Summary of Contents for Inkbird IBS-P02R
- Page 1 IBS-P02R Wireless Pool Thermometer and Receiver Set User Manual Product Introduction Features & Specifications Operation Instruction Safeguards Product Warranty FCC Requirement...
-
Page 2: Product Introduction
1. Product Introduction Temperature and Humidity Monitor (Receiver) Pool Thermometer Battery Level Current Channel Action Buttons Number Battery Level of Indoor Monitor Current Indoor Temperature Current Detected Temperature Current Indoor Humidity Pool Thermometer (Transmitter) Battery Level Current Detected Temperature Pool Thermometer - 1 -... -
Page 3: Features And Specifications
2. Features & Specifications Battery: 4*AAA 1.5V (not included) Transmission Distance: up to 300 ft in open space, if there is interference, the transmission distance will be limited. Temperature and Humidity Monitor (Receiver) Temperature measurement range: -10℃~60℃ (14℉~140℉) Temperature measurement accuracy: ±1.0℃ (±1.8℉) Temperature display accuracy: 0.1℃... - Page 4 Temperature and Humidity Monitor (Receiver) ℉/℃ Button MAX/MIN Button CH/R Button CH/R Button: Press it to switch between the channels (CH1, CH2, CH3, CH8), the screen will display the measured temperature of the chosen channel (CH1, CH2, CH3). If CH8 is selected, the measured temperature of CH1, CH2, and CH3 will be displayed alternately for 3 seconds.
- Page 5 Unscrew the cover of the pool thermometer, as shown below. The green part is a waterproof gasket, which should not be removed at any time! TX/CF Button TX/CF Button: Press it to transmit the detected temperature from the pool thermometer to the temperature and humidity monitor and light up the indicator once.
- Page 6 3.3 Battery Installation of Pool Thermometer (Transmitter) Unscrew the lid of the pool thermometer as shown below. - 5 -...
- Page 7 Remove the battery cover, install 2 AAA batteries, put the cover back. - 6 -...
-
Page 8: Product Warranty
5. Product Warranty This item carries a 1-year warranty against defects in either components or workmanship. During this period, products that prove to be defective will, at the discretion of INKBIRD, be either repaired or replaced without charge. - 7 -... -
Page 9: Fcc Requirement
6. FCC Requirement Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 10 Factory address: 6th Floor, Building 713, Pengji Liantang Industrial Area, NO.2 Pengxing Road, Luohu Disctrict, Shenzhen, China Office address: Room 1803, Guowei Building, NO.68 Guowei Road, Xianhu Community, Liantang, Luohu District, Shenzhen, China MADE IN CHINA DESIGNED BY INKBIRD V1.0...
