Instruction

manual

niche

OD-5520

Material: Stainless steel

The following installation details are

applicable for existing wall before tiling

and do not cover every possible

situation. Always consult with a licenced

professional during preparation and

installation.

Installation

of the niche

If you are using a newly constructed

wall, start the installation from step 3.

1. Locate and mark the center lines of the adjacent wall studs using a

stud finder. Draw a level line between the two wall studs at the

desired height to insert the niche.

If the distance between the wall studs

are greater than the niche, add a frame

around the niche to accommodate it.

Professional advice may be needed.

Need help?

Do you have a question about the niche and is the answer not in the manual?

Page 1 If the distance between the wall studs applicable for existing wall before tiling wall, start the installation from step 3. are greater than the niche, add a frame and do not cover every possible around the niche to accommodate it.
Page 2 Installation of the niche 2. Trace the cutting line with a pencil, above the center line, cut a cavity in the wall panel along the drawn line. Make sure that the top and bottom lines are level. 3. Level and secure the upper and lower support frame to the adjacent vertical studs.
Page 3 6. Apply a necessary layer of silicone around the back periphery of the flange of the niche to ensure watertightness. 7. Insert the niche into the cavity. Press firmly on the flange and make sure that the niche is in place. It is recommended to seal the space...
Page 4 Installation instruction 8. Add adhesive tape to hold the niche in place until the silicone has hardened. Wait 24 hours before using the shower. Please be sure to read the manual carefully before installation. MAINTENANCE LIMITED GUARANTEE Wipe the surface with a soft Odass offers a guarantee 5-year cloth after each use.

Od-5520
