TWO SPEED CENTRIFUGAL • EX6750-2
Installation and Service Manual
EasyPro
EX6750-2
S/N: XXXX-XXXXXX
TYPE:
STRAIGHT CENTRIFUGAL
MOTOR:
NEMA C Face, 56J
HORSEPOWER:
.2 (1750 RPM), 1.5 (3450 RPM)
VOLTAGE:
115
MODEL
SPEED INLET
HIGH
1.5"
EX6750-2
LOW
1.5"
WARNING: Please read completely before you install or operate your new pump! This is an external "out-of-pond" pump!
It is NOT submersible! Do NOT allow this pump to become submerged! Never run dry! Max. case pressure.- 65 PSI!
INLET:
DISCHARGE:
MATERIAL:
HARDWARE:
OPTIONS:
DISCHARGE
MAX FLOW
MAX HEAD
(gph)
(feet)
1.5"
6750
84
1.5"
3350
21
Reliability You Can Count On!
1
/
" FNPT
1
2
1
/
" FNPT
1
2
40% Glass-Filled Polypropylene
STAINLESS STEEL
SALTWATER SERVICE
MAX POWER
MAX CURRENT
@ (volts)
(watts)
(amps)
1453
12.7
115
275
4.4
115
Please fi ll in for future reference:
MODEL: _____________________________
SERIAL NUMBER: ____________________
DATE PURCHASED: __________________
* Please fi ll out the warranty registration
card in this manual.
ACCESORIES:
90 CUBIC INCH STRAINER BASKETS
(1
/
" & 2"),
1
2
SWING CHECK VALVES (1
500 CUBIC INCH STRAINER BASKETS
(1
/
", 2", 3")
1
2
MOTOR
MOTOR
HP
VOLTAGE
ENCLOSURE
1.5
115 Only
ODP
0.2
115 Only
ODP
/
", 2", 3"),
1
2
MOTOR
IMPELLER
4
4
© 2010 EasyPro, Inc
Pg. 1
Advertisement
Table of Contents
Related Manuals for EasyPro EX6750-2
Summary of Contents for EasyPro EX6750-2
- Page 1 TWO SPEED CENTRIFUGAL • EX6750-2 Installation and Service Manual EasyPro EX6750-2 S/N: XXXX-XXXXXX Please fi ll in for future reference: MODEL: _____________________________ SERIAL NUMBER: ____________________ DATE PURCHASED: __________________ * Please fi ll out the warranty registration card in this manual.
- Page 2 To insure proper performance, we urge you to carefully follow the instructions in this manual. If you have any questions, call your nearest distributor or EasyPro for assistance. INSTALLATION Please read carefully! When properly installed this pump will provide dependable trouble-free service.
- Page 3 TWO SPEED CENTRIFUGAL • EX6750-2 PUMP END ASSEMBLY 1. Clean and inspect all pump parts (0-ring, seal seats, motor shaft, etc.). 2. Apply sealant to the bracket bore ID wall and around the seal case - follow sealant mfg. instructions. We recommend using Gasgacinch .
- Page 4 7. This warranty is in lieu of all other express warranties which now or hereafter might otherwise arise with respect to this product. Any and all limited warranties, the event this product malfunctions within 18 months from the date of purchase, the sole obligation of EasyPro, Incorporated (hereinafter referred to as EP) will be including the warranties of merchantability and fi...
