TP-Link TL-SF1008P User Manual

8-port 10/100mbps desktop poe switch
Hide thumbs Also See for TL-SF1008P:
Table of Contents

Advertisement

Quick Links

TL-SF1008P
8-Port 10/100Mbps Desktop PoE Switch

User Guide

Rev：1.0.0
7106503865

Advertisement

Table of Contents
loading

Related Manuals for TP-Link TL-SF1008P

Summary of Contents for TP-Link TL-SF1008P

  • Page 1: User Guide

    User Guide TL-SF1008P 8-Port 10/100Mbps Desktop PoE Switch Rev：1.0.0 7106503865...
  • Page 3 No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD. Copyright © 2012 TP-LINK TECHNO- LOGIES CO., LTD. All rights reserved. http://www.tp-link.com...

  • Page 4: Fcc Statement

    FCC STATEMENT This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 5: Ce Mark Warning

    2) This device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. CE Mark Warning This is a class A product.

  • Page 6: Table Of Contents

    CONTENT ............Package Contents ......Chapter 1. Introduction of the Product Overview of the Product ........2 Convention ............3 Features..............3 ..........Chapter 2. Installation Mounting the Switch on a Desk......4 Power On ............... 5 ....Chapter 3. Identifying External Components Front Panel ............

  • Page 7: Package Contents

    Package Contents The following items should be found in your box: One TL-SF1008P 8-Port 10/100Mbps Desktop PoE Switch One DC Power Adapter Four rubber cushions to be used under the Switch This User Guide Note Make sure that the box contains the above items. If any of the listed items are damaged or missing, please contact your distributor.

  • Page 8: Chapter 1. Introduction Of The Product

    Chapter 1. Introduction of the Product Thank you for choosing the TL-SF1008P 8-Port 10/100Mbps Desktop PoE Switch. 1.1 Overview of the Product The TL-SF1008P 8-Port 10/100Mbps Desktop PoE Switch provides the seamless network connection, which integrates 100Mbps Fast Ethernet and 10Mbps Ethernet network capabilities.

  • Page 9: Convention

    1.2 Convention The Switch or TL-SF1008P mentioned in this User Guide stands for TL-SF1008P 8-Port 10/100Mbps Desktop PoE Switch without any explanation. 1.3 Features Complies with IEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.3af standards 8 10/100Mbps Auto-Negotiation RJ45 ports with 4 ports supporting PoE function (port-1~port-4), all of them support Auto-MDI/MDIX Supports PoE power up to 15.4W for each PoE port...

  • Page 10: Chapter 2. Installation

    Chapter 2. Installation During the installation procedure, please only use the accessories equipped with the Switch. 2.1 Mounting the Switch on a Desk To install the Switch, please follow the steps: 1) Place the Switch on a flat desk. 2) Remove the adhesive backing papers from the rubber cushions.

  • Page 11: Power On

    2.2 Power On The TL-SF1008P Switch can be used with DC power supply. Powering on the Switch, it will automatically initialize and its LED indicators will respond as follows: 1) Firstly, the Power LED indicator will light up. 2) Then, the 100Mbps and Link/Act LED indicators will flash momentarily for one second, which represents a resetting of the system.
  • Page 12 Name Status Indication The Switch is powered on. (green) Power The Switch is powered off. There is a PoE PD connected to the port, which supply power successfully. (green) Flashing The PoE power circuit may be in short or ports the power current may be overloaded.

  • Page 13: Rear Panel

    The following parts are located on the rear panel: Power (48V): 48V indicates the input voltage of the power adapter provided with this TL-SF1008P Switch. The Power socket is where you will connect the power adapter. PoE Ports (1-4): These ports support PoE function which integrates power and data onto one Ethernet cable.
  • Page 14 The working status can be indicated by the corresponding LEDs on the front panel. Ethernet Ports (1-8): Besides the 4 PoE ports, the TL-SF1008P Switch is also equipped with the other four 10/100Mbps Auto-Negotiation RJ45 ports without PoE function. Once the network devices are connected to these...

  • Page 15: Appendix A: Specifications

    Appendix A: Specifications General Standard IEEE802.3,IEEE802.3u,IEEE802.3x,IEEE802.3af Protocol CSMA/CD Ethernet: 10Mbps (Half Duplex) 20Mbps (Full Duplex) Data Transfer Rate Fast Ethernet: 100Mbps (Half Duplex) 200Mbps (Full Duplex) 10Base-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) Network Media(Cable) 100Base-TX:...
  • Page 16 Environmental and Physical 5.8 Watts (max. no PD connected) Power Consumption 58 Watts (max. with 53W PD connected) Operating Temperature 0 ~40℃ (32 ~104℉ ) Storage Temperature -40 ~70℃(-40 ~158℉) Operating Humidity 10%~90% non-condensing Storage Humidity 5%~90% non-condensing...
