Getting started
Quick reference guide

Base lights

SPEAKER
On when speakerphone
is in use.
MUTE
On when
speakerphone or
handset microphone is
muted.

Screen icons

12:00
AM
ERR
LOWER
NEW
REP
00
No:
1 CALLS 1 NEW

Display screen messages

Displays
STORED
DELETED
END OF LIST
DIRECTORY EMPTY
NO NAME FOUND
NO NUMBER
LINE IN USE
LINE RINGING
LINE ON HOLD
MEMORY FULL
ONLY 24 ALLOWED
ONLY 15 ALLOWED
CHECK BATTERY
E R R
1-01
NEW
REP
LOWER
NO:
Means
The telephone number displayed is stored.
•
All entries stored in the call history have been deleted.
•
The last number dialed has been deleted.
You have reached the end of the call history records.
There are no telephone numbers stored in the directory.
There are no names matching the letter combination you have selected.
There is no entry stored in the speed dial location you have selected.
The connected telephone line cord is not plugged into a wall jack or
another telephone on the same line is in use.
There is an incoming call.
The line is on hold.
The directory is full.
The number you have entered in the directory or speed dial memory is
over 24 digits.
The name you have entered in the directory is over 15 characters.
There are no batteries installed or you need to replace the old batteries.
CALL INFO
•
On when the line is in use.
•
Flashes slowly when a call is on hold.
-OR-
When the connected telephone line cord is
not plugged into a wall jack.
-OR-
When the telephone on the same line is in use.
•
Flashes quickly when there is an incoming call.
There is an error in the caller ID information.
Line is in use or the connected telephone line cord is
not plugged into a wall jack.
The caller ID information has not been reviewed.
A person from this number has called more than once.
The lower speed dial location is active.
The position of the number stored in call history.
The battery power is low.
The ringer volume is set to OFF.
3
