- Page 1 型号 设计师 杨雪娇 编码 21-b 说明书 设计主管 零件名称 计君竹 尺寸要求 审核 113*63mm 重量要求 日期 20240724 V1.0 材质： 105g双粉纸（哑粉）（封面过防刮花哑胶）内页70g书纸 尺寸：113*63mm 装订：骑马钉 页码：40p 骑马钉...
- Page 3 INT-21-B Wireless BBQ Thermometer User Manual...
- Page 4 Please keep this manual properly for reference. You can also scan the QR code below to visit our official website for product usage videos. For any usage issues, please feel free to contact us at support@inkbird.com.
- Page 5 Wenn Sie eine Bedienungsanleitung in deutscher Sprache benötigen, scannen Sie bitte den QR-Code und besuchen Sie unsere Website, um sie zu erhalten und ein Video über die Verwendung des Produkts zu sehen. Se avete bisogno di un manuale di istruzioni in italiano, scansionate il codice QR e visitate il nostro sito web per ottenerlo e vedere un video su come utilizzare il prodotto.
- Page 6 Usage Precautions 1.Charging Case Introduction The base features the function of Bluetooth signal repeater and it should be placed as close to the probe as possible, preferably within 100 meters and with no metal objects or ≤100m/328ft ≤100m/328ft obstacles in between. Do not place the base on a running oven, stove, or any other hot surface.
- Page 7 2.Probe Introduction The probe can measure both food and ambient temperatures simultaneously. A safe cooking line is engraved on the probe body and during cooking the probe should be inserted into the meat until the safe line is exceeded, keeping the probe tip unexposed as this will damage the probe.
-
Page 8: Table Of Contents
APP Installation & Connection ········································································ Overview Cleaning and Maintenance ········································································ ········································································ Technical Specifications Important Notes/Warnings ········································································ ········································································ Product Description Troubleshooting Guide ········································································ ········································································ Operation Button Definitions FCC Requirement ········································································ ········································································ Battery Details & Maintenance IC Warning ········································································ ········································································ Operation Instructions Customer Service ········································································... -
Page 9: Overview
Overview INKBIRD INT-21-B is a smart wireless needle meat thermometer, supporting a stable and efficient wireless connection through Bluetooth 5.4, freeing you from worries about signal problems during cooking. The unit is equipped with a clear LCD screen, which displays food internal temperature and ambient temperature in real time, making cooking process visible at a glance. -
Page 10: Technical Specifications
Technical Specifications Brand INKBIRD Model Number INT-21-B Bluetooth Version BLE 5.4 Bluetooth Connection Distance 656ft/200m（the longest distance in an open area） Screen Type High definition LCD Probe Waterproof Rating IP67（dishwasher safe） Probe Size φ5mm... - Page 11 Probe Sensor Quantity 2 sensors Probe Measurement Range Food temperature：-10~100℃/14~212℉ (short-time measuring) Ambient temperature：0~300℃ /32~572℉ Probe Measurement Accuracy ±1℃/±1.8℉ Temperature Refresh Time ＜3s Battery Life 120 hours Powered By AAA Batteries*2 Weight 132g Probe*1 Base*1 Package Contents AAA Batteries*2 User Manual*1...
-
Page 12: Product Description
Product Description Product Appearance Take out HD LCD Indicator Light Power Button Base... - Page 13 Product Appearance Battery Cover Battery Compartment...
- Page 14 Probe Food-grade Stainless Steel Safe Cooking Line Ceramic Handle Charging Contact Point...
- Page 15 On-Screen and Indicator Light Informatio Reference Table Screen Display Information Base battery level. The base′s battery power is low,please replace the flashing batteries immediately. Bluetooth is pairing. flashing...
- Page 16 Bluetooth connected. Bluetooth disconnected. Disappear Always on The probe is connected to The probe is paring with the the base. base. flashing Always on The probe is disconnected The current temperature from the base. unit displayed. Disappear Food temperature. Probe battery level. The probe′s battery power The probe is charging.
- Page 17 Target temperature. Ambient temperature. It detects that the food temperature is higher than It detects that the food 95℃ and the ambient temperature is lower than flashing flashing temperature is higher than -10℃ and triggers the alarm. 300℃ and triggers the alarm. Indicator Light When the probe triggers During pairing, it flashes...
-
Page 18: Operation Button Definitions
Operation Button Definitions Power ON/OFF: Press and hold for 3 seconds to power on. Press and hold the button for 3 seconds until you hear a beep, and then release the button to switch the device off. Alarm: When the device sounds an alarm, press the button once to stop the alarm. - Page 19 NOTE: 1.When device is sounding any alarm, press the button on the base to cancel it. If a high-temperature alarm is triggered, please immediately stop heating, move the unit to a cool, shaded place and switch it off. Alternatively, if the unit detects that the temperature has dropped to a safe level, it will automatically stop the alarm.
-
Page 20: Battery Details & Maintenance
Battery Details & Maintenance Battery Installation 1.Open the battery cover. 2.Pay attention to the polarity of the batteries and insert the two new AAA alkaline batteries in the correct way. 3.Cover the battery compartment and press and hold the button for 3 seconds to turn on the device. The screen will light up. - Page 21 Battery Details 1.The base of the INKBIRD INT-21-B requires two 1200mah AAA alkaline batteries and acts as a probe charger, fully charging the probe in approximately 30 minute. 2.A fully charged probe can be used continuously for 20 hours. There is no need to worry that the battery will not last for the cooking time you need on any cooking occasion.(Consistently high temperatures can reduce battery life.)
- Page 22 Precautions For Use 1.Please do not place the product on any hot surface such as hot stoves, ovens, and smokers, as this may cause damage to the product or even personal injury. 2.Please do not clean this product base with running water or place it in a dishwasher or water sink to avoid battery damage.
-
Page 23: Operation Instructions
2.Prepare a smartphone running iOS 12 (or later) or Android 7.1 (or later) to download the INKBIRD app and complete the connection (referring to the section 7 App Installa- tion & Connection). -
Page 24: App Installation & Connection
APP Installation & Connection 7.1 INKBIRD APP Search the INKBIRD App from Google Play or App Store to get it for free, or you can scan the QR code to download it directly. - Page 25 7.2 Registration Step1: Registering an account is necessary before using the INKBIRD app for the first time. Step2: Open the app, select your Country/Region, and a verification code will be sent to you.
-
Page 26: Cleaning And Maintenance
7.3 How To Connect Open the INKBIRD app and click ″+″ on the top right corner to add a device. Then, follow the app instructions to complete the connection. Ensure that the device is placed as close as possible to the smartphone during the connection process. -
Page 27: Important Notes/Warnings
3.If you are not going to use this product for an extended period of time, please remove the batteries and cover the battery compartment. 4.This product base is not waterproof. Use a slightly damp cloth to clean it when necessary and prevent water from seeping into it and causing damage. Important Notes/Warnings 1.Do not use the probe in a microwave oven or pressure cooker. - Page 28 4.Please do not use the probe in cooking environments above 300℃ (572°F) or below 0℃ (32°F), not expose it directly to flame or burning wood charcoal, as this may damage the probe battery. 5.During or at the end of cooking, please do not touch the overheated probe with bare hands.
-
Page 29: Troubleshooting Guide
Troubleshooting Guide Possible Solutions Issues 1.Make sure that your smartphone or tablet is running iOS12 / Android 7.1 or later. 2.Make sure that you have Bluetooth enabled on your smartphone or Cannot tablet and that the thermometer′s battery has sufficient power. Connect Bluetooth? 3.Make sure that the positioning function is enabled on your... - Page 30 Bluetooth function is disabled on those Connect smartphones. Bluetooth? 6.Restart the thermometer, open the INKBIRD app, and repeat the connection steps. 7.Turn off any other Bluetooth devices or disable their Bluetooth functions within the connection range.If the issue persists after the...
- Page 31 Issues Possible Solutions 1.Correctly install two new AAA alkaline batteries according to the battery polarity（Do not use rechargeable batteries.） 2.Check for battery leakage or rusty battery connectors. 3.Check for water seepage or humid surfaces on the batteries or Cannot battery compartment. Remove the batteries and uncover the battery Charge The Base? compartment.
- Page 32 Issues Possible Solutions Why Is 2.Check if the current temperature exceeds or has once exceeded the The Probe probe measurement range, which caused damage. Reading 3.Do not immerse the probe in water for a long time. Incorrect? 1.Ensure that the charging contact point on the top of the probe is in contact with the charging plate on the base and place the probe correctly (refer to the Product Appearance section of this manual).
-
Page 33: Fcc Requirement
FCC Requirement Changes or modifications not expressly approved by the party responsible for compli- ance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)this device may not cause harmful interference, and. - Page 34 installed and used in accordance with the instructions, may cause harmful interfer- ence to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interfer- ence to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: –...
-
Page 35: Ic Warning
uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. IC Warning This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject ... -
Page 36: Customer Service
During this period, products that prove to be defective will, at the discretion of INKBIRD, be either repaired or replaced without charge. For any problems in use, please feel free to contact us at support@inkbird.com. We will do our best to help you. - Page 37 Shenzhen Inkbird Technology Co.,Ltd. support@inkbird.com Consignor: Shenzhen Inkbird Technology Co., Ltd. Office Address: Room 1803, Guowei Building, No.68 Guowei Road, Xianhu Community, Liantang, Luohu District, Shenzhen, China Manufacturer: Shenzhen Inkbird Technology Co., Ltd. Factory Address: 6th Floor, Building 713, Pengji Liantang Industrial Area, No.2 Pengxing Road, Luohu District, Shenzhen, China V1.0...
