LED INDICATORS

Table 3-1 describes the LED indicator conditions for check and card reading operations. The
LED indicator is located below the slot where the check is first inserted for reading.
LED INDICATOR
OFF
SOLID GREEN
OFF→ SOLID GREEN
SOLID RED/GREEN
FLASH RED
SOLID RED

CLEANING

Clean the outside of the MDX with a soft, damp cloth and wipe with a dry cloth.
To avoid damaging the read head, do not touch the inside of the
check or card paths with a wet cloth.
Use the Cleaning Swab, P/N 97200078, to clean the Scan Bars as shown and described in the
next section.

Table 3-1. LED indicators

-Power off
-Processing check
Ready to read check or card
Good read
Initialization
-Motor sensor blocked (motor does not run)*
-Error reading MICR data
-Error reading card data
Suspend mode
*Refer to "Section 4. Troubleshooting Guide."
Caution
DESCRIPTION
Section 3. Operation
