Bottom view
EN
1
Cliff sensors
2
Front caster wheel
3
Charging contacts
4
Floor type sensor
5
Nozzle
6
Bin release button
7
Brush frame release tab
8
Floor tracking sensor
9
Debris evacuation port
10
Refill port
10
For more information, visit global.irobot.com
6
11
Brush caps
12
Multi-surface brushes
