- Page 1 CDGNE-50 Disconnecting switch Instruction manual Before installing and using the product, please read the instruction manual carefully and keep it properly.
-
Page 2: Safety Notice
Safety Notice Before installation, operation, running, maintenance, and inspection, please read this manual carefully, and install and use this product accurately according to the content in the manual. Danger ： ； Do not operate the isolation switch with wet hands ... - Page 3 Catalogue 1 Know CDGNE......................... 1 1.1 Packing list......................1 1.2 Product use........................1 1.3 Product model and meaning Product features..............1 2 Storage and transportation..................1 3 Environment and conditions of use................1 4 Main technical parameters..................2 5 Overall dimension.......................3 6 install CDGNE ......................4.1 Position state........................
-
Page 4: Packing List
1.2 Product use CDGNE-50 series isolation switch is suitable for rated voltage DC1500V and below in the power system, the product can be used as infrequent on and off, play the role of isolation line, can be widely used in construction, telecommunications, metallurgy and other industries, and for the current solar photovoltaic system in the DC breaking problem has excellent performance. - Page 5 Ambient temperature: Ambient air temperature in normal operation is -40℃~+85℃ (ambient air temperature exceeds +70℃, it needs to be used for capacity reduction, see the schedule of capacity reduction coefficient) Temperature reduction coefficient Ambient temperature/℃ 0.92 0.84 0.76 Capacity reduction factor ...
-
Page 6: Overall Dimension
Mechanical life (second) Electrical life (s) CCC、CE、CB、TUV Product certification 2.0- Fixed torque of the whole machine（N·m） 1.5- Wiring moment（N·m） 0.6- 0.75 Holding torque of handle（N·m） Connection area Follow Table 9 of GB/T14048.1 Installation mode Panel installation Class of protection The whole machine IP20; External handle: IP66 5、... -
Page 7: Mounting Dimension
3-layer product diagram CDGNE-50 product outline and mounting dimensions 43.9 74.2 2 layer switch body 54.4 84.7 3-layer switch body 64.9 95.2 4-layer switch body 85.9 116.2 6-layer switch body 106.9 137.2 8-layer switch body 6、 installation 6.1、 Status position This product has two position states, that is, the opening position "O/OFF"... -
Page 8: Installation Diagram
Opening position Closing position Cabinet door Cabinet door opening dimensions Cabinet door thickness：1.5-3mm 6.3、 Retaining nut Installation mode: Panel installation 6.4、 Switch body and handle installation diagram controller Retaining nut Switch body Cabinet door... - Page 9 Insert the switch body into the opening hole of the cabinet door, and install the retaining nut and handle in turn. Connection mode Two positive and negative product wiring diagram Two positive and minus 6 layers Two positive and three negative layers Two-layer series product wiring diagram Two layers in series 4 layers Two layers in series 6 layers...
- Page 10 9、 Unpacking inspection After opening the box, the user must check whether the product is intact, whether the exposed metal is rusty, whether the product is defective due to poor transportation and storage, if the above phenomenon, the product can not be used, please contact the supplier in time to solve. 10、...
- Page 11 Adress:Delixi High-Tech Industry Park , Liushi,Yueqing,Zhejiang,P.R.China P/C：325604 T T T T T T t l el:(86-577)61778888 F ex:(86-577)61778000 Hotline：400-826-8008 www.delixi-electric.com This manual is from the first edition of March 2023...
