Viking Range 5 Series Installation Manual
Built-in electric/induction cooktops
Hide thumbs
Also See for 5 Series:
- Installation, use & care manual (40 pages) ,
- Use & installation manual (12 pages) ,
- Manual (57 pages)
Subscribe to Our Youtube Channel
Related Manuals for Viking Range 5 Series
Summary of Contents for Viking Range 5 Series
- Page 1 Installation GUIDE ® 5 SERIES Built-In Electric Cooktops Built-In Induction Cooktops VECU530(1) / VECU536(1) VICU530(1) / VICU536(1)
-
Page 2: Table Of Contents
Table of Contents Warnings & Important Safety Instructions _____________________________ 3 Specifi cations /Dimensions (Electric Cooktops) _________________________ 4 Specifi cations /Dimensions (Induction Cooktops) _______________________ 6 Cutout Dimensions________________________________________________ 8 Clearance Dimensions _____________________________________________ 9 Electrical Requirements ___________________________________________ 11 General Information ______________________________________________ 12 Installation _____________________________________________________ 12 Final Preparation ________________________________________________ 13 Performance Checklist ____________________________________________ 13 Service &... -
Page 3: Warnings & Important Safety Instructions
IMPORTANT – Please Read and Follow! • DO NOT remove permanently affi xed labels, warnings, or plates from product. This may void the warranty. • Please observe all local and national codes and ordinances. Installation must conform with local codes and National Fuel Gas Code ANSIZ233.1/NFPA-54–latest edition. -
Page 4: Specifi Cations /Dimensions (Electric Cooktops)
Specifi cations (VECU Electric Cooktops) VECU Electric Cooktop Description 30” W. - 76 cm Wide 36” W. - 91 cm Wide Overall width 30-3/4” (78.1 cm) 36-3/4” (93.3 cm) Overall height from bottom To top of knobs 4-1/2” (11.4 cm) To top of cooking surface 3-1/2”... - Page 5 Dimensions (VECU Electric Cooktops) 30” W. (76 cm) Cooktop 36” W. (91 cm) Cooktop - 3 / ( 7 8 4 ” . 1 c ” . 4 c ( 5 3 - 3 / ( 9 3 4 ” .
-
Page 6: Specifi Cations /Dimensions (Induction Cooktops)
Specifi cations (VICU Induction Cooktops) VICU Induction Cooktop Description 30” W. - 76 cm Wide 36” W. - 91 cm Wide Overall width 30-3/4” (78.1 cm) 36-3/4” (93.3 cm) Overall height from bottom To top of knobs 4-1/16” (10.3 cm) To top of cooking surface 3”... - Page 7 Dimensions (VICU Induction Cooktops) 30” W. (76 cm) Cooktop 36” W. (91 cm) Cooktop - 3 / ( 7 8 4 ” . 1 c ” . 4 c ( 5 3 - 3 / ( 9 3 4 ” .
-
Page 8: Cutout Dimensions
Cutout Dimensions Electric 30”W. MODELS 36”W. MODELS 28-7/8” (73.3 cm) min. to 34-7/8” (88.6 cm) min. to 29-1/8” (74.0 cm) max. 35-1/8” (89.2 cm) max. 19-1/4” (48.9 cm) min. to 19-3/4” (50.2 cm) max. Induction 30”W. MODELS 36”W. MODELS 28-1/2” (72.4 cm) min. to (87.6 cm) min. -
Page 9: Clearance Dimensions
Clearance Dimensions PROXIMITY TO SIDE CABINET Minimum Clearances from Adjacent INSTALLATION Combustible Construction • The cooktop may be installed directly to • Above countertop 36” (91.4 cm) minimum existing base cabinets. • Side 6” (15.2 cm) • The cooktop CANNOT be installed •... - Page 10 Clearance Dimensions INTERIOR CABINET CLEARANCES INDUCTION COOKTOPS IMPORTANT: The electronic components for the induction elements in the cooktop need air circulation. To ensure long life of electronic components, it is required that 1-1/2 (3.8 cm) or more open space remains between the bottom of the cooktop and any shelf underneath.
-
Page 11: Electrical Requirements
Electrical Requirements WARNING WARNING BURN HAZARD The electrical power to the unit must be shut off while line The use of cabinets for storage connections are being made. above the appliance may result Failure to do so could result in serious injury in potential burn hazard. -
Page 12: General Information
General Information READ AND FOLLOW ALL WARNING AND CAUTION INFORMATION WHEN INSTALLING • When removing the cooktop for service THIS APPLIANCE. and/or cleaning, disconnect the electrical supply from the breaker box • Keep appliance area clear and free from • Electrical requirements are listed in the combustible materials, gasoline and other product specifi cations under the “Electrical fl ammable vapors. -
Page 13: Final Preparation
Final Preparation • Some stainless steel parts may have plastic • If it is necessary to scrape stainless steel to protective wrap which must be peeled off . remove encrusted materials, soak with hot, • All stainless steel body parts should be wet cloths to loosen the material, then use wiped with hot, soapy water and with a a wood or nylon scraper. -
Page 14: Service & Registration
DO NOT repair or replace any part of the appliance unless specifi cally recommended in the manual. All other servicing should be referred to a qualifi ed technician. Contact Viking Range, LLC, 1-888-(845-4641), for the nearest service parts distributor in your area or write to: VIKING RANGE, LLC... - Page 16 Viking Range, LLC 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information, call 1-888-(845-4641) or visit our web site at vikingrange.com F21271J EN (041523)
