- Page 1 OPERATION & MAINTENANCE MANUAL HVES PUMPS PATTERSON PUMP COMPANY A GORMAN-RUPP COMPANY PO Box 790 2129 Ayersville Road Toccoa, Georgia 30577 USA Telephone: 706-886-2101 Revision 05-2019...
- Page 2 SAFETY TERMINOLOGY AND SYMBOLS This symbol indicates electrical safety instructions where noncompliance will involve a high risk to personal safety or the loss of life. This symbol indicates safety instructions where noncompliance would affect personal safety and could result in loss of life. This symbol indicates safety instructions where noncompliance will involve some risk to safe operation and personal safety and/ or would damage the equipment or property.
- Page 3 SAFETY PRECAUTIONS WARNING Do not operate this equipment in excess of its rated speed or other than in accordance with the instructions contained in this manual. The equipment has been found satisfactory for the conditions for which it was sold, but its operation in excess of these conditions may subject it to stresses and strains which it was not designed to withstand.
-
Page 4: Table Of Contents
TABLE OF CONTENTS SECTION 1 General Information ................ 1 SECTION 2 Storage & Protection ..............1 SECTION 3 Installation 3-1 Location ................2 3-2 Mounting ................. 2 3-3 Alignment ............... 2 3-4 Wiring and Controls ............3 SECTION 4 Operation 4-1 Starting ................ -
Page 5: General Information
SECTION 1 GENERAL INFORMATION This manual covers the installation, operation and maintenance of Patterson Pump HVES pumps. The pump is a centrifugal, single stage; single suction type furnished with mechanical seals. When properly installed and when given reasonable care and maintenance, centrifugal pumps should operate satisfactorily for a long period of time. -
Page 6: Location
instruction manuals for other precautions concerning storage of individual components of pumping unit. Fresh lubricant should be applied to bearings upon removal of equipment from storage. SECTION 3 INSTALLATION Location: Several factors should be considered when selecting a location for the pumping unit (pump and drive). -
Page 7: Wiring And Controls
To check coupling alignment, the following procedure should be followed: Set the coupling gap to the dimension shown on the coupling data sheet. Check for parallel misalignment by placing a straight edge across both coupling halves at four points 90° apart. Correct alignment occurs when the straight edge is level across the coupling halves at all points. -
Page 8: Operation
The motor ratings stamped on the motor nameplate must match the line voltage and wire capacity. DO NOT USE ANY OTHER VOLTAGE. SECTION 4 OPERATION Do not exceed the rated working pressure of the pump. The sum of the suction pressure and the maximum pump operating head (converted to units of pressure) must be less than the pump working pressure, at all times. -
Page 9: Shutdown
vacuum pump or ejector operated by air, steam, water, etc. to evacuate air from the pump case and suction line by connecting the ejector to the priming connection on top of the pump case. Check direction of rotation before starting pump. Rotation should be the same as the direction arrow on the case. - Page 10 Mechanical seals should be replaced if they are leaking. Refer to the motor manufacturer’s instructions for periodic maintenance requirements. Check that electrical control equipment contacts are in good condition and clean. Bearing relubrication requirements – refer to the table “Pump Bearing Relubrication Requirements”.
-
Page 11: Repairs & Replacement
General Pump Inspection and Maintenance Schedule HVES Pumps Excludes drivers, VFD’s, and controls. Contact Patterson Pump Company if assistance is needed to determine the inspection and service requirements for a specific pump. 2000 4000 8000 Inspect () or service () at the indicated hours hours hours... -
Page 12: To Remove Rotor
To Remove Rotor and Bearing Housing: Reference: Pump Assembly Section Remove coupling guard and disconnect coupling halves. Remove bolts holding the motor to base or floor, then remove the motor. Remove bolts from bearing housing support (99A) to base, bolts holding the volute cover (11) to the casing (1). -
Page 13: Inspection
Clean all metal parts with a solvent. Use a bristle brush (not metal or wire) to remove tightly adhering deposits. A fiber scraper may be used to remove the gasket and shellac from casing flange. Blow dry with clean dry compressed air. Never use hydrocarbon liquids (oil or solvent) to clean mechanical seal parts. -
Page 14: Locating Operation Difficulties
30601, USA, Phone: 706-353-7780, Fax: 706-546-1427) prior to assembly. Lubricate the O.D. of the shaft sleeve (14) and the I.D. of the opposite half of the mechanical seal using Dow Corning Molykote 111 Compound or equivalent. Press the shaft sleeve (14) through the seal. Coat the interior of the shaft sleeve (14) with Dow Corning 732 Multi- Purpose Sealant or equivalent. - Page 15 Abnormally Small Quantities Delivered Air leaks in suction pipe or stuffing boxes. Speed too low. Discharge head higher than anticipated. Impeller partially plugged up. Obstruction in suction line. Mechanical defects: Impeller damaged; casing or seal defective. Insufficient Pressure ...
- Page 16 Rubbing due to foreign matter in the pump between the case ring and the impeller. Pump Vibrates Misalignment. Foundation not sufficiently rigid. Impeller partially clogged. Mechanical defects: bent shaft, rotating element binds, bearings worn, coupling defective.
-
Page 17: Recommended Spare Parts
RECOMMENDED SPARE PARTS FOR HVES PUMPS Reference: Assembly Section INTERMITTENT DUTY Number Description Casing Ring Shaft Sleeve Mechanical Seal O-Ring (casing) Coupling and its accessories (not shown) CONTINUOUS DUTY Number Description Impeller Shaft Casing Ring Shaft Sleeve Bearing (inboard) Bearing (outboard) Outer Retaining Ring Inner Retaining Ring Impeller Screw... -
Page 18: Typical Assembly Section
PET COCK VENTI NG 73A 73 Typical Assembly Section, Type HVES ITEM DESCRIPTION ITEM DESCRIPTION MATERIAL MATERIAL CASING Cast Iron - ASTM MB-CL30 IMPELLER KEY Stainless Steel - ASTM Type 304 IMPELLER Bronze - ASTM B584-B75 BEARING COVER Cast Iron - ASTM M8-CL30 SHAFT DEFLECTOR Nitrile... -
Page 19: Notes
Notes...
