Assa Abloy NORTON RIXSON 5200 Series Installation Instructions Manual

5200 Series Full Feature Low Energy Operator
Model 5241 (Push Side)
Installation Instructions
WARNING
This product can expose you to lead which is known to
the state of California to cause cancer and birth defects or
other reproductive harm. For more information go to
www.P65warnings.ca.gov.
5241 Push Side Up to 130° opening
Tools Needed
#7 #16
1/4-20
10"
#2 2.5mm
or 12"
& #3
The table below provides a list of documents associated with this product. These documents are available for download
from www.nortonrixson.com. If additional information or assistance is needed, contact Technical Product Support.
5200 Series Programming Instructions
5231 Push Side Template
Copyright © 2024, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole or in
part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9352-0026-020 Rev 1 07/24
Power Supply
(6200CM)
Optional
AC Power/
Conduit Bracket
(6300CBPC)
End Cap Kit
Push Arm Pkg
(5200END)
Pair
Safety Glasses
3/16" 3/32"
Ø7/8 Drill
12-24 9/32" 3/8"
or Hole Saw
Wire Stripper/ Pliers
Punch
Cutter
Document Title
Approved 2024-07-16
Pour la version francaise voir NortonRixson.com.
READ AND FOLLOW ALL INSTRUCTIONS.
SAVE THESE INSTRUCTIONS.
Backplate
(5200BP)
(7701-1)
Supplied Fasteners and Tools
3/16"
3x
Cable
Ties
Forearm Shoe Option
1/4-20 x 5/8" Screw &
1/4-20 x 1-3/4"
4x
Sleeve Nut
Operator Body
1/4-20 x 3-3/4"
Closer Body
(5200LAP)
Cover (5200COV)
12x
Backplate &
Forearm Shoe
12x
1/4-20 Machine
#14 x 1-3/4"
Screw
Self-Tapping Screw
2x
6x
Power Supply
& End Caps
Main Arm
1/4-20 x 3/8"
1/4-20 x 1/2"
Document Number
80-9352-0022-020
80-7352-0002-020
2x
Optional
8-32 x 1/4"
Machine Screw
1x
1x
Cable
Retaining Clip
