HARLEY DAVIDSON NIGHTSTER '24-
M
O
RE F 21956
1 Person
20 min
EASY
ID
PIEZA/PART
1
2
3
4
5
6
7
*
Algunos componentes se suministran montados.
Some components are supplied assembled.
U
N
T
I
N
G
S EMIFAIRING A NA RC HY MO DE L/ SE MIC AR E NADO A NA RC H Y
DESCRIPCIÓN
Semicarenado Anarchy
Soporte derecho
Soporte izquierdo
Silentblock Ø12xØ6x9
Casquillo con valona Ø12xØ6,8x7,3
Tornillo Allen M5x16 Ø11 ISO 7380
Tapón tornillo M5 ISO 7380
www.puig.tv
www.puigusa.com
I
N
S
T
R
DESCRIPTION
Anarchy semifairing
Right support
Left support
Ø12xØ6x9 Silentblock
Ø12xØ6,8x7,3 Bush with flange
M5x16 Ø11 ISO 7380 Allen screw
M5 ISO 7380 screw cap
Pg. 1/2
info@puigusa.com
U
C
T
I
O
N
QTY
1
1
1
4
4
4
4
Illustrations and layout by: www.ciandisseny.com
info@puig.tv
S
TORX
T30
ALLEN
Nº23
REF
10896NM3
SOPOR2P3-R21956
SOPOR2P3-L21956
AROPASACABLES-1
CASQUI-1A---750
TORNI-I7380-493
TAPON--------85
V0.06/24
