- Page 1 Z-3192BT Wireless Gun Type 2D Image Reader Service Guide Revision History Changes to the original manual are listed below: Version Date Description of Version April. 01, 2013 Initial release...
-
Page 2: Preface
This scanner is in conformity with CE standards. Please note that an approved, CE-marked power supply unit should be used in order to maintain CE conformance. This manual is in A4 format. Please check your printer setting before printing it out. Z-3192BT Service Guide 2 / 11... -
Page 3: Power Supply
Improper assembly/disassembly may result in performance degradation to the wireless and other functions of the scanner. Use this service guide at your own risk. We do not guarantee or warranty the timeliness, completeness, or performance of the information provided in this service guide. Z-3192BT Service Guide 3 / 11... -
Page 4: Table Of Contents
Radio Notice...................................2 Radio and Television Interference............................2 For CE-Countries ...................................2 Power Supply ..................................3 WARNING................................3 Introduction ...................................5 Product Overview...................................5 Scanner Parts ..................................6 Take Apart ..................................8 Before You Start ..............................8 Important Instructions ..............................8 Tools to Prepare ..................................8 Z-3192BT Service Guide 4 / 11... -
Page 5: Introduction
UIDE Introduction With a state of the art technology, the Z-3192BT gives wireless freedom in scanning within 100-meter connection range. The included 2D scan engine enables wide variety of application at superb scanning speed. Embedded with ZEBEX most advanced decoder, Z-3192BT guarantees accurate reading and decodes most popular 1D and 2D barcode symbologies. -
Page 6: Scanner Parts
Handle board assembly 1.00 541-5319X0-151 Clip(Φ5.0*Φ2.0*0.5) 1.00 613-190BT1-201 BT module board 1.00 602-2319X0-691 Z-319XBT light guide LED rubber 1.00 031-007016-000 16P, FFC,L=70mm,one side contact 1.00 644-7319X0-000 Mylar Tape 2.00 564-031920-461 P.C Board spacer 2.00 Z-3192BT Service Guide 6 / 11... - Page 7 IR LED cover 2.00 560-131901-523 Trigger 1.00 684-100000-001 Dust cover 1.00 602-2SSHC0-681 Center mirror base rubber 4.00 031-007830-420 FFC cable 30PIN 1.00 564-031900-371 Handle base – battery base 1.00 191-B25004-201 Lithium_ion Battery pack-NP100 1.00 Z-3192BT Service Guide 7 / 11...
-
Page 8: Take Apart
Heed all warnings. Tools to Prepare • Philips screwdriver. Please follow these steps to take apart the scanner. Remove the screws from the scanner. Remove the top cover and dust cover from the scanner. Z-3192BT Service Guide 8 / 11... - Page 9 ERVICE UIDE Remove the 4 screws from the decoder board. Remove FFC cable from decoder board. Remove 2 screws from the engine. Z-3192BT Service Guide 9 / 11...
- Page 10 ERVICE UIDE Remove the FFC cable. Remove the 4 screws on BT module board. Remove the battery after unscrewing the screw from the battery cap. Z-3192BT Service Guide 10 / 11...
- Page 11 ERVICE UIDE Remove the 2 screws in handle case. 10. Remove the screw in battery base. 11. Remove the FFC cable from the handle base assembly. Z-3192BT Service Guide 11 / 11...
