S T R E N G T H H O M E

I N S T R U C T I O N

M A N U A L

Table of Contents

Need help?

Do you have a question about the STRENGTH HOME and is the answer not in the manual?

Questions and answers

Summary of Contents for Echelon STRENGTH HOME

Page 1 S T R E N G T H H O M E I N S T R U C T I O N M A N U A L...
Page 2 Lou Lentine Founder & CEO Echelon Fitness Multimedia, LLC...
Page 3 Hello, I am Lou Lentine, Founder & CEO of Echelon, and I would like to welcome you to the Echelon community. You’ve made a great decision for yourself and your family. The Echelon Experience is an innovative combination of fitness products integrated with our state-of-the-art Echelon Fit app.
Page 4: Federal Communications Commission (Fcc) Statement
FEDERAL COMMUNICATIONS COMMISSION (FCC) STATEMENT 15.21 FCC RF RADIATION EXPOSURE STATEMENT: You are cautioned that changes or modifications not expressly approved 1. This Transmitter must not be co-located or operating in conjunction with by the party responsible for compliance could void the user’s authority to any other antenna or transmitter.
Page 5 INNOVATION, SCIENCE AND ECONOMIC DEVELOPMENT CANADA (ISED) INNOVATION, SCIENCE ET DÉVELOPPEMENT ÉCONOMIQUE CANADA (ISED) THIS CLASS B DIGITAL APPARATUS COMPLIES WITH CAUTION: EXPOSURE TO RADIO CANADIAN ICES-003. FREQUENCY RADIATION 1. To comply with the Canadian RF exposure compliance requirements, this CET APPAREIL NUMÉRIQUE DE CLASSE B EST device and its antenna must not be co-located or operating in conjunction CONFORME À...
Page 6: Warning Labels
Cet appareil est conforme à la partie 15 des règles de la FCC. Son fonctionnement est sourris aux deux conditions Allez sur http://echelonﬁt.zendesk.com/hc/en-us pour en savoir plus. SERIAL # suivantes: (1) cet appareil peut provoquer desinterférences nocives, et (2) cet appareil coit accepter les Cet appareil est doté...
Page 8: Table Of Contents
TABLE OF CONTENTS CHAPTER 1: IMPORTANT SAFETY INSTRUCTION �� 9 CHAPTER 2: PARTS LIST�� 14 CHAPTER 3: STRENGTH HOME SPECIFICATIONS �� 16 CHAPTER 4: ASSEMBLY INSTRUCTIONS �� 18 CHAPTER 5: USER INSTRUCTIONS �� 22 CHAPTER 6: CARE & MAINTENANCE �� 39...
Page 9: Important Safety Instructions
Care should be taken when raising or lowering the workout platform of the This appliance is not intended for use by persons with reduced physical, Echelon Strength Home. Before lowering the workout platform, be sure sensory or mental capabilities, or lack of experience and knowledge, ®...
Page 10 Read the user manual fully and follow all instructions. This ensures your safety. into your shoes. • ALWAYS use the Echelon® Strength Home on solid, level ground and in a • ALWAYS warm up/stretch before starting exercise. well-lit and ventilated area.
Page 11 • NEVER overexert yourself or work to exhaustion. If you feel faint, dizzy, short of breath, or if you have chest or other pains, STOP IMMEDIATELY! If any problems arise affecting the performance of the Echelon® Strength Home, Consult your physician before using the Echelon® Strength Home again.
Page 12 IMPORTANT SAFETY INSTRUCTIONS (cont’d.) GROUNDING INSTRUCTIONS Electrical arcs are detected by AFCI outlets and are designed to disrupt and This product must be grounded. If it should malfunction or breakdown, cancel the flow of electricity. Due to this, treadmills and other equipment would grounding provides a path of least resistance for electric current to reduce the likely have issues of shutting down if plugged into AFCI outlets.
Page 13 SKETCH A DANGER – Improper connection of the equipment-grounding conductor can result in a risk of electric shock. Check with a qualified electrician or serviceman if you are in doubt as to whether the product is properly grounded. Do not modify the plug provided with the product.
Page 14: Chapter 2: Parts List
PARTS LIST Strength machine 1pc Tablet rotation bracket Mirror Top frame cover 23.8” tablet Bar 1pc Smart handle 1 pair Snap hook 1 pair Smart bar control Rope 1 pc module 1 pc Power cord 1 pc Button battery 3 pcs Cushion rubber 2pc Ankle strap 1 pc | parTs LIsT...
Page 15: Hardware Pack
HARDWARE PACK Do not open sections of hardware pack until they are needed. Part No. Hex cylindrical head full tooth bolt (4) M8×15 Cross recessed countersunk head full tooth bolt (6) M5×16 Fish eye washer (6) M5×Φ18×3.5 Cross open-end wrench (1) 14×17×75 L-shaped wrench (1) 6×40×120 L-shaped wrench (1) M2×17×50 HarDWarE paCK |...
Page 16: Chapter 3: Strength Home Specifications
STRENGTH HOME SPECIFICATIONS Screen Accessory Storage Rack Adjustment Slider Platform Locks Pulleys Power Switch & Ports (back of unit) Platform Release | sTrEngTH HOME spECIFICaTIOns...
Page 17 ACCESSORIES & PORT SPECIFICATIONS Handle Grips Straight Bar Pause & Resume Class Rope Grip Pause | Resume | Adjust Resistance Ankle Strap DC IN USB-A TF CARD USB OTG HDMI Ethernet Audio DC OUT Tablet Reset Output aCCEssOrIEs & pOrT spECIFICaTIOns |...
Page 18: Chapter 4: Assembly Instructions
Remove Mirror (E) from packaging, and check for damage prior to installation. Gently lift mirror (E) into place so it rests on support brackets and lean mirror against Main Frame (A). Be sure that Echelon logo is facing outward at bottom of mirror. STEP IMPORTANT NOTE: Do NOT overtighten assembly screws.
Page 19 STEP Touchscreen Setup Remove Touchscreen (C) and Rotation Bracket (D) from packaging. Remove 2x rear covers from back of touchscreen (C) to reveal 4x Mounting Screws. Using cross open-end wrench, remove Mounting Screws. Attach Rotation Bracket (D) to Touchscreen (C) using cross open- end wrench and 4x Mounting Screws.
Page 20 STEP DC IN USB-A Insert Main Frame USB cable into Touchscreen USB port. Insert Main Frame DC Cable into Touchscreen DC IN port. STEP Attach Frame Cover (B) onto top of Main Frame (A) using 4x Bolt M8×15 (O) with L-shaped wrench. | assEMBLY...
Page 21: Battery Installation
BATTERY INSTALLATION Handle Grip Loosen and remove screws (A) from Handle Grip end cap without button using the included L-Shaped Wrench Remove End Cap (B) and Handle Tube (C). Insert CR2032 Button Battery (D) into battery compartment with positive (+) pole facing upwards. Fix Handle Tube C and End Cap (B) back into place and replace screws.
Page 22: Chapter 5: User Instructions
USER INSTRUCTIONS IMPORTANT NOTE: Be sure unit and screen are powered on before pulling resistance cables Rotate Touchscreen • Rotate Touchscreen into Horizontal position before lowering workout platform. • Rotate Touchscreen into Vertical position once platform is lowered and workout is ready to begin. | usEr InsTruCTIOns...
Page 23 IMPORTANT NOTE: Be sure unit and screen are powered on before pulling resistance cables Workout Platform • Step down on pedal release on the lower right side of strength machine. • Pull platform away from main frame and carefully lower into workout position.
Page 24 USER INSTRUCTIONS (cont’d.) IMPORTANT NOTE: Be sure to engage platform locks prior to use. Failure to do so could result in tipping and personal injury. Platform Locks Rotate the L-shaped handles on both sides platform at bottom of Main Frame to lock platform into place. •...
Page 25 Platform Pulleys • Set weight to lowest setting (10lbs) and move left and right adjustment sliders into lowest position (K) and lock into place. • On the platform, press pulley release button to allow pulley to spring free from platform. •...
Page 26 WORKOUTS Cable Twist Chest Fly Bent Over Row Cable Kickback Cable Squat Overhead Tricep Shoulder Press Side Lunge Bench Press Bicep Curl (Bench Not Included) | WOrKOuTs...
Page 27: App Instructions
We recommend a welcome class, but any class will work. Connecting to the Echelon Fit ® Press play. Ensure your Echelon Strength Home is powered on. Follow the link from the activation email. Choose "Sign Up Now" and follow the prompts to complete your membership enrollment.
Page 28 APP INSTRUCTIONS (cont’d.) TERMINOLOGY CLASSES CLASS LIST FILTERS WORKOUT DETAILS END WORKOUT STATS | app InsTruCTIOns...
Page 29: General Functionality
GENERAL FUNCTIONALITY Introducing the Echelon Strength Home CLASSES CLASS LIST The Classes Page can be found on the far left side of the navigation bar at the bottom of the screen. This page will show the available categories for classes.
Page 30 APP INSTRUCTIONS (cont’d.) GENERAL FUNCTIONALITY (cont'd.) How does the search work? CLASSES CLASS LIST The Search can be found by going to the Classes page and selecting the magnifying glass in the top left corner. On the search page you will see popular searches and recent searches. You can search for class names, keywords, instructors or class types.
Page 31 Where are Echelon Workouts found? 2. Select ‘Create Workout’ in the bottom right. Echelon workouts are found on the ‘Custom’ page. Once on the Custom 3. You will be prompted to enter a name for the new workout. page, the workouts will be split into 2 sections: 4.
Page 32 Freestyle via an option on the ‘Custom’ Tab, similar to g. Once one, select ‘+ Add to Workout’. You will be taken back to the where you would find Echelon Created Workouts. workout screen with all movements. From here you can continue adding movements.
Page 33 RESISTANCE MODES What is a resistance mode? How to change resistance modes. Resistance modes can vary based on workout type, movements, When in a class, pause the workout. and preference. The modes are: Select the button in the top left that shows the current resistance mode. Standard —...
Page 34 APP INSTRUCTIONS (cont’d.) WIFI CONNECTION LOGIN WIFI Before logging in: Tap the WiFi icon in the upper right corner to enter the WiFi page. Select your network to connect. | app InsTruCTIOns...
Page 35 ME PAGE SETTINGS WIFI Already logged in: Tap the 'Me' icon in the bottom menu bar to enter the 'Me' page. Tap the Settings gear icon in the upper right corner to enter the Settings page. Tap WiFi and select your network. app InsTruCTIOns |...
Page 36 APP INSTRUCTIONS (cont’d.) BLUETOOTH CONNECTION ® BLUETOOTH DEVICES ME PAGE SETTINGS ® Tap the 'Me' icon in the bottom menu bar to enter the 'Me' page. Tap the Settings gear icon in the upper right corner to enter the Settings page. Tap Bluetooth Devices and select your Bluetooth ®...
Page 37 SMART ACCESSORIES CONNECTION ME PAGE SETTINGS WIFI Tap the 'Me' icon in the bottom menu bar to enter the 'Me' page. Tap the Settings gear icon in the upper right corner to enter the Settings page. Tap 'Sync Accessories' to select and pair the Straight Bar and Handle Grips.
Page 38: Connecting To The App
CONNECTING TO THE APP Connecting to the Echelon Fit ® 1. Ensure your Echelon® Strength Home is both powered on. The power cord should be plugged into the wall and the base of the Echelon® Strength Home. 2. Log in to the Echelon Fit® App.
Page 39: Chapter 6: Care & Maintenance
Inspect the power cord for damage. If damaged, replace immediately by contacting Customer Service (833-937-2453). Note: When the Echelon® Strength Home is not in use, unplug and store the power cord in a secure, dry area and away from children.
Page 40 Weekly (cont'd.) Weekly | 5-a 3. Dust and vacuum the Echelon® Strength Home and the surrounding area. To clean underneath the Echelon® Strength Home, turn off the power, and move the Echelon Strength Home to an alternate location. Return the Echelon Strength Home to its original location after cleaning.
Page 41 Echelon Strength Home again. 2. Inspect the cables for damage. If damaged, replace by contacting Customer Service.
Page 42: Customer Service
Submit a Request: Warranty Information Your Echelon Strength Home comes with a 1-year parts ® and labor warranty. Should the need arise, all you need is a proof of purchase and our customer service team will be happy to assist. Additional 1- or 2-year extended warranties are available through customer service.
Page 43 NOTES nOTEs |...
Page 44 MODEL: ECH-STRENGTHHM ECHELON FITNESS MULTIMEDIA, LLC 605 CHESTNUT STREET, SUITE 700 CHATTANOOGA, TN 37450 ECHELONFITCOM / ECHELONCOMMERCIALCOM READ INSTRUCTIONS MADE PATENT REVISION: IN CHINA PENDING 07312024 BEFORE OPERATING...
