Anycubic Kobra 3 Combo FAQ EN
How long does the entire installation process take for the
machine?
The machine installation generally takes about 15 minutes to assemble, but there may be differences
depending on individual manual skills.
How much time does each of the machine's functions such as
vibration detection, PID calibration, and automatic leveling take?
Vibration detection takes about 4 minutes, PID calibration takes about 6 minutes, and automatic
leveling takes about 10 minutes.
What is the machine's automatic filament replenishment function
like?
1. It automatically detects materials with RFID recognition, identifying the same material and color
without any operation (default automatic replenishment).
2. It can be manually set to the same material and color without any operation (default automatic
replenishment).
3. It can be manually set to require automatic replenishment.
What is the purpose of the filament entanglement and blockage
detection in the multi-color filament box?
During printing, if the filament becomes entangled or blocked, the machine can detect it and
automatically pause printing until the issue is resolved.
How to load filament into the multi-color filament box of the
machine?
1. Place the K3 on the left side of the printer with a spacing of 10-15cm.
2. Insert one end of the signal line 4-pin into the hole on the left side of the external interface of the
printer base, with the buckle facing down.
3. Insert one end of the PTFE tube into the hole at the top of the printer, with the four PTFE tubes
inserted one by one.
4. Pass the other end of the PTFE tube through the wire clamp, with the four PTFE tubes inserted one
by one.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Kobra 3 Combo and is the answer not in the manual?

Questions and answers

Summary of Contents for AnyCubic Kobra 3 Combo

  • Page 1 Anycubic Kobra 3 Combo FAQ EN How long does the entire installation process take for the machine? The machine installation generally takes about 15 minutes to assemble, but there may be differences depending on individual manual skills. How much time does each of the machine's functions such as...
  • Page 2 What are the maximum nozzle temperature, maximum hotbed temperature, and recommended printing speed? The maximum nozzle temperature is 300 degrees; the maximum hotbed temperature is 110 degrees; the recommended printing speed is 350mm/s, with an acceleration of 20000mm/s. What materials can the machine print, and can it print 3mm consumables? The machine can print PLA, TPU, ABS, PETG, and other linear consumables, but it only supports consumables with a diameter of 1.75mm.
  • Page 3 2. Check if the filament is tangled or stuck and straighten it out. 3. If the print head is clogged, heat the nozzle to 240 degrees, use a steel needle to clear the nozzle of the print head, and replace it with a spare nozzle if necessary. How to deal with the nozzle not heating up? 1.
  • Page 4 If the above steps do not provide assistance or if you encounter any other issues during subsequent use , we recommend that you create a support ticket. The after- sales engineers will assist you in finding a solution to the problem(Reply time :1 working day) Please click this link to submit your ticket: https://support.anycubic.com/VisitorTicket/guest?id=3&token=6e6e6f9affeKpTBnN5emV0ejsfQEYJ UwFSUwNRAFMGTkAY...
