odass OD-5520L Instruction Manual

Download this manual

Instruction

manual

niche

OD-5520L

Material: Stainless steel

The following installation details are

applicable for existing wall before tiling

and do not cover every possible

situation. Always consult with a

licenced professional during

preparation and installation.

Installation of the electric power to

allow light in the niche

Transformer included

Connector

If you are using a newly constructed

wall, start the installation from step 3.

Transformer

10 feet \ 12 Volts DC

If the distance between the wall studs

are greater than the niche, add a frame

around the niche to accommodate it.

Professional advice may be needed.

Plug

3 feet \ 120 Volts AC

Need help?

Do you have a question about the OD-5520L and is the answer not in the manual?

Page 1 Instruction manual niche OD-5520L Material: Stainless steel The following installation details are If you are using a newly constructed If the distance between the wall studs applicable for existing wall before tiling wall, start the installation from step 3. are greater than the niche, add a frame and do not cover every possible around the niche to accommodate it.
Page 2 Installation of the niche 1. Locate and mark the center lines of the adjacent wall studs using a stud finder. Draw a level line between the two wall studs at the desired height to insert the niche. 2. Trace the cutting line with a pencil, above the center line, cut a cavity in the wall panel along the drawn line.
Page 3 Installation of the niche 5. Apply your installation material and fix your tiles, marbles or stones directly on the shower wall. It is preferable that the tiles are symmetrical around the support structure. 6. Apply a necessary layer of silicone around the back periphery of the flange of the niche to ensure watertightness.
Page 4 Please be sure to read the manual carefully before installation. LIMITED GUARANTEE MAINTENANCE Odass offers a guarantee 5-year Wipe the surface with a soft limited* term on all finishes of cloth after each use. Use mild niches and washbasins from the cleaning products.
