Summary of Contents for HPRT HLP106D
- Page 1 Label Printer User Manual HLP106D Xiamen Hanin Electronic Technology Co.,Ltd ADD: 5F,8#,Aide Airport Industrial Park, Huli District, Xiamen, China 361009 Tel.: +86-(0)592-5885993 Fax: +86-(0)592-5885992 Web: www.hprt.com...
- Page 2 REVISION RECORDS REV. DATE DESCRIPTION DRAWN CHECKED APPROVED 2014.11.18 Preliminary Cui Xiao Yang Kaiqu Ren Xiaowei 1.Update Important Safety Instruction 2.Change structure General Specification 3.Update the printing speed to 120mm/s; 4.Change the picture of Control Panel 5.Update Chapter 5 2015.06.24 Ji Qiuxia Yang Kaiqu Ren Xiaowei...
-
Page 3: Table Of Contents
Contents MANUAL INFORMATION ......................... 2 IMPORTANT SAFETY INSTRUCTIONS ....................3 CHAPTER 1 INTRODUCTION ......................5 1.1 Packing List ........................5 1.2 Appearance and Components ................... 6 1.3 Dimension .......................... 7 CHAPTER 2 SPECIFICATIONS ......................8 CHAPTER 3 INSTALLATION & USAGE ....................9 3.1 Media Loading ........................ - Page 4 HLP106D User Manual Statement This manual content may be altered without permission, and Xiamen Hanin Electronic Technology Co., Ltd. reserves the rights to make changes without notice in technology, spare parts, hardware and software of the products. If more information is needed about the products, please contact Xiamen Hanin Electronic Technology Co., Ltd.
-
Page 5: Manual Information
HLP106D User Manual MANUAL INFORMATION This User Manual contains basic information for product usage as well as for emergency measures that may be required. Provides information on utility usage for function selection, operating condition modification etc. Provides information on Seagull Windows Driver installation. -
Page 6: Important Safety Instructions
HLP106D User Manual IMPORTANT SAFETY INSTRUCTIONS Before using the appliance, please carefully read the following safety regulations in order to prevent any hazard or material damage. 1.Safety Precautions 1) Be sure to use the accompanying power charger, if not, it may cause fire, explosion or damage. - Page 7 HLP106D User Manual 4. Other Precautions The copyright for this user manual and various other manuals is property of our company. Any copying or conversion into electronic firm and saving of this material without the express written permission of our company is strictly prohibited. Use of the information contained in this manual is not subject to any patent liability.
-
Page 8: Chapter 1 Introduction
HLP106D User Manual CHAPTER 1 INTRODUCTION 1.1 Packing List Notes: 1. Unpack the printer and keep the packing material in case you need to ship the printer in the future. 2. Make sure you own all parts as follows, if not, do contact the local dealer. -
Page 9: Appearance And Components
HLP106D User Manual 1.2 Appearance and Components Note: Views above are for reference only, ports differ by your choice. Rev.1.3... -
Page 10: Dimension
HLP106D User Manual 1.3 Dimension Rev.1.3... -
Page 11: Chapter 2 Specifications
HLP106D User Manual CHAPTER 2 SPECIFICATIONS Items Parameter Printing method Thermal transfer/Direct thermal Resolution 203dpi(8dots/mm) Printing speed Printing 102mm/s Max. Printing width 108mm Max. Printing length 15mm - 300mm 32 bit RISC CPU Processor Memory Flash Adjustable reflective sensor,Fixed transmissive... -
Page 12: Chapter 3 Installation & Usage
HLP106D User Manual CHAPTER 3 INSTALLATION & USAGE 3.1 Media Loading 3.1.1 Open the Printer Cover Push two cover open buttons simultaneously and then lift the cover. 3.1.2 Open The Printing Group Press the two release latches simultaneously and lift the printing group. - Page 13 HLP106D User Manual 3.1.3 Paper Roll Loading 1. Open the printer cover. According to the roll paper core , adjust the direction of paper supply shaft. It supports three kinds of roll paper core, there are instruction on the paper supply shaft.
- Page 14 HLP106D User Manual 3.1.4 Ribbon Loading 1.Put the new ribbon into the ribbon supply shaft, and put ribbon supply group into the printing group. Figure 3-3 2. Put the empty ribbon core into ribbon pick-up shaft, and put ribbon pick-up group into the printing group.
- Page 15 HLP106D User Manual 3.Pull some ribbon out, pass through print head. Stick the front of ribbon to the empty ribbon core and wind the ribbon core 2~3 circles. Turn around the ribbon feed mechanism to make it smooth. 4. Press down the printing group and fix it, then close the printer cover.
-
Page 16: Power Connection
HLP106D User Manual 3.2 Power Connection 1. Make sure the printer is power off. 2. Connect the power adapter to the printer power supply connector. 3. Connect the power cord to the power adapter. 4. Connect the other end of power cord to the socket. -
Page 17: Interface Cable Connection
HLP106D User Manual 3.3 Interface Cable Connection The standard for the printer’s interface cable is below: - USB B-Type cable -RJ45 cable 1. Make sure the printer is off. 2. Please plug in the cables Insert the USB B-Type cable into the interface;... -
Page 18: Detection
HLP106D User Manual 3.4 Detection Rev.1.3... -
Page 19: Control Panel
HLP106D User Manual 3.5 Control Panel 1. READY and STATUS indicators Show the printer’s information via different colors(red & kelly) and LED status( on and flash) 2. FEED button ① Feed paper The printer will auto-feed the paper to the specified points according to the type of paper used. -
Page 20: Basic Operation
HLP106D User Manual 3.6 Basic Operation 3.6.1 Power On/Power Off Press “O” to power off the printer. Press "I" to power on the printer. 3.6.2 Feed Paper Pressing FEED button, printer will feed paper to the specified position according to the paper type. - Page 21 HLP106D User Manual 3.6.4 Print Self-test Page The self-test checks the printer’s current settings, status and whether the printer has any problem. The users can print out the “self-test page”through two methods. 1. Print out self-test page a. Check whether the paper/ribbon has been installed on the printer, whether the power is connect.
-
Page 22: Chapter 4 Interface
HLP106D User Manual CHAPTER 4 INTERFACE 4.1 USB Interface Figure 4-1 SIGNAL NAME VBUS 4.2 Other Optional Interface Ethernet Port SIGNAL NAME Rev.1.3... -
Page 23: Chapter 5 Printer Cleaning
HLP106D User Manual CHAPTER 5 PRINTER CLEANING Adhesives and coatings of the media can transfer onto the printer parts over time along the media path including the thermal print head and media sensor. This build-up can accumulate dust and debris. Failure to clean the print head, media path, and media sensor could result in print quality, worst more of inadvertent loss off labels, label jams and possible damage to the printer. -
Page 24: Chapter 6 Label Printer Utility Instructions
HLP106D User Manual Chapter 6 Label Printer Utility Instructions 6.1 Installation Preparation Download HPRTUtilityLabel application program.eg:Print Utility For Label--Channel V2.0.0.1. 6.2 Usage Note: The screen may vary slightly by different operating systems and models. (1).Install “HPRTUtilityForLabel V2.0.0.1.exe” and then open the “HPRTUtility”. - Page 25 HLP106D User Manual ●Click “Add Printer” choose the printer and port(take “USB” for example), click “OK” add successful, check in “Printer List”. ●Click “Modify Printer” choose the printer and port(take “COM1” for example), click “OK” modify successful, and check in “Printer List”.
- Page 26 HLP106D User Manual ●Click “Delete Printer”, click “OK” delete the printer you chosen, click “Cancel” cancel delete printer. ●Choose the printer you currently use, connect it with computer; Click “Connect Test” to test whether the connection is ok or not.
- Page 27 HLP106D User Manual (3).Function. ●Click “Printer Information”, shows printer information.(Differ from your printer) ●Click “Print Test Text”, type the text you need to print→ Set up the printing range(printable width & height)→Click “Print” printer start to print printer test text.
- Page 28 HLP106D User Manual ●Click “Parameter Setting”. 1) Print density (choose range:0~15,0:Washiest): 2) Print type: 3)Label paper automatic position when power on: 4) Ethernet Setting: 5) After stopping X mins, enable the anti-adhesive paper function(choose range:0~255): 6)Print when error: 7) Select small label (Label length less than 20mm):...
- Page 29 HLP106D User Manual 8) Other: Max Mark Length(choose range:0~500mm): Judge Paper Mode(Label, Receipt, BlackMark): Codepage: Heat Adjust: Print Speed(choose range:2,3,4): ●Click “Restore Factory Settings”, click “OK” printer restore factory settings, click “Cancel” cancel restore factory settings. (4).Click “Quit”, finish printer settings.
-
Page 30: Chapter 7 Seagull Windows Driver Installation
HLP106D User Manual Chapter 7 Seagull Windows Driver Installation 7.1 Introduction This chapter provides information on installation according to PC operating system (OS). This driver support for these following operating systems: Microsoft Windows 10 (32 bit/64 bit) Microsoft Windows 8 (32 bit/64 bit) -
Page 31: Installation
HLP106D User Manual 7.3 Installation Warning: Under different operating system, the screen has slight difference. Please operate it according to the tips. Take Windows XP as example. Recommend to close security software before installation in case of preventing installation. 1.Select one interface to connect your printer to computer. - Page 32 HLP106D User Manual 6.Click"Finish". 7.Select "Install printer drivers" then click "Next". Rev.1.3...
- Page 33 HLP106D User Manual Note: Connect your printer to computer, can automatically detect and install.(Take USB for example) 8.Select "Install a driver for a Plug and Play printer, click "Next". 9.Enter a name for this printer, click "Next". Rev.1.3...
- Page 34 HLP106D User Manual 10.Click"Finish". 11.Click "Close", the HPRT HLP106D Label printer driver installed successfully. 12.After installation, the icon will be found in ”Start”→“Printers and Faxes”. Note: 1.If you already installed the driver (No matter what kind of port), when you connect the printer with computer, it will create a USB port automatically.
-
Page 35: Chapter 8 Bartender® Ultralite Installation
HLP106D User Manual Chapter 8 BarTender® Ultralite Installation 8.1 Introduction This chapter provides information on BarTender® installation according to PC operating systems(OS). This label design software is available in two versions:32-bit and 64-bit. 8.2 Installation Preparation Download BarTender® application program. -
Page 36: Installation
HLP106D User Manual 8.3 Installation Note：Under different operating system, the screen has slight difference. Please operate it according to the tips. Take Windows 7 as example.(Recommend to close security software before installation in case of preventing installation) 。 1.Double click application program 2.Select language, then click "OK"。... - Page 37 HLP106D User Manual 4.Read and accept the license agreement, then click "Next"。 5.Select "Features" and "Installation Location" then click "Next". Rev.1.3...
- Page 38 HLP106D User Manual 6.Click "Installation"。 7.If occurs following windows, please choose "Allow this operation", or you may close security software before installation in case of preventing installation. Rev.1.3...
- Page 39 HLP106D User Manual 8.Click "Finish"。 9. Select the edition you need（can be changed according to your need while using）,then click "OK". Rev.1.3...
- Page 40 HLP106D User Manual 10.Click "Close", BarTender® installed successfully。 11.Back to desktop, you may see BarTender® icon,dobule click it get down to use. Rev.1.3...
