EasyPro EX8800 Installation And Service Manual

Installation and Service Manual
EasyPro
S/N: XXXX-XXXXXX
Model
Inlet
Discharge
Max Flow (gph)
Max Head (feet)
Max Power (watts)
Max Current (amps) 4.0 @ 115v
Volts
Motor HP
Motor Enclosure
Impeller
WARNING: Please read completely before you install or operate your new pump! This is an external "out-of-pond" pump!
It is NOT submersible! Do NOT allow this pump to become submerged! Never run dry! Max. case pressure.- 65 PSI!
EX8800 • EX11200 • EX13200
EX8800
EX8800 EX11200
2" 2"
2" 2"
8220 11160
22.3' 80.8'
450 2162
9.6@230v
115/230 230
1/2 3
TEFC TEFC
8 6
Reliability You Can Count On!
Please fi ll in for future reference:
EX13200
MODEL: ________________________________________
2"
SERIAL NUMBER: _______________________________
2"
DATE PURCHASED: _____________________________
* Please fi ll out the warranty registration card in this manual
13200
81.7'
MOTOR: NEMA C FACE, 56J
HORSEPOWER: 1/2 (1750 RPM), 3 (3450 RPM)
2595
11.5@230v
DISCHARGE: 2" FNPT AND BUTTRESS THREAD PORTS
MATERIAL: 40% GLASS-FILLED POLYPROPYLENE
230
HARDWARE: STAINLESS STEEL
OPTIONS: SALTWATER SERVICE
3
ACCESORIES: 90 CUBIC INCH STRAINER BASKETS (1.5" & 2")
TEFC
7
TYPE: STRAIGHT CENTRIFUGAL
INLET: 2" FNPT AND BUTTRESS THREAD PORTS
SWING CHECK VALVES (1.5", 2", 3")
500 CUBIC INCH STRAINER BASKETS
(1.5", 2", 3")
© 2010 EasyPro, Inc
Pg. 1
