- Page 1 JLXK1 Series Travel Switch User Manual □ Please carefully read this User Manual before installing and operating the product, and keep this manual properly for future reference...
- Page 2 JLXK1 Series Travel Switch User Manual Safety Notice Please carefully read this instruction before the installation, operation, run, maintenance, and inspection, and follow the contents of the instruction to properly install and operate this product. Danger: ⚫ Do not operate the travel switch with wet hands;...
- Page 3 About JLXK1 Series Travel Switch ●Panel introduction Legends: 1. Hit head structure form 2. Company logo 3. Product model 4. Standard: GB/T 14048.5 5. Resistive current in free air Ith=5A 6. Certification mark 7. Protection grade: IP62 (after installation) 8. Technical parameters AC –...
- Page 4 Normal Operation, Installation and Transport Conditions ●Normal operation and installation conditions (1) The ambient air temperature is not higher than +40℃, and is not below -5℃; the average value within 24 hours does not exceed +35℃; (2) The altitude of the installation site does not exceed 2000m; (3) The relative humidity of the atmosphere does not exceed 50% at the maximum ambient temperature of +40℃, and a higher relative humidity is allowed at lower temperatures, such as 90% at 20℃.
- Page 5 Signage...
- Page 6 Stroke Stroke ●Debugging and operation (1) Check whether the technical parameters on the product nameplate meet the working requirements. (2) Fix and tighten the product with screws. (It is recommended that spring washers and flat gaskets are used). (3) After installation, please carefully check the Hit headfor blockage when being pushed and whether the switch core works within the specified range;...
- Page 7 (4) Wire selection. 1~2 copper wires with a cross-sectional area of 0.5mm² ~1mm² are used. (5) When connecting the lead wire, refer to the wiring diagram above the core. The NC means normally closed contact, and NO means the normally open contact. The diagram is shown in figure. Please carefully distinguish the normally open and normally closed contact terminal sets at the core wiring terminal of the switch to prevent reverse or wrong connection.
- Page 8 Inspector: Check 05 DELIXI ELECTRIC LTD Production date: See label on inner box Manufacturer: Zhejiang Delixi Electrical Co., Ltd. Address: Delixi High-Tech Industrial Park, Liushi Town, Yueqing City, Zhejiang P/C: 325604 Tel: (86-577) 61778888 Fax: (86-577) 61778000 Customer Service Hotline: 400-826-8008 www.delixi-electric.com...
