PUIG 21853 Mounting Instructions

M O
REF 21853
1 Person
40 min
EASY
ID PIEZA/PART
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
*
Algunos componentes se suministran montados.
Some components are supplied assembled.
BMW R1300GS '23-
U N T I N G
DESCRIPCIÓN
Protector de far
Soporte izquierdo
Soporte derecho
Soporte inferior
Soporte fijación
Perno de clip M4
Tornillo M4X8 DIN7991
Arandela de nylon M4
Tornillo Allen M5x12 Ø11 ISO 7380
Casquillo Ø8,5x Ø13x 3,5
Tornillo Allen M5x16 Ø11 ISO 7380
Tuerca de clip M5
Silentblock Ø12xØ6x9
Tornillo Allen M6x16 Ø14 ISO 7380
Tuerca de clip M6 (negra)
www.puig.tv
www.puigusa.com
I N S T R
HEADLIGHT PROTEC TO R
DESCRIPTION
Headlight protector
Left support
Right support
Lower support
Fixing support
M4 clip bolt
M4X8 DIN7991 screw
M4 nylon washer
M5x12 Ø11 ISO 7380 Allen screw
Ø8,5x Ø13x 3,5 Arrowhead
M5x16 Ø11 ISO 7380 Allen screw
M5 clip nut
Ø12xØ6x9 Silentblock
M6x16 Ø14 ISO 7380 Allen screw
M6 clip nut (black)
Pg. 1/4
