INSTRUCTIONS–PARTS LIST
Parts
INSTRUCTIONS
AIR–OPERATED DOUBLE DIAPHRAGM
Bulk Transfer Packages
Model No. 244679, 1040 AODD Dual Inlet
120 psi (0.8 MPa, 8.3 bar) Maximum Air Working Pressure
120 psi (0.8 MPa, 8.3 bar) Maximum Fluid Working Pressure
Model No. 244680, 1040 AODD Single Inlet
120 psi (0.8 MPa, 8.3 bar) Maximum Air Working Pressure
120 psi (0.8 MPa, 8.3 bar) Maximum Fluid Working Pressure
KEEP FOR REFERENCE.
See pump and motor manuals (supplied)
for important safety warnings and instal-
lation, operation, and service instructions.
BULK
WATER
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441
ECOPYRIGHT 2001, GRACO INC.
Graco Inc. is registered to I.S. EN ISO 9001
First choice when
quality counts.t
Model No. 244681, 515 AODD Dual Inlet
100 psi (0.7 MPa, 7 bar) Maximum Air Working Pressure
100 psi (0.7 MPa, 7 bar) Maximum Fluid Working Pressure
Model No. 244682, 716 AODD Single Inlet
100 psi (0.7 MPa, 7 bar) Maximum Air Working Pressure
100 psi (0.7 MPa, 7 bar) Maximum Fluid Working Pressure
BULK ANTI–FREEZE /
WINDSHIELD WASH
TI1376A
309353
Rev. A
Advertisement
Related Manuals for Graco 244680
Summary of Contents for Graco 244680
- Page 1 120 psi (0.8 MPa, 8.3 bar) Maximum Fluid Working Pressure 100 psi (0.7 MPa, 7 bar) Maximum Fluid Working Pressure BULK ANTI–FREEZE / BULK WINDSHIELD WASH WATER TI1376A GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441 ECOPYRIGHT 2001, GRACO INC. Graco Inc. is registered to I.S. EN ISO 9001...
