SK41
Direct thermal label printer
Direct thermal label printer
User Guide
Website: http://www.hprt.group
Customer Service Email: sk@hprt.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the SK41 and is the answer not in the manual?

Questions and answers

Summary of Contents for HPRT SK41

  • Page 1 SK41 Direct thermal label printer Direct thermal label printer User Guide Website: http://www.hprt.group Customer Service Email: sk@hprt.com...
  • Page 2: Packing List

    Appearance ❻ ❷ ❶ ❸ ❺ ❹ ❼ ❽ ❶ Feed Bu�on(Status Indicator) ❺ USB Port ❷ Paper Guide ❻ Print Head Module ❸ Cover Open Levers ❼ Platen ❹ Power Receptacle ❽ Movable Paper Sensor Packing List ● Unpack the printer and keep the packing materials in case you need to ship the printer in the future.
  • Page 3 Printer Connec�on Power Connec�on 1. Make sure the printer’s power switch is in the off posi�on. 2. Connect the power cord to printer. 3. Connect the other end of power cord to the outlet. 4. Connect the USB cable to the printer and PC. ❶...
  • Page 4 Fanfold Label Loading Folding Paper Loading Insert the paper into the entry Turn the power on, adjust the slot. paper guide to fit the width of paper. The paper will be sucked into Roll Type Label Loading the paper guide automa�cally. NOTE: ●...
  • Page 5 Feed Bu�on ● Turn on In the shutdown state, turn on the power switch behind the printer, then the indicator will be light on. ● Turn off When the power switch is turned off, the printer shuts down and the indicator light is off. In the power-on state, turn off the power switch behind the printer, then the indicator will be light off.
  • Page 6 Windows Driver Instruc�on Driver Prepara�on for windows Download Windows Driver applica�on program in h�p://www.hprt.group. Driver Installa�on for Windows Warning: Recommend to close security so�ware before installa�on in case of preven�ng installa�on. 1. Select one interface to connect your printer to computer.
  • Page 7 Prin�ng Preferences 1. Click “Start” → “Devices and Printers”. Right click the icon and choose “Prin�ng preferences”, figure (1). 2. Click “Paper Name”, choose the paper type as needed, figure (2). ● Click “Manager” to add a new stock, figure (3)(4). ●...
  • Page 8 3. Click “Advanced” to set “Save Paper”, “Density”, “Speed”, “Test”, “Media Handling”, “Media Type”. 1) Save Paper 2) Density 3) Speed 4) Test 5) Media Handling 6) Media type...
  • Page 9 5. Click “Hal�one”. Printer Proper�es 1. Click “Start” → “Devices and Printers”. Right click the icon and choose “Printer proper�es”, figure (A). 2. Click “General” → “Print Test Page”, and printer will print labels with current se�ngs, figure (B). SK41...
  • Page 10 3. Click “Ports”, then choose the port needed, figure (C). 4. Click “Advanced” to set the available �me for the printer, figure (D). SK41 SK41 SK41 Driver Removing Note: Please turn off the printer or unplug the USB cable before removing the driver.
  • Page 11 Mac Driver Instruc�on Driver Prepara�on for macOS Download Mac Driver applica�on program in h�p://www.hprt.group. Driver Installa�on for macOS Warning: Under different opera�ng system, the screen has slight difference. Please operate it according to the �ps. 1. Double click the Driver and click “Con�nue”, figure (a).
  • Page 12 6. Turn on the printer and connect it to your computer (for example: via USB cable) 7. Click: Launchpad -> System Preferences -> Printers & Scanners, figure (g). 8. Under “Printer & Scanner”, printer SK41 is available, figure (h). SK41 -12-...
  • Page 13: Troubleshoo�Ng

    Troubleshoo�ng LED Display ● Blue Always on The printer is ready ● Purple Always on The print head is over heat Always on The cover is not closed ● Flash slowly Paper out Flash rapidly Label learning is abnormal Always on The printer is not ready yet ●...
  • Page 14: Print Problem

    Print Problem Problem Cause Solu�on 1. Common Error speed se�ng. Set minimum prin�ng speed by control panel, quality problem drivers and so�ware to a�ain best prin�ng of print. quality. Incorrect margins and Make sure the label size is correct before prin�ng. paper size.
  • Page 15 Problem Cause Solu�on 4. Misalignment / The printer is Calibrate the printer . skip label. uncalibrated. Method 1: Tools --- "Automa�c label learning". Method 2: Press and hold the feed bu�on (top bu�on) un�l the blue light goes out twice and then release. The tag format is incorrect Check your label format and correct it as needed.
  • Page 16 Problem Cause Solu�on 8. The bar code The prin�ng is too dark or Adjust the concentra�on or print speed too light, the barcode does printed on the label properly. not meet the specifica�ons. can not be scanned. Leave at least 3.2 mm (1/8 inch) between There is not enough blank the barcode on the label and other printed space around the barcode.
  • Page 17 FCC WARNING This device complies with part 15 of the FCC Rules. Opera�on is subject to the following two condi�ons: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interfer ence that may cause undesired opera�on. Any changes or modifica�ons not expressly approved by the party responsi- ble for compliance could void the user's authority to operate the equipment.
  • Page 18 Web(SK41): h�p://www.hprt.group Web(HPRT): www.hprt.com Xiamen Hanin Electronic Technology Co., Ltd. Add: 4F, 10#, Aide Airport Industrial Park, Huli District, Xiamen, China Customer Service Email: sk@hprt.com Web(HPRT): www.hprt.com Web(SK41): h�p://www.hprt.group...
