Echelon STRENGTH PRO Instruction Manual page 14

HARDWARE PACK
Do not open sections of hardware pack
until they are needed.
Part No.
L Hardware Kit (2)
L01 Hex Large Flat Head Full Tooth Bolt (8) M10×15
L02 Hex Countersunk Head Full Tooth Bolt (8) M10×95
L03 L-Shaped Wrench M2×17×50
L04 Cross Recessed Pan Head Full Tooth Bolt (2) M5×20
L05 Spring Washer (6) 10
Ф
A09 Flat Washer (6) 10
Ф
L06 Concrete Sleeve Anchor (4) M10×80
L07 L-Shaped Hex Wrench (1) 6×40×120
L08 Cross Open-Ended Wrench (1) 14×17×75
L09 L-Shaped Wrench (1) 5×35×85
Definitions
= Diameter
Ø
14 | MasTEr parTs LIsT
A09
L01
L04
L05
L02
L06
L08
L03
L09
L07
