- Page 1 Installation Manual BUILT-IN REFRIGERATION 60" RBIV MODELS www.zlinekitchen.com...
- Page 2 ZLINE Kitchen and Bath provides Attainable Luxury, where the kitchen and bath of your dreams is never out of reach. Through our unique designs and unparalleled quality, we’re dedicated to providing you an elevated experience in the heart of your home. With an endless selection of...
- Page 3 ZLINE is fueled by a passion for innovation; A relentless pursuit of bringing the highest end luxury designs and professional features into everyone’s homes. Because we continually strive to improve our products, we may change specifications and designs without prior notice.
- Page 4 TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ..... 1 BEFORE INSTALLATION ....... . . 6 INSTALLATION .
-
Page 5: Important Safety Instructions
PLEASE READ THIS MANUAL BEFORE INSTALLING AND USING THE PRODUCT • Please note that the installation process for your dual built-in refrigerator requires combining two RBIV-30 model refrigerators to create one RBIV-60 unit. • Always follow allow applicable safety instructions in this manual as well as the manuals for ZLINE's built-in refrigeration models (RBIV-30 and RBIV-36). - Page 6 The Installation and User Manuals for WARNING ZLINE's built-in refrigeration models (RBIV-30 and RBIV-36) must also be taken into consideration, as they contain important information about operation and safety. You may get seriously injured and your products damaged if you ignore the warnings given in these manuals.
- Page 7 IMPORTANT SAFETY INSTRUCTIONS INSTALLATION ENCLOSURE REQUIREMENTS • The floor on which the dual refrigerator will be installed must be capable of bearing a minimum of 2,400 lb (1,089 kg). • The kitchen floor and bottom of the product must be level. Otherwise, air flow for the unit's cooling system may be impeded or reduced.
- Page 8 For the best installation, clearances between cabinets and the product must be in compliance with the values specified in this manual and in the Installation Manual for ZLINE's built-in refrigeration models (RBIV-30 and RBIV-36). Side walls must be free of any obstructions and their surfaces must be flat.
- Page 9 IMPORTANT SAFETY INSTRUCTIONS The installation process for your dual built-in refrigerator requires combining two RBIV-30 model refrigerators to create one RBIV-60 unit. Scan the QR code to access the Installation Manual for ZLINE's built-in refrigeration models (RBIV-30 and RBIV-36). ELECTRICAL CONNECTION •...
-
Page 10: Before Installation
BEFORE INSTALLATION CABINET DIMENSIONS • Much like ZLINE's RBIV-30 and RBIV-36 built-in refrigerators, the RBIV-60 model is a panel-ready appliance designed to be a permanent fixture in your custom kitchen; therefore, precise cabinet cutouts and superior attention to detail are required for seamless integration. - Page 11 BEFORE INSTALLATION RBIV-60 ELECTRICAL AND WATER REQUIREMENTS • Each RBIV-30 appliance is provided with a NEMA 5-15P plug and a 3-pin power cable designed to be connected to a 120VAC, 60Hz power receptacle. • Therefore, we recommend both RBIV-30 units be plugged into independent circuits.
- Page 12 BEFORE INSTALLATION WATER SYSTEM LOCATION • The water connected to the dual refrigeration unit must be potable. • Location of the water system must be within the range outlined in the graphic at the bottom of this page. • The unit's water system must be connected to the main water system in the house. The user must be able to switch the water system on/off with a valve when necessary.
- Page 13 BEFORE INSTALLATION !"#$%&'()#$$#)&*'%+*,-*'.')( DUAL INSTALLATION COMPONENTS Divider Trim Plastic Upper Bracket Adhesive Foam Divider Metal Lower Bracket "...
-
Page 14: Installation
INSTALLATION PARTS PROVIDED PART IMAGE DESCRIPTION 1/8" x 15 3/4" x 68 7/8" 1. Adhesive Foam Divider (3 mm x 400 mm x 1749 mm) 1/8" x 2" x 4 1/2" 2. Plastic Mounting Bracket (3 mm x 51 mm x 1 14 mm) 1/16"... - Page 15 INSTALLATION MOUNT UPPER BRACKETS AND LOWER BACK BRACKET TO CONNECT THE REFRIGERATORS 1. On the back of one unit near the top, find the location for one plastic mounting bracket (Item No. 2) and fasten into place with two screws (Item No. 4), ensuring the small arm is pointed in.
- Page 16 INSTALLATION CONNECT UPPER BRACKETS TO CONNECT THE REFRIGERATORS 1. Realign both refrigerators so they are flush and line up with the opening where they 1'2'() "--./%0/#+1.)(%)*%+*''.+)%)4.%/.5/&6./#)*/( will be installed. 2. Finish installing the plastic mounting bracket on the back with the other two screws A 4)?"E7'C37':(7)3H)?E3)&'()7#?D37GI7#?D3, to connect both units.
- Page 17 RBIV-30 parts kit before you can push the dual unit into place. • Three cabinet mounting brackets go on the outer left and right sides of the dual RBIV-60 unit, while four total brackets go on top of the dual unit — two on each RBIV-30.
- Page 18 Width of cabinet cutout: 60" (1524 mm) Width of dual unit: 59 5/8" (1514 mm) 1/8" (3 mm) RBIV-30 refrigerators are top-heavy and weigh 342 lb (155 kg). The dual unit weighs close to 700 lb (318 kg). Take care when installing the WARNING...
- Page 19 A/D — Turn the key clockwise to lift the front B/C — Turn the key clockwise to lift the rear • After adjusting the feet, check if both RBIV-30 units are level in both width and depth directions. You may readjust as needed after panels are installed.
- Page 20 • Using the remaining cabinet mounting bracket screws provided with your RBIV-30 parts kit, secure the right unit to the cabinet — 4 screws on top and 6 on each side.
- Page 21 • Attach the side trim pieces provided with the RBIV-30 parts kit onto the outer sides of each unit, covering the cabinet mounting brackets as shown below. • Attach the top trim pieces provided with the RBIV-30 parts kit onto the tops of both units, covering the cabinet mounting brackets as shown below.
- Page 22 INSTALLATION INSTALL DIVIDER TRIM • After ensuring both units are flush and everything is level, insert the center divider 1'2'()*% .')./%)/&,%0.)3..'%/.5/&6./#)*/( trim (Item No. 5 in the dual unit parts list) between both units and lightly pound into place with the back of your fist. A BH'3)79&6?"E7#$)37'C&'7'C3I7&)37?"7&%?E"93"'7?"#3)'753"'3)7')?97G3':33"7)3H)?E3)&'(),...
- Page 23 INSTALLATION 7*,-$.)&*'%&'()#$$#)&*' INSTALLATION COMPLETE • IMPORTANT: Refer to your RBIV-30 Installation Manual as needed for other A >(98%3'37?"#'&%%&'?("75("H3)7'(78)3@?($#78&E3#7)3E&)D?"E7('C3)7?"#'&%% installation procedures. Scan the QR code to view the most up-to-date version of our RBIV-30 / RBIV-36 Installation Manual and User Manual.
-
Page 24: Warranty
WARRANTY COVERAGE ZLINE Kitchen and Bath ("ZLINE") built-in refrigerators have a two year parts and service warranty and a five year parts warranty on the unit's sealed cooling system. ZLINE warranty periods begin from the original purchase date of the product and solely cover the original purchaser of the product, delivered new and in its original carton. - Page 25 If a product qualifies within the service window provided under these warranty terms, and ZLINE is unable to repair the product or a defective part of the product after a reasonable number of attempts, ZLINE reserves the right to offer to replace the defective part or the...
- Page 26 Always check the ZLINE website for the most up-to-date version of its product manuals: www.zlinekitchen.com/pages/manuals. Do not install or operate any ZLINE product if it has missing or broken parts or if it arrives damaged due to shipping. If ZLINE products arrive damaged, contact ZLINE Customer Experience at 1-614-777-5004 for help.
- Page 27 Always check the ZLINE website for the most up-to-date version of its product manuals: www.zlinekitchen.com/pages/manuals. Do not install or operate any ZLINE product if it has missing or broken parts or if it arrives damaged due to shipping. If ZLINE products arrive damaged, contact ZLINE Customer Experience at 1-614-777-5004 for help.
- Page 28 1.3.1 1-614-777-5004 www.zlinekitchen.com contact@zlinekitchen.com...
