EasyPro ECO Series Installation Instructions

UWD16
16-66 gpm
16"w x 3 / "t x 14" deep
1
2
32-132 gpm
(over 100 gpm should be plumbed from both ends)
32"w x 3
Thank you for purchasing the Eco-Series Universal Waterfall Diffuser. You are about to experience the
Eco-Series difference in water feature products. The simple design of all Eco-Series
®
you with reliable, trouble-free installation and maintenance for all your water feature designs. This Universal
Waterfall Diffuser is a fast and easy way to create professional looking waterfalls.
HOW IT WORKS...
Water enters the diffuser and is depressurized. Water then flows over and
under the vertical dividers resulting in an even flow of water at the source
point. These diffuser units are designed for flows up to 6000 gph from a
single end. By using both ends as inlets the UWD32 and UWD46 units can
handle higher flows.
Insert the threaded 2" plug into the unused port and tighten. When using dual
diffusers both ends may need to have a male adapter for higher flow rates.
Installation Instructions for
Universal Waterfall Diffusers
UWD32
/ "t x 14" deep
1
2
STEP ONE
Insert the 2" male adapter into the desired port and tighten. Ideally silicone or Teflon
tape is used on threads for water tight seal.
UWD46
50-200 gpm
(over 100 gpm should be plumbed from both ends)
46"w x 3 / "t x 14" deep
1
2
products provides
®
STEP TWO
UWD23
25-100 gpm
23"w x 3 / "t x 14" deep
1
2
