GV-R Series IP Camera Mount
GV-Mount108
GV-Mount111
GV-Mount210-2
GV-Mount213-1
GV-Mount215-1
GV-Mount311
GV-Mount460
GV-Mount504-1
GV-Mount505
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
Installation Guide
MT-RSERIES

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV-R Series and is the answer not in the manual?

Questions and answers

Related Manuals for GeoVision GV-R Series

Summary of Contents for GeoVision GV-R Series

  • Page 1 GV-R Series IP Camera Mount Installation Guide GV-Mount108 GV-Mount111 GV-Mount210-2 GV-Mount213-1 GV-Mount215-1 GV-Mount311 GV-Mount460 GV-Mount504-1 GV-Mount505 Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use. MT-RSERIES...
  • Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.

  • Page 3: Table Of Contents

    Contents Preface ........................1 1. Straight Tube GV-Mount108 ..................2 2. Pendant Mounting with GV-Mount111 ................4 3. Wall Pendant Mounting with GV-Mount210-2 .............. 8 4. Wall Box Mounting with GV-Mount213-1 ..............10 5. Wall Bracket Mounting with GV-Mount215-1 ............. 13 6.

  • Page 4: Preface

    Preface Welcome to the GV-R Series IP Camera Mount Installation Guide. This Installation Guide is designed for the following models: Model Model Number GV-RBL5800 IR Bullet IP Camera GV-RBL5811 IR Eyeball Dome IP Camera GV-REB5800 IR Fisheye IP Camera GV-RFER12700...

  • Page 5: Straight Tube Gv-Mount108

    1. Pendant Mount GV-Mount108 Packing List GV-Mount108 Expansion bolt x 4 Allen wrench x 1 Applicable Models  GV-RFER12700 Note: GV-Mount108 must be used with GV-Mount504-1.
  • Page 6 Dimension GV-Mount108 + GV-Mount504-1 Installation See 8.1 GV-Mount108 + GV-Mount504-1 Installation below for details.

  • Page 7: Pendant Mounting With Gv-Mount111

    2. Pendant Mounting with GV-Mount111 Packing List GV-Mount111 Expansion bolt x 4 Hexagon screws x 3 Hexagon socket head cap screw x 2 Hexagon wrench Applicable Models:  GV-RMS32810...
  • Page 8 Dimension GV-Mount111 Installation Install the camera and the adapter base.
  • Page 9 Drill four screw holes on the wall where installation is needed, and hammer in four expansion screws into the holes. Then thread the main cable connector out from the center of the mounting bracket, and align the mounting bracket base with the four screw holes on the wall and tighten the screws.
  • Page 10 If adjustment of each lens angle is needed, loosen the screws on the camera transparent cover, remove the cover, adjust as needed, then align the cover with the screw holes and tighten the screws. Lock the transparent cover of the dome camera onto the camera base.

  • Page 11: Wall Pendant Mounting With Gv-Mount210-2

    3. Wall Pendant Mounting with GV-Mount210-2 Packing List GV-Mount210-2 Expansion bolt x 4 Short screw (10 mm) x 1 Long screw (35 mm) x 4 Colloidal particle x 4 Applicable Models  GV-RFER12700 Note: GV-Mount210-2 must be used with GV-Mount504-1.
  • Page 12 Dimension GV-Mount210-2 + GV-Mount504-1 Installation See 8.2 GV-Mount210-2 + GV-Mount504-1 Installation below for details.

  • Page 13: Wall Box Mounting With Gv-Mount213-1

    4. Wall Box Mounting with GV-Mount213-1 Packing List GV-Mount213-1 Base x 1 Allen wrench x 1 Socket screw (14 mm) x 3 Colloidal particle x 4 Long screw (35 mm) x 4 Screw waterproofing ring x 4 Waterproof joint rubber ring x 1 Waterproof connector x 1 10.
  • Page 14 Dimension GV-Mount213-1 Installation Place the template paster on the wall surface where installation is needed. Drill four self-tapping screw holes, and hammer four colloidal particles into the drilled wall holes. Align the four screw holes of GV-Mount213-1 base with the wall screw holes and tighten them with self-tapping screws.
  • Page 15 Align the adapter board of the fisheye camera with the screw holes on the bottom cover of GV-Mount213-2, and tighten three screws. Thread the network cable through the waterproof connector and pull it out from the central hole of the adapter board. Connect the tail cable of the fisheye camera and the network cable, place them in GV-Mount213-1, and align the fisheye camera with the buckle on the adapter board.

  • Page 16: Wall Bracket Mounting With Gv-Mount215-1

    5. Wall Bracket Mounting with GV-Mount215-1 Packing List GV-Mount215-1 Short screw (10 mm) x 3 Allen wrench x 1 Long screw (25 mm) x 4 Colloidal particle x 4 Drill Template Paster Applicable Models:  GV-REB5800 Dimension...
  • Page 17 GV-Mount215-1 Installation Drill holes according to the drill template paster on the wall and insert the colloidal particles. Secure the bottom plate of GV-Mount215-1 on the wall using the supplied screws.
  • Page 18 Fix the camera’s collar onto GV-Mount215-1 with supplied screws. Thread the camera’s cables inside GV-Mount215-1 and mount the whole camera onto GV-Mount215-1.
  • Page 19 Connect the cables from the side hole of UA-Mount215 and tighten the bottom screw to complete the installation.

  • Page 20: Corner Mounting With Gv-Mount311

    6. Corner Mounting with GV-Mount311 Packing List GV-Mount311 Colloidal particle x 8 Long screw (35 mm) x 8 Socket screw (M6 x 16 mm) x 4 Spring washer (M6) x 4 Conical spring washer (M6) x 4 Socket screw (M4 x 16 mm) x 4 Spring washer (M4) x 4 Conical spring washer (M6) x 4 Applicable Models:...
  • Page 21 Dimension...

  • Page 22: Gv-Mount311 Installation For Gv-Reb5800

    6.1 GV-Mount311 Installation for GV-REB5800 Refer to the installation method mentioned above, drill four holes on each side of the wall at the wall corners, hammer four colloidal particles into the drilled wall holes, and then align the GV-Mount311 (port #2 as indicated below) with the wall screw holes and tighten it with self-tapping screws.

  • Page 23: Gv-Mount311 Installation For Gv-Rms32810

    See Step 3 ~ 4 in 4 Wall Box Mounting with GV-Mount213-1 for the subsequent installation steps. 6.2 GV-Mount311 Installation for GV-RMS32810 Use 8 plastic anchors and self-tapping screws to install the bracket onto the corresponding wall corner.
  • Page 24 Thread the main cable connector out from the center of the wall corner bracket and wall-mounted bracket, align the base of the wall-mounted bracket with the four screw holes of the wall corner bracket, and tighten the screws. After connecting the main cable connector with the camera tail cable, place them into the base, then insert the camera bottom cover connector into the interface of the wall-mounted bracket and lock it with the side screw.

  • Page 25: Pole Mounting With Gv-Mount460

    . Pole Mounting with GV-Mount460 Packing List GV-Mount460 Stainless steel clamp x 2 M6 socket screw (16 mm) x 4 M4 socket screw (16 mm) x 4 M6 spring washer x 4 M6 conical spring washer x 4 M4 spring washer x 4 M4 conical spring washer x 4 Applicable Models: ...
  • Page 26 Dimension GV-Mount460 Installation Use two clamps to install the pole mount bracket onto the corresponding pole.
  • Page 27 Thread the main cable connector out from the center of the pole-mounted bracket and wall mount bracket, align the base of the wall mount bracket with the four screw holes of the pole-mounted bracket, and tighten the screws. After connecting the main cable connector with the camera tail cable, place them into the base, then insert the camera bottom cover connector into the interface of the wall mount bracket and lock it with the side screw.

  • Page 28: Wall Bracket Mounting With Gv-Mount504-1

    If adjustment of each lens angle is needed, loosen the screws on the camera transparent cover, remove the cover, adjust as needed, then align the cover with the screw holes and tighten the screws. Lock the transparent cover of the dome camera onto the camera base. 8.

  • Page 29: Gv-Mount108 + Gv-Mount504-1 Installation

    Dimension 8.1 GV-Mount108 + GV-Mount504-1 Installation Install the fisheye camera adapter board onto the concealed wiring box.
  • Page 30 Thread the tail cable of the fisheye camera through the central hole of GV-Mount504-1 base. Rotate the camera clockwise to ensure that the latch on the bottom of the camera and the latch on the adapter board are fully engaged.
  • Page 31 Drill four screw holes on the wall where installation is needed. Hammer four expansion screws into the drilled wall holes. Then, thread the main cable connector out from the center of the suspension rod. Align the suspension rod base with the four wall screw holes and tighten with screws.
  • Page 32 After connecting the main cable connector and fisheye camera tail cable, place them into the concealed wiring box. Then, insert the concealed wiring box bottom cover connector into the suspension rod interface and tighten the side machine screws. This completes the installation.

  • Page 33: Gv-Mount210-2 + Gv-Mount504-1 Installation

    8.2 GV-Mount210-2 + GV-Mount504-1 Installation Install the fisheye camera adapter board onto the concealed wiring box. Thread the tail cable of the fisheye camera through the central hole of the concealed wiring box. Rotate the camera clockwise to ensure that the latch on the bottom of the camera and the latch on the adapter board are fully engaged (as shown in Figure 1).
  • Page 34 Drill four screw holes on the wall where installation is needed. Hammer four expansion screws into the drilled wall holes. Then, thread the main cable connector out from the center of the bracket. Align the bracket base with the four wall screw holes and tighten with screws (as shown in Figure 2).

  • Page 35: Wall Box Mounting With Gv-Mount505

    9. Wall Box Mounting with GV-Mount505 Packing List GV-Mount505 Short screw (8 mm) x 3 Long screw (35 mm) x 3 Colloidal particle x 3 Allen wrench x 1 Screw waterproofing ring x 3 Waterproof joint rubber ring x 1 Waterproof connector x 1 Dill template paster 10.
  • Page 36 Dimension GV-Mount505 Installation Drill holes according to the drill template paster on the wall and insert the colloidal particles.
  • Page 37 Secure the bottom of GV-Mount505 on the wall using the supplied screws. Thread the necessary cables from the bottom hole of GV-Mount505.
  • Page 38 Connect the camera’s cables inside GV-Mount505 and fix the camera onto the upper part of GV-Mount505 using the supplied screws. Assemble GV-Mount505 to complete the installation.
