- Page 1 User Manual REFRIGERATION www.zlinekitchen.com...
- Page 2 ZLINE Kitchen and Bath provides Attainable Luxury, where the kitchen and bath of your dreams is never out of reach. Through our unique designs and unparalleled quality, we’re dedicated to providing you an elevated experience in the heart of your home. With an endless selection of...
- Page 3 ZLINE is fueled by a passion for innovation; A relentless pursuit of bringing the highest end luxury designs and professional features into everyone’s homes. Because we continually strive to improve our products, we may change specifications and designs without prior notice.
-
Page 4: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS OPERATION MAINTENANCE AND CLEANING TROUBLESHOOTING WARRANTY... -
Page 5: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS This manual contains important safety information. Failure to follow these instructions may result in death, fire, or electric shock. WARNING: Indicates a potentially hazardous situation which, if not avoided, could WARNING result in death or serious injury. CAUTION: Indicates a potentially hazardous situation which, if not avoided, may CAUTION... - Page 6 IMPORTANT SAFETY INSTRUCTIONS • WARNING: Do not use mechanical devices or other means to accelerate the defrosting process in this unit, other than those recommended by the manufacturer. • WARNING: Do not damage the unit's refrigerant circuit and sealed cooling system. •...
- Page 7 IMPORTANT SAFETY INSTRUCTIONS • To avoid food contamination, please read the following instructions and information: • Opening the door for long periods of time can cause a significant increase in the temperatures inside the appliance. • Users should regularly clean surfaces and accessible drainage systems that come in contact with food •...
- Page 8 IMPORTANT SAFETY INSTRUCTIONS PLACEMENT OF ITEMS • Do not put flammable, explosive, volatile, or highly corrosive items in the refrigerator or freezer to prevent damage to the product and limit risk of fire or explosion. • Do not place flammable items near the refrigerator to limit risk of fire or explosion. •...
- Page 9 IMPORTANT SAFETY INSTRUCTIONS WARNINGS FOR DISPOSAL Both the refrigerant (R600a isobutane) and cyclopentane foaming material used for this appliance are flammable. Therefore, when the appliance reaches the end of its service life, it should be kept away from any fire source and be disposed of according to local regulations so as to prevent damage to the environment or other harm.
-
Page 10: Operation
3.1 Key components OPERATION Re frige rat ing c ha m b e r LED lighting LED lig hting Anti-condensation heating strip Filte r Filter Ic e m a ke r Ice maker Doo r tra y Door tray Doo r tra y She lf Door tray Shelf... - Page 11 OPERATION REFRIGERATING CHAMBER • The refrigerating chamber is suitable for storage of a variety of fruits, vegetables, beverages, and other food consumed in the short term. • Cooking ingredients should not be placed inside the refrigerating chamber until cooled to room temperature. •...
- Page 12 OPERATION 3.2 Functions BUTTONS WAKE REF-ICE °F/°C - 3 sec Quick Cool Quick Freeze On / Off On / Off Reset - 3 sec On / Off - 3 sec - 3 sec - 3 sec Temperature zone display Temperature down The picture above is only for reference.
- Page 13 OPERATION WATER DISPENSER DISPLAY AND CONTROL • When the refrigerator is energized for the first time, the water dispenser display and control will be fully displayed for 3 seconds before entering the normal operation display. The dispenser display includes functions for water, cubed ice, and crushed ice. The water function is the default option when using the refrigerator for the first time.
- Page 14 OPERATION TEMPERATURE SETTING OF FLEX DRAWER • Press the FLEX DRAWER MODE button to select this temperature shift zone, and press the button again to adjust the temperature of flex drawer. • Each time the button is pressed, the temperature increases by one setting. When the temperature is increased to WINE (4th setting), if you press the button again, the temperature will return to MEAT (1st setting).
- Page 15 OPERATION CONTROL OF WATER DISPENSER LAMP • When the dispenser switch is switched on, the dispenser lamp will turn on. • When the dispenser switch is disconnected, the dispenser lamp will turn off after a 3-second delay. • Press the REF-ICE key to turn on the indicator light and the ice maker. Press the REF-ICE key again to turn off the indicator light and the ice maker.
- Page 16 OPERATION ECO MODE • Press ENERGY SAVING key to enter the Eco Mode. The indicator light will turn on. The quick freeze mode is canceled at the same time. The freezer temperature is controlled at 6.8°F and refrigerator temperature at 44.6° F. The mode will take effect after locking. •...
- Page 17 • Although the refrigerator in the following error cases will typically still provide standard cool/freeze functions, please call ZLINE Customer Service at 1-614-777-5004 to ensure normal use of refrigerator. Fault code...
- Page 18 OPERATION DISPENSING WATER AND ICE The ice/water dispenser is located on the outside of left refrigerating chamber door. It offers a choice of cubed ice, crushed ice, or cold water. The dispenser only works when the 3.3 Fetching water and Ice refrigerating chamber door is closed.
- Page 19 OPERATION DISASSEMBLING THE LEFT REFRIGERATOR DOOR 1. There are three Phillips-head screws to remove from the top panel that connects both doors. With the doors closed, remove the screws and set aside. 2. Pop off the top panel, revealing a pair of electrical wire harnesses at the left and right side of the panel, as well as the plastic water line connection in the middle.
- Page 20 Method for disassembly of variable temperature door: 1. Remove the variable temperature drawer; 2. Pull the variable temperature door to the maximum stroke, demount harness cover with OPERATION screwdriver or electronic runner for screw fixation, and remove the harness cover; 3.
-
Page 21: Maintenance And Cleaning
MAINTENANCE AND CLEANING MAINTENANCE AND CARE OF THE REFRIGERATOR OVERALL CLEANING • Dirt and dust behind the refrigerator and on the surrounding floor should be cleaned frequently to improve the cooling effect and to save energy. • Check the door gasket regularly to make sure there is no debris. Clean the door gasket with a soft cloth dampened with soapy water or diluted detergent. - Page 22 MAINTENANCE AND CLEANING DOOR TRAY REMOVAL • Following the direction of the arrow in the figure above, use both hands to squeeze the tray and push it upward, and then take it out to clean. Replace following the reverse of the steps above.
- Page 23 Drawing and stretching variable temperature drawer Open the variable temperature door to the maximum stroke, hold the left and right sides of the variable temperature drawer with both hands, lift the tail, exert a little force to pull the whole drawer back for about 15mm until the support MAINTENANCE AND CLEANING claw of the slide rail is separated from the drawer, then lift the front end of the drawer at a certain angle, hold the drawer and move horizontally to the inside of the chamber, and then rotate it back and up to remove the drawer.
- Page 24 MAINTENANCE AND CLEANING 4.4 Cleaning of ice storage box CLEANING THE ICE BUCKET When you need to use a lot of ice, or take ice abnormally, or need to clean the ice storage box, you can take out the ice storage box, but please put it back in time. TO TURN ON/OFF THE ICE MAKER 4.4 Cleaning of ice storage box •...
- Page 25 MAINTENANCE AND CLEANING CHANGING THE LIGHT Any replacement or maintenance of the LED lamps is intended to be made by a professional. If lights fail within the unit's warranty timeframe, call ZLINE Customer Service at 1-614-777-5004. DEFROSTING The refrigerator is made based on air-cooling principles and has an automatic defrost- ing function.
-
Page 26: Troubleshooting
TROUBLESHOOTING ZLINE Customer Service is available at 1-614-777-5004. POSSIBLE FAULT POSSIBLE FAULT/SOLUTION Failed operation Check whether the appliance is connected to power and/or whether the plug is securely plugged in. Check whether the voltage is too low. Check whether there is a power failure or partial circuits have tripped. - Page 27 TROUBLESHOOTING POSSIBLE FAULT POSSIBLE FAULT/SOLUTION Water pan overflows There is too much food in the chamber or food stored contains too much water, resulting in heavy defrosting. The doors are not closed properly, resulting in frosting due to the entry of air and increased water due to defrosting.
- Page 28 Please replace the filter following the instructions on page 13 of the Installation Manual for your refrigerator. If filter doesn't work, call ZLINE Customer Service at 1-614-777-5004. The water tastes bad Please check the water filter and age. Replace water filter as described on page 13 of the Installation Manual for your refrigerator.
-
Page 29: Warranty
WARRANTY COVERAGE ZLINE Kitchen and Bath refrigerators have a one year parts and service warranty and a five year parts warranty on the unit's sealed cooling system. This is from the original purchase date for the original purchaser of the product. - Page 30 SERVICE For warranty service, please contact our Customer Service team at 1-614-777-5004 or visit www.zlinekitchen.com/contact to utilize our online Customer Experience Portal. Need to purchase a part or accessory for your ZLINE product? Visit www.zlineparts.com, ZLINE's official parts distribution partner.
