MATRIX and MATRIX RT
Online Double Conversion UPS
1:1
1-2-3 kVA
Singlephase / Singlephase
Accedi al link ed utilizza la password per scaricare il manuale in Italiano
Access the link and use the password to download the manual in English
Accédez au lien et utilisez le mot de passe pour télécharger le manuel en Français
Acceda al enlace y utilice la contraseña para descargar el manual en Español
Rufen Sie den Link auf und verwenden Sie das Passwort, um das Handbuch
auf Deutsch herunterzuladen
Uzyskaj dostęp do linku i użyj hasła, aby pobrać instrukcję w języku włoskim
العربية باللغة الدليل لتن ز ز يل المرور كلمة واستخدم ال ر ابط عىل ادخل
Зайдите по ссылке и используйте пароль для загрузки русского руководства
USER MANUAL | EN
www.gtec-power.eu
http://gtec-power.eu/en/matrix-
user-manual/
PASSWORD: GTCMTX11022
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Gtec Matrix Tower 1K
Summary of Contents for Gtec Matrix Tower 1K
- Page 1 1-2-3 kVA Singlephase / Singlephase Accedi al link ed utilizza la password per scaricare il manuale in Italiano http://gtec-power.eu/en/matrix- Access the link and use the password to download the manual in English user-manual/ Accédez au lien et utilisez le mot de passe pour télécharger le manuel en Français Acceda al enlace y utilice la contraseña para descargar el manual en Español...
- Page 3 Manufacturer: G-Tec Europe S.r.l Strada Marosticana 81/13 36031 Dueville (VI) Italy www.gtec-power.eu Service and support: Call your local service representative Service Agency Name Phone number Mail Legend • RT: Short form for Matrix RT for use in rack Cabinet, but it can be use also in Tower •...
- Page 4 SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS. This manual contains important instructions that should be followed during installation and maintenance of the UPS and batteries. UPS Tower models are considered acceptable for use in the ambient of 0 ~ 45°C. UPS RT models are considered acceptable for use in the ambient of 0 ~ 40°C. Certification standards •...
- Page 5 Safety of persons Dangerous voltage levels are present within the system. It should be opened exclusively ⚫ by qualified service personnel. The system must be properly grounded. ⚫ The battery supplied with the system contains small amounts of toxic materials. To avoid ⚫...
- Page 6 for PERMANENTLY CONNECTED EQUIPMENT, a readily accessible disconnect device shall ⚫ be incorporated external to the equipment. for PLUGGABLE EQUIPMENT, the socket-outlet shall be installed near the equipment and ⚫ shall be easily accessible. Check that the indications on the rating plate correspond to your AC powered system ⚫...
-
Page 7: Table Of Contents
Contents 1 Introduction .........................1 1.1 Electronic equipment protection ................1 1.2 Environmental protection ..................2 2 Product Overview ......................3 2.1 Weight and Dimension ....................3 2.2 Rear panels ......................... 5 3 Installation ........................9 3.1 Inspecting the equipment ..................9 3.2 Checking the accessory kit ..................9 3.3 Install the Unit ...................... -
Page 8: Introduction
Bigger charger current for long backup mode:8A, adjustable from 2A to 8A through LCD • EBM quantity auto detection • Communication ports: RPO, Dry in, Dry out, intelligent slot, USB, RS232 • IoT: Ethernet(default) and Wireless (Optional) • Dot-matrix LCD, it supports Multi-Language • ECO Mode • Start-able without battery. www.gtec-power.eu... -
Page 9: Environmental Protection
(WEEE). Battery The product contains lead-acid batteries that must be processed according to applicable local regulations concerning batteries. The battery may be removed to comply with regulations and in view of correct disposal. www.gtec-power.eu... -
Page 10: Product Overview
428 X 192 X 318 Tower 3K 26,4 428 X 192 X 318 Tower 3K-KS 11,4 428 X 192 X 318 Tower 36V EBM 16,8 404 X 145 X 220 Tower 72V EBM 38,7 428 X 192 X 318 www.gtec-power.eu... - Page 11 15,8 445*438*85,5 (2U) RT 1,5K-KS 445*438*85,5 (2U) RT 2K 23,3 600*438*85,5 (2U) RT 2K-KS 10,6 600*438*85,5 (2U) RT 3K 26,2 600*438*85,5 (2U) RT 3K-KS 11,0 600*438*85,5 (2U) RT 36V EBM 22,6 445*438*85,5 (2U) RT 72V EBM 39,9 600*438*85,5 (2U) www.gtec-power.eu...
-
Page 12: Rear Panels
Rear panels Tower 1K/1K-KS/1,5K/1,5K-KS (IEC is the std version) Tower 2K/2K-KS (IEC is the std version) www.gtec-power.eu... - Page 13 Tower 3K (IEC is the std version) Tower 3K-KS (IEC is the std version) www.gtec-power.eu...
- Page 14 Tower EBM (battery cabinet) 1K/1K-KS/1,5k/1,5K-KS 2K/2KS www.gtec-power.eu...
- Page 15 36V EBM (battery Cabinet) 72V EBM (battery Cabinet) WLAN(HDMI) Ethernet (RJ45) RPO/Dry in/Dry out EBM auto detection RS232 Slot Card Box EBM Connector Input Breaker(optional) Input Socket/ Output Socket/ Output Fuse (optional) Input Terminal Output Terminal Programmable Output Socket www.gtec-power.eu...
-
Page 16: Installation
2. Send a copy of the damage claim within 15 days to your service representative. 3.2 Checking the accessory kit Tower model Input cable (Except for 3KS models) Output cable (only for IEC models) USB cable RS232 cable(optional) Slot card (optional) User manual User manual (Multi-Language) (optional) www.gtec-power.eu... - Page 17 RT model Output cables Input cable USB cable User manual Tower stands Rack ears Slot card (optional) Cable lockers (optional) Rail kit (optional) RS232 cable (optional) User manual (Multi-Language) (optional) www.gtec-power.eu...
-
Page 18: Install The Unit
Note: The UPS charges the battery as soon as it is connected to the AC-power source, even if button is not pressed. Once the UPS is connected to the AC-power source, 8 hours of charging are required before the battery can supply the rated backup time. www.gtec-power.eu... - Page 19 4 mm²/(0,8N.m) 10 mm² conductor cross section Note: For Tower 3K-KS, the output cable should less than 3m. When the cables connected to terminal block, the inner copper wire must not be exposed to avoid the risk of electric shock. www.gtec-power.eu...
- Page 20 3.3.1 RT models • Rack installation Follow steps 1 to 4 for module mounting on the rails. www.gtec-power.eu...
-
Page 21: Connecting The Ebm(S)
3.4 Connecting the EBM(s) A small amount of arcing may occur when connecting an EBM to the UPS. This is normal and will not harm personnel. Up to 4 EBMs can be connected to the UPS. 3.4.1 Tower models 1k/1,5k www.gtec-power.eu... - Page 22 2k/3k 3.4.2 RT models www.gtec-power.eu...
-
Page 23: Operation
The UPS is operating normally on Online or on High Efficiency mode. Green The UPS is on Battery mode. Yellow The UPS is on Bypass mode, load is supply from mains. Yellow The UPS has an active alarm or fault. See Chapter 7 troubleshooting for additional information. www.gtec-power.eu... -
Page 24: Lcd Description
Press the button to mute the buzzer temporarily, once Mute buzzer new warning or fault is active, buzzer will work again LCD description The LCD backlight automatically dims after 10 minutes of inactivity. Press any button to restore the screen. www.gtec-power.eu... - Page 25 UPS is in Bypass mode. Battery test UPS is executing a battery test Battery fail The UPS detects bad battery or battery disconnected Load >100%, some unnecessary loads should be cut off Overload to reduce the load. Fault mode Some fatal problems happened. www.gtec-power.eu...
-
Page 26: Display Functions
[200V], [208V], [220V], [230V], [240V] [240V] for AU Output frequency [autosensing], [converter 50Hz, 60Hz] autosensing High efficiency mode [disabled], [enabled] disabled Auto bypass [disabled], [enabled] disabled Cold start/Auto restart: Start/Auto restart/Start enabled [disabled], [enabled] from bypass Start from bypass: disabled www.gtec-power.eu... -
Page 27: Starting The Ups With Utility
Date and time dd/mm/yyyy hh:mm LCD contrast [-5 ~ +5] [enabled], [disabled] disabled Modbus TCP [enabled], [disabled] disabled If the load type is a transformer type, it is recommended to enable the “start from bypass” function. Starting the UPS with utility www.gtec-power.eu... -
Page 28: Starting The Ups On Battery
Starting the UPS on Battery Before using this feature, the UPS must have been powered by utility power with output enabled at least once (press ON >0,1s & <1s). Battery start can be disabled. Refer to the Chapter 4.4 User setting UPS Shutdown www.gtec-power.eu... -
Page 29: Communication
Dry in Comments Connector type 16 AWG Maximum wires External breaker specification 60 V DC/30 V AC 20 mA max • Dry out Dry out is the relay out, dry out function can be configured (see Settings > Dry out). www.gtec-power.eu... -
Page 30: Iot
Remote report UPS faults and status (contact with your service for detail) from APP or registered APP account (Email address). o Automatic UPS and battery warranty alert from APP or registered APP account (Email address). IoT Connection - Wired connection 1. Connect UPS and router or switch with network cable www.gtec-power.eu... -
Page 31: Modbus Tcp
The wireless module is optional, please contact your local distributor for details. 5.4 Modbus TCP Built-in ethernet port offers Modbus TCP feature to facilitate remote monitoring of the UPS into your own software. Contact with your service for protocol details. www.gtec-power.eu... -
Page 32: Intelligent Card (Optional)
WinPower provides user-friendly interface to monitor and control your UPS. This unique software provides safely auto shutdown for multi-computer systems while power failure. With this software, users can monitor and control any UPS on the same LAN no matter how far from the UPSs. www.gtec-power.eu... - Page 33 WinPower View APP WinPower View is a mobile app which allows you to centralized monitoring UPS(s) connected to cloud. Please download it from Google Play store or Apple APP store. Please refer to the chapter 5.3 for IoT connection. www.gtec-power.eu...
-
Page 34: Ups Maintenance
DO NOT DISCONNECT the batteries while the UPS is in Battery mode. Consider all warnings, cautions, and notes before replacing batteries. Servicing should be performed by qualified service personnel with knowledgeable ⚫ of batteries and required precautions. Keep unauthorized personnel away from batteries. www.gtec-power.eu... - Page 35 • Replacing the internal battery (For RT) Put the new battery pack into the UPS. Screw back the metal protection covers and the front panel. Testing new batteries. Verify that the replacement batteries have the same rating and brand as the batteries being replaced. www.gtec-power.eu...
-
Page 36: Recycle
By separating waste electrical and electronic equipment, you will help reduce the volume of waste sent for incineration or land-fills and minimize any potential negative impact on human health and environment. www.gtec-power.eu... -
Page 37: Troubleshooting
OBM cycling mode. The UPS does not Apply utility power for 48 hours to provide the The batteries need charging charge the batteries. If the condition expected backup or service. persists, contact your service time. representative. www.gtec-power.eu... - Page 38 APP cannot connect IoT is disabled Enable IoT function in LCD to UPS Your IT settings may block please refer to WinpowerView app help UPS get cloud connected file (NTP, Proxy, etc.) www.gtec-power.eu...
-
Page 39: Specifications
<1% linear load; <5% nonlinear load Output Transfer time 0ms@line <-> battery; 4ms @ line <-> bypass; 10ms @ ECO <->Inverter performance Crest Ratio Max 3:1 100%<load≤105% continuous. 105%< load ≤125% for 5 minutes Overload 125<load≤150% for 30 seconds. >150% for 500ms. www.gtec-power.eu... - Page 40 Optional, AS400 Long Card Wireless module Optional IOT Ethernet port RJ45 Monitor software Winpower, Winpower View APP Dimension RT: 438*445*85.5(2U) RT: 438*600*85.5(2U) (W*D*H) mm Tower: 145*404*220 Tower: 192*428*318 Physical IP protection level IP20 performance Plug solid RT: Optional; Tower: NA Wheel www.gtec-power.eu...
- Page 41 IEC/EN 61000-4-5 Input power cable Output power Yes (For IEC models) cable EBM cable Yes (in EBM) USB cable Accessory RS232 cable Optional Rail kit Optional Tower Feet RT: Yes; Tower: No Rack ear RT: Yes; Tower: No Manual (English) www.gtec-power.eu...
- Page 42 614-40071-01...
