Specification
January
2023
TFT LCD Display
600C
APT(Tianjin) Development Co., Ltd.
1001, Building 5 HuaDing, No.1 HuaKe 3
Road,
Development Zone, Tianjin, China
TEL: 86 22 26345859
FAX: 86 22 83719955
yzhao@aptdevelop.com
Binhai
hi-tech
Industrial
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for APT 600C
Summary of Contents for APT 600C
- Page 1 TFT LCD Display APT Model: 600C Client Model: Client: ： Client Check Supplier： APT(Tianjin) Development Co., Ltd. 1001, Building 5 HuaDing, No.1 HuaKe 3 Road, Binhai hi-tech Industrial Development Zone, Tianjin, China TEL: 86 22 26345859 FAX: 86 22 83719955 Email yzhao@aptdevelop.com...
-
Page 2: Table Of Contents
APT (Tianjin) Development Co., Ltd. Content Product model ............................2 Suppliers ..............................2 Specifications ............................2 Dimensions and Material ........................2 Features ..............................2 Main page ............................3 Functional Description .......................... 4 Power On/Off ..........................5 Assist levels ..........................5 Screen Switching ........................ -
Page 3: Product Model
APT (Tianjin) Development Co., Ltd. 1 Product model Model: 600C 2 Suppliers APT (Tianjin) Development Co., Ltd. 3 Specifications 2.4inch TFT screen Battery supply:24V/36V/48V/52V Multi-language support(6 languages) Maximum output current to controller: 200mA, off-leakage current <1μA ... -
Page 4: Main Page
APT (Tianjin) Development Co., Ltd. Ergonomic external button design, easy to operate, vibration function is provided during button operation. 6 languages: Czech, German, French, English, Italian, Spanish are supported. Speed indicator: Speed (Real-time), AVG Speed, MAX Speed. -
Page 5: Functional Description
APT (Tianjin) Development Co., Ltd. Battery Headlight voltage Assist levels Speed value Power/ Current ODO/Trip/ Time/Range LOGO/ Brake Error Analog mode Clock: 12h or 24h. Head Light: Head Light on/ off. Mileage Mode: TRIPA (Data reset after shutdown), TRIPB (Data is saved after shutdown), Odometer, Range. -
Page 6: Power On/Off
APT (Tianjin) Development Co., Ltd. 7.1 Power On/Off Press POWER button for 2 seconds, you can turn on/off the display. The Display can automatically turn off when there is no operating and riding for 5 minutes. (The time can be set，refer to 8.1.4 ‘Auto off’) *Input pattern in first if pattern unlock was activated. -
Page 7: Headlight / Display Mode
APT (Tianjin) Development Co., Ltd. Basic information Page Information-1 Information-2 7.4 Headlight / Display Mode Press and hold UP button for 2 seconds can turn on/off headlight, display will switch to the corresponding mode (Day or Night). Night * The brightness of the Display can be set according to the user's needs， Refer 8.1.3 Brightness. -
Page 8: Menu Page
APT (Tianjin) Development Co., Ltd. 8 Menu Page Double press MENU button (press interval less than 0.3 second) can get into setting menus, press UP/DOWN button to change the parameter setting, press MENU button can get into or save the settings. Select EXIT or press MENU button twice to exit from menu. -
Page 9: Brightness
APT (Tianjin) Development Co., Ltd. 8.1.3 Brightness You can set the backlight brightness in the light on and off state, press UP/DOWN button to change brightness of backlight, 1 is darkness, 5 is brightness. The light is turned on Display setting The light is turned off 8.1.4... -
Page 10: Scenes
APT (Tianjin) Development Co., Ltd. 8.1.5 Scenes Select Digital or Analog. 8.1.6 Clock This item can set date and time. You can choose Show-12 hour, Show-24 hour on Main Page. Show-12 hour Show-24 hour * Note: When display was powered off, internal Button Battery can keep clock running. When display is power on, Button Battery will be charged by external battery. -
Page 11: Focus
APT (Tianjin) Development Co., Ltd. turned on for a long time, the Button Battery will drain (in winter or during long-distance transportation), Clock may slow or stop, please charge the battery as follows: Set “Automatic shutdown” to “OFF” (Disable power off automatically), keep the display power on for 72 hours. -
Page 12: Assist Levels
APT (Tianjin) Development Co., Ltd. If you had set start password ON, you must input right password before power on. Turn on the start password function Start password setting page You need to input the right password before start with 30 seconds. -
Page 13: Battery Voltage
APT (Tianjin) Development Co., Ltd. 12/14/16/18/20/22/24/26/27/27.5/28~31 inch, 51cm~250cm. Incorrect wheel diameter selection can lead to abnormal speeds. 8.2.4 Battery voltage The following voltage settings are supported: 24V/36V/48V/52V. 8.2.5 Battery Indexes This item can select battery Indexes setting, including OFF, Percent, Voltage. -
Page 14: Pow Indexes
APT (Tianjin) Development Co., Ltd. 8.2.6 Pow Indexes This item can select power indicator on Main Page, Power(W) , Current(A), Trip A, Range, Clock. Note: Power indicator represent battery’s output power (current), not motor. 8.2.7 Pow range Support Output power range Settings: 250W/500W/750W/1000W/1250W/1500W/1750W/2000W. -
Page 15: Factory Setting
APT (Tianjin) Development Co., Ltd. Input correctly password to enter advanced setting page, where you can adjust the speed limit, range 10km/h ~ 60km/h, 99m/h（6.2Mile/h ~ 37.3Mile/h, 61.5 Mile/h）, and where you can see the error code messages of the last 10 times. -
Page 16: Information
APT (Tianjin) Development Co., Ltd. Note：ODO, RANGE and CLOCK data are not cleared. 8.5 Information The information display interface includes: Speed and Mileage Information, Product Information, Battery Information. 8.5.1 Product Infor Product Information show Hardware Version, Software Version, Date… 8.5.2... -
Page 17: Assembly Instructions
APT (Tianjin) Development Co., Ltd. Error code prompt page Error Code Error description Handle Throttle error Check throttle and connection Throttle turn back fault Check throttle and connection Overvoltage protection Hall error Check the hall connection three-phase power error Check three-phase power line connection... -
Page 18: Install And Use Precautions
12 Copyright Notice Questions about your e-bike, please contact with dealer firstly. APT reserves the right to modify this specification file, without declaration in advance. Content and Image owner：APT (Tianjin) Development Co., Ltd. 1001, Building 5 HuaDing, No.1 HuaKe 3 Road, Binhai hi-tech Industrial Development Zone, Tianjin, China website：www.aptdevelop.com...
