GV-A/T/EBD Series IP Camera Mount
GV-Mount107
GV-Mount113
GV-Mount114
GV-Mount208-5
GV-Mount210-3
GV-Mount211-12
GV-Mount211P
GV-Mount212P
GV-Mount213
GV-Mount300-2 / 310-2
GV-Mount312
GV-Mount313
GV-Mount420
GV-Mount440
GV-Mount480
GV-Mount504
GV-Mount511
GV-Mount704
GV-Mount924
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
Installation Guide
ATEBDSERIES-MI-D
Advertisement
Table of Contents
Related Manuals for GeoVision GV-Mount107
Summary of Contents for GeoVision GV-Mount107
- Page 1 GV-A/T/EBD Series IP Camera Mount Installation Guide GV-Mount107 GV-Mount113 GV-Mount114 GV-Mount208-5 GV-Mount210-3 GV-Mount211-12 GV-Mount211P GV-Mount212P GV-Mount213 GV-Mount300-2 / 310-2 GV-Mount312 GV-Mount313 GV-Mount420 GV-Mount440 GV-Mount480 GV-Mount504 GV-Mount511 GV-Mount704 GV-Mount924 Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use.
- Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.
-
Page 3: Table Of Contents
Chapter 1 Installing Multi-Sensor Camera ............1 1.1 Pendant Adapter Plate GV-Mount113 ..............1 1.2 Pendant Mounting ....................2 1.2.1 Pendant Mounting with GV-Mount107 ..............2 1.2.2 Pendant Mounting with GV-Mount114 ..............5 1.3 Wall Mounting ......................7 1.3.1 Wall Mounting with GV-Mount211-12 ............... 7 1.3.2 Wall Pendant Mounting with GV-Mount210-3 ............ -
Page 4: Preface
Preface Welcome to the GV-A/T/EBD Series IP Camera Mount Installation Guide. This Installation Guide is designed for the following models: Model Model Number Bullet IP Camera GV-TBL2718 Multi-Sensor IP Camera GV-TMS8800 / 20811 GV-EBDP5800 / 8800 Panoramic IP Camera GV-TBLP5800 / 8800 Vandal Proof IP Camera GV-TVD2712... -
Page 5: Chapter 1 Installing Multi-Sensor Camera
Chapter 1 Installing Multi-Sensor Camera 1.1 Pendant Adapter Plate GV-Mount113 GV-Mount113 is a pendant adapter plate designed to be used with other mounts. It is not intended for standalone use. GV-Mount113 Packing List GV-Mount113 Pendant Adapter Plate M4 Screw (12 mm) x 4 Applicable Models ... -
Page 6: Pendant Mounting
Pendant Tube Tube Connector Torx Wrench Applicable Models GV-TMS8800: GV-Mount107 must be used with GV-Mount511. Note: Before installing GV-Mount107, note the following: Prepare 3 long screws for securing the Pendant Bracket to the ceiling. GV-Mount107 optionally extends with GV-Mount704. - Page 7 GV-Mount107 + GV-Mount511 Installation Place GV-Mount107 on the ceiling and mark the location for the center socket and the 3 screws. Drill the marks and secure the Pendant Bracket onto the ceiling. Attach one end of the Pendant Tube to the Pendant Bracket, and the other end to the Tube Connector.
- Page 8 Fix the camera base to GV-Mount511, adjust the lens angle, and fix the housing to the camera base. Caution: Do not pull hard when leading the tail cables; otherwise, it will cause loose or disconnected tail cables.
-
Page 9: Pendant Mounting With Gv-Mount114
1.2.2 Pendant Mounting with GV-Mount114 The mounting requires GV-Mount114 and GV-Mount113. GV-Mount114 Packing List GV-Mount114 Pendant Mount M8 Screw Anchor (80 mm) x 4 Drill Template Paster Applicable Models GV-TMS20811: GV-Mount114 must be used with GV-Mount113. - Page 10 GV-Mount114 + GV-Mount113 Installation Stick the drill template paster to the ceiling and drill holes on the ceiling according to the drill template. Insert the screw anchors in the ceiling. Secure the GV-Mount114 pendant mount to the ceiling. Mount the GV-Mount113 adapter plate by referring to Steps 2 to 3 in 1.3.2 Wall Pendant Mounting with GV-Mount210-3.
-
Page 11: Wall Mounting
1.3 Wall Mounting 1.3.1 Wall Mounting with GV-Mount211-12 The mounting requires GV-Mount211-12. GV-Mount211-12 Packing List GV-Mount211-12 Long Screw (47 mm) x 5 Short Screw (10 mm) x 4 Screw Anchor x 5 Drill Template Paster Applicable Models GV-TMS8800... - Page 12 GV-Mount211-12 Installation Unscrew the bottom of GV-Mount211-12 to separate the two parts. Drill 4 mounting holes on the wall using the drill template paster. Secure the bottom of GV-Mount211-12 to the wall using the supplied long screws. Unscrew the four screws of the camera to remove the housing from the camera base. Thread the necessary wires through GV-Mount211-12.
-
Page 13: Wall Pendant Mounting With Gv-Mount210-3
1.3.2 Wall Pendant Mounting with GV-Mount210-3 The mounting requires GV-Mount210-3 and GV-Mount113. GV-Mount210-3 Packing List GV-Mount210-3 Wall Pendant Mount M8 Screw Anchor (80 mm) x 4 Drill Template Paster Rubber Pad Applicable Models GV-TMS20811: GV-Mount210-3 must be used with GV-Mount113. - Page 14 GV-Mount210-3 + GV-Mount113 Installation Secure the GV-Mount210-3 wall mount bracket. (1) Locate the positions of the holes according to the 4 screw holes on the bracket. Drill 4 expansion screw holes on the wall and insert the expansion screws. (2) Lead cables through the bracket hole. (3) Align the bracket holes with the expansion screws, and insert the expansion screws into the bracket holes.
- Page 15 Mount the GV-Mount113 adapter plate. Hang the safety rope on the lock nut. Align the locknut on the GV-Mount113 adapter plate with the GV-Mount210-3 wall mount bracket, tighten the locknut in reverse direction (relative to the installation direction of the adapter plate), and tighten the screws on the bracket and the hex nuts on the locknut with the hex key and a Philips screwdriver.
-
Page 16: Convex Corner Mounting
1.4 Convex Corner Mounting 1.4.1 Convex Corner Mounting with GV-Mount312 The mounting requires GV-Mount312 and GV-Mount211-12. GV-Mount312 Packing List GV-Mount312 M4 Screw (20 mm) x 4 M8 Screw (80 mm) x 4 Applicable Models GV-TMS8800: GV-Mount312 must be used with GV-Mount211-12. - Page 17 GV-Mount312 + GV-Mount211-12 Installation Drill 4 mounting holes on the corner using the drill template paster. Secure GV-Mount312 to the corner using the supplied screws. Unscrew the bottom of GV-Mount211-12 to separate the two parts. Secure the bottom of GV-Mount211-12 onto GV-Mount312 using the supplied screws as indicated below.
-
Page 18: Convex Corner Mounting With Gv-Mount313
1.4.2 Convex Corner Mounting with GV-Mount313 The mounting requires GV-Mount313, GV-Mount210-3, and GV-Mount113. GV-Mount313 Packing List GV-Mount313 Convex Corner Mount M8 Screw Anchor (25 mm) x 4 D8 Flat Washer x 4 D8 Spring Washer x 4 Applicable Models GV-TMS20811: GV-Mount313 must be used with GV-Mount210-3. - Page 19 GV-Mount313 + GV-Mount210-3 + GV-Mount113 Installation Secure the GV-Mount313 corner mount bracket to the wall using the 6 screws and thread the external cables through. Secure the GV-Mount210-3 wall mount bracket to the GV-Mount313 corner mount bracket by referring to Step 1 in 1.3.2 Wall Pendant Mounting with GV-Mount210-3. Mount the GV-Mount113 adapter plate by referring to Steps 2 to 3 in 1.3.2 Wall Pendant Mounting with GV-Mount210-3.
-
Page 20: Pole Mounting
1.5 Pole Mounting 1.5.1 Pole Mounting with GV-Mount420 The mounting requires GV-Mount420 and GV-Mount211-12. GV-Mount420 Packing List GV-Mount420 M4 Screw x 4 Additional Screw Kit M6 Screw x 4 M6 Nut x 4 M6 Plain Washer x 4 ... - Page 21 GV-Mount420 + GV-Mount211-12 Installation Unscrew the bottom of GV-Mount211-12 to separate the two parts. Align and attach the bottom of GV-Mount211-12 to GV-Mount420 using the supplied screws as indicated. Note: Make sure the direction of the UP indicators on the 2 parts are placed pointing upward.
-
Page 22: Pole Mounting With Gv-Mount480
1.5.2 Pole Mounting with GV-Mount480 The mounting requires GV-Mount480, GV-Mount210-3, and GV-Mount113. GV-Mount480 Packing List GV-Mount480 Pole Mount Bracket Clamp x 3 M8 Screw Anchor (25 mm) x 4 D8 Flat Washer x 4 D8 Spring Washer x 4 Applicable Models ... - Page 23 GV-Mount480 + GV-Mount210-3 + GV-Mount113 Installation Secure the GV-Mount480 pole mount bracket using the hoop and thread the external cables through. Secure the GV-Mount210-3 wall mount bracket to the GV-Mount480 pole mount bracket by referring to Step 1 in 1.3.2 Wall Pendant Mounting with GV-Mount210-3. Mount the GV-Mount113 adapter plate by referring to Steps 2 to 3 in 1.3.2 Wall Pendant Mounting with GV-Mount210-3.
-
Page 24: Wall Box Mounting
1.6 Wall Box Mounting 1.6.1 Wall Box Mounting with GV-Mount511 The mounting requires GV-Mount511. GV-Mount511 Packing List GV-Mount511 M3 Screw (25 mm) x 4 M3 Screw (12 mm) x 2 Screw Anchor x 4 Drill Template Paster Applicable Models GV-TMS8800... - Page 25 GV-Mount511 Installation Drill 4 mounting holes and a hole at the center socket location on the wall using the drill template paster. Insert 4 screw anchors to the mounting screw location and secure GV-Mount511 to the wall with the supplied screws. Note that the knobs should point down. Knobs point down Unscrew the four screws of the camera to remove the housing from the camera base.
- Page 26 Secure the camera base onto GV-Mount511 using the 2 supplied screws as indicated below: Adjust the camera lens angles if necessary, and fix the housing to the camera base.
-
Page 27: Swan Neck Mounting
1.7 Swan Neck Mounting 1.7.1 Swan Neck Mounting with GV-Mount208-5 The mounting requires GV-Mount208-5 and GV-Mount113. GV-Mount208-5 Packing List GV-Mount208-5 Swan Neck Mount M8 Screw Anchor (90 mm) x 6 Applicable Models GV-TMS20811: GV-Mount208-5 must be used with GV-Mount113. - Page 28 GV-Mount208-5 + GV-Mount113 Installation Secure the GV-Mount208-5 swan neck mount. Align the GV-Mount113 adapter plate with the holes in the mounting plate and tighten the four screws with the matching wrench or hexagonal screwdriver, installing the mounting plate with the side with the “FRONT” logo facing downward (the opposite side of the adapter plate).
-
Page 29: Chapter 2 Installing Eyeball Dome / Vandal Proof Dome
Chapter 2 Installing Eyeball Dome / Vandal Proof Dome 2.1 Pendant Mounting with GV-Mount107 The mounting requires GV-Mount107 and GV-Mount213 / 212P. GV-Mount213 is for eyeball domes, while GV-Mount212P is for vandal proof domes. The following illustration uses GV-Mount213 as an example:... - Page 30 Prepare 3 long screws for securing the Pendant Bracket to the ceiling. GV-Mount107 optionally extends with GV-Mount704. Place GV-Mount107 on the ceiling and mark the location for the center socket and the 3 screws. Drill the marks and secure the Pendant Bracket onto the ceiling.
-
Page 31: Junction Box Mounting With Gv-Mount211P
2.2 Junction Box Mounting with GV-Mount211P The mounting requires GV-Mount211P. GV-Mount211P GV-Mount211 GV-Mount211P Packing List GV-Mount211P Long Screw x 5 Short Screw x 4 Screw Anchor x 5 Plastic PG21 Conduit Connector Drill Template Paster Applicable Models Eyeball Dome GV-EBD2702 / 2704 / 2705 / 4700 / 4701 / 4704 / 4711 / 4712 / 4813 / 8700 / 8711 / 8800 / 8813 ... - Page 32 GV-Mount211P Installation Unscrew the bracket. Loosen the indicated area by turning it anticlockwise. Power Box Stick the drill template paster to the wall with the arrow pointing up. Drill 4 holes according to the sticker and insert the 4 screw anchors to the 4 holes. Secure the power box to the wall with 4 long screws.
- Page 33 Remove the bottom ring by turning it anticlockwise. Bottom Ring Secure the camera to the wall mount bracket with the provided short screws according to the screw position for each model: GV-EBDP5800 / 8800...
- Page 34 GV-EBD2702 / 2704 Thread the Ethernet cable through the PG21 conduit connector and the power box as shown in No. 8, Step 10. Then connect the cable to the camera. Rotate the plastic ring to secure the conduit connector to the power box. Screw in the cap as shown in No.
- Page 35 11. Mount the bottom ring.
-
Page 36: Convex / Concave Corner Mounting With Gv-Mount 300-2 / 310-2
2.3 Convex / Concave Corner Mounting with GV-Mount 300-2 / 310-2 The mounting requires GV-Mount211P and GV-Mount300-2 / 310-2. GV-Mount300-2 is for convex corner mounting, while GV-Mount310-2 is for concave corner installation. GV-Mount300-2 / 310-2 Packing List Mounting Bracket Convex / Concave Mounting Plate x 2 1/4”... - Page 37 Position and secure GV-Mount211P to GV-Mount300-2 / 310-2 as indicated below. Secure your camera to the GV-Mount211P to complete the installation.
-
Page 38: Pole Mounting With Gv-Mount420
2.4 Pole Mounting with GV-Mount420 The mounting requires GV-Mount211P and Mount420. GV-Mount420 Packing List GV-Mount420 M4 Screw x 4 Additional Screw Kit M6 Screw x 4 M6 Nut x 4 M6 Plain Washer x 4 M6 Split Washer x 4 Applicable Models ... - Page 39 GV-Mount211P + Mount420 Installation Unscrew the bracket. Loosen the indicated area by turning it anticlockwise. Power Box Align and attach the power box to the back plate using the 4 supplied M4 screws as indicated. Note: Make sure the direction of the “up ↑” indicator on the back plate match that of the power box.
- Page 40 Thread the 3 steel straps onto the back plate. To install the camera to the GV-Mount211P junction box, follow Steps 6 to 12 in 2.2 Junction Box Mounting with GV-Mount211P. Secure the camera onto the desired pole by tightening the steel straps.
-
Page 41: Wall / Ceiling Box Mounting With Gv-Mount 213 / 212P
2.5 Wall / Ceiling Box Mounting with GV-Mount 213 / 212P The mounting requires GV-Mount213 or GV-Mount212P. GV-Mount213 is for eyeball domes, while GV-Mount212P is for vandal proof domes. The following illustration uses GV-Mount213 as an example: GV-Mount213 / 212P Packing List GV-Mount213 / 212P Long Screw x 3 Short Screw x 3... - Page 42 2. Drill 3 holes according to the screw locations. Then, drill a bigger hole at the center socket location for the Ethernet cable. 3. Insert 3 screw anchors to the screw locations and secure GV-Mount to the wall / ceiling with 3 long screws.
- Page 43 Note: In addition to the abovementioned standard installation, you can also choose to run the Ethernet cable through a corrugated tube. To do this, you will have to purchase your own conduit connector and corrugated tube. 3/4” NPS is the recommended type of connector.
-
Page 44: Power Box Mounting With Gv-Mount924
2.6 Power Box Mounting with GV-Mount924 The mounting requires GV-Mount924. GV-Mount924 Packing List GV-Mount924 M3 8 mm Screw x 4 Applicable Models GV-EBDP5800 / 8800 The mounting is only for eyeball domes. GV-Mount924 installation 1. Secure the gang box onto the back of GV-Mount924 using the ports indicated below. US Double Gang Box US Single Gang Box... - Page 45 2. Thread the camera’s cables through GV-Mount924 and secure the camera onto the mount using the ports indicated below using the supplied screws.
-
Page 46: Chapter 3 Installing Bullet Camera
Chapter 3 Installing Bullet Camera 3.1 Convex / Concave Corner Mounting with GV-Mount300-2 / 310-2 The mounting requires GV-Mount504 and GV-Mount300-2 / 310-2. GV-Mount300-2 is for convex corner mounting, while GV-Mount310-2 is for concave corner installation. GV-Mount300-2 / 310-2 Packing List Mounting Bracket Convex / Concave Mounting Plate x 2 1/4”... - Page 47 GV-Mount300-2 / GV-Mount310-2 + GV-Mount504 Installation Follow the instructions in 3.2 Wall Box Mounting with GV-Mount504 to install the camera onto GV-Mount504. Assemble GV-Mount300-2 / 310-2 by attaching the two mounting plates onto the mounting bracket with the supplied carriage bolts, 1/4” plain washers, and 1/4” flange nuts.
-
Page 48: Wall Box Mounting With Gv-Mount504
3.2 Wall Box Mounting with GV-Mount504 The mounting requires GV-Mount504. GV-Mount504 Packing List GV-Mount504 Long Screw x 4 Short Screw x 3 Screw Anchor x 4 Drill Template Paster Waterproof Rubber Plug Plastic PG21 Conduit Connector Applicable Models GV-TBL2718 ... - Page 49 GV-Mount504 Installation 1. Unscrew the box cover. 2. Stick the drill template paster to the wall with the arrow pointing up. 3. Drill the 4 mounting holes according to the drill template. 4. Insert the 4 screw anchors to the mounting holes. 5.
- Page 50 7. Connect the Ethernet cable using one of the two methods: Thread the Ethernet cable through the center hole. Thread the Ethernet cable through the PG21 conduit connector and the power box as shown in No 8 in the figure below. Rotate the plastic ring to secure the conduit connector to the power box.
-
Page 51: Pole Mounting With Gv-Mount440
3.3 Pole Mounting with GV-Mount440 The mounting requires GV-Mount440 and GV-Mount504. GV-Mount440 Packing List GV-Mount440 M4 Screw x 4 Applicable Models GV-TBL2718 GV-TBLP5800 / 8800 GV-Mount440 + GV-Mount504 Installation 1. Unscrew the box cover. - Page 52 2. Align and attach the power box to the back plate using the 4 supplied M4 screws as indicated. Note: Make sure the direction of the “up ↑” indicator on the back plate matches that of the power box. 3. Thread the 3 steel straps onto the back plate. 4.
-
Page 53: Power Box Mounting With Gv-Mount924
3.4 Power Box Mounting with GV-Mount924 The mounting requires GV-Mount924. GV-Mount924 Packing List GV-Mount924 M3 8 mm Screw x 4 Applicable Models GV-TBL2718 GV-TBLP5800 / 8800 GV-Mount924 installation 1. Secure the gang box onto the back of GV-Mount924 using the ports indicated below. US Double Gang Box US Single Gang Box... - Page 54 2. Thread the camera’s cables through GV-Mount924 and secure the camera onto the mount using the ports indicated below using the supplied screws.
