EPA1900 • EPA2500 • EPA3100
EPA4500 • EPA5500 • EPA6500 • EPA9500
High Volume Mag Drive Pumps
Thank you for purchasing the EasyPro Mag Drive pump.
This pump is a magnetically driven water pump. It contains
no oil, shaft seals or bearings. This pump combines
simplicity of design with the most energy efficient operation
of any pump. All electrical components are encapsulated
in epoxy. The impeller assembly consists of impeller blades
attached to a magnet and is easily replaced should the
need arise. There are threaded inlet and outlet ports on all
models.
Safety and Electrical Connections
Always disconnect the electrical supply before handling, maintaining,
1.
repairing or installing any pond equipment.
2.
Connect this product only to a 115 volt receptacle that is protected by a Ground Fault
Circuit Interrupter (GFCI).
3.
The pump must be fully submersed underwater at all times when operating.
4.
Never let the pump run dry, as this can damage the impeller, over heat the pump and
possibly burn out the pump.
5.
Do not use this product in bathrooms or swimming pools.
6.
For fresh water applications only. Not for use in chlorinated systems.
7.
It is highly recommended to place the pump in an EasyPro skimmer.
8.
All electrical work must be performed by a qualified technician. Always follow the National
Electrical Code (NEC) or the Canadian Electrical Code as well as all local, state and
provincial codes. Code questions should be directed to your local electrical inspector.
Failure to follow electrical codes and OSHA safety standards may result in personal injury
or equipment damage. Failure to follow manufacturer's installation instructions may result
in electrical shock, fire hazard, personal injury or death, damaged equipment, provide
unsatisfactory performance and may void manufacturer's warranty.
When installing a check valve assembly, thread in the assembly finger tight. Do not over
9.
tighten as this could crack the housing and is not covered under warranty.
Instructions for
Operation • Safety • Warranty
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for EasyPro EPA1900
Summary of Contents for EasyPro EPA1900
- Page 1 Do not use this product in bathrooms or swimming pools. For fresh water applications only. Not for use in chlorinated systems. It is highly recommended to place the pump in an EasyPro skimmer. All electrical work must be performed by a qualified technician. Always follow the National Electrical Code (NEC) or the Canadian Electrical Code as well as all local, state and provincial codes.
- Page 2 Clean the intake screen if clogged. Flow will be visibly reduced. If the impeller needs to be serviced, remove the intake screen. For EPA1900, EPA2500 and EPA3100, carefully pull screen from pump housing by hand. No tools required. For EPA4500,EPA5500,EPA6500,EPA9500, remove the four #2 Phillips screws from each foot and remove the screen.
- Page 4 EasyPro shall not be held liable for any loss of fish, plants or any other livestock as a result of any failure or defect of this Product. This warranty gives you specific legal rights, and you may also have other rights that vary from State to State.
