Current, Last Uncharge Times, Temperature, Remaining Capacity, Full Charge Capacity, Max Uncharge Times. The battery information will be displayed if the battery supports communication. -
Page 21: Assembly Instructions
12 Copyright Notice Questions about your e-bike, please contact with dealer firstly. APT reserves the right to modify this specification file, without declaration in advance. Content and Image owner：APT (Tianjin) Development Co., Ltd. 1001, Building 5 HuaDing, No.1 HuaKe 3 Road, Binhai hi-tech Industrial Development Zone, Tianjin, China website：www.aptdevelop.com... - Page 22 APT (Tianjin) Development Co., Ltd. 21 / 21...
