- Page 1 KG316T Time Switch User Manual □ Please carefully read this User Manual before installing and operating the product. and keep this manual properly for future reference...
- Page 2 1. Overview 1.1 Scope of Application It is suitable for AC 50/60Hz control circuit with the voltage of 380V and below as a delay timing element to turn on or off the power of various control circuits at a predetermined time, suitable for street lights, neon lights, advertising sign lights, radio and television equipment and various household appliances.
- Page 3 3.5 Rated control power supply voltage Us: AC50/60Hz: 220V, 380V; 3.6 Pollution level: 3; 3.7 Enclosure protection grade: IP50; 3.8 Contact capacity: 30A AC220V (resistive) 3.9 The time error a day (24 hours) is not greater than ±2 seconds; 3.10 16 on and 16 off actions can be set every day; 3.11 The switching time can be cycled by days or week;...
- Page 4 Input Output Direct control load wiring diagram Connect AC contactor control load wiring diagram 5 Installation and Operation 5.1 The keyboard will be locked automatically if not operated within 15 seconds, and the mark " " is displayed in the lower left corner. 5.2 Unlock: Press the "Cancel/Restore"...
- Page 5 6. Operation Precautions 6.1 In order to prevent the contact from heating under strong current, please tighten the screws of the wiring terminal when connection. 6.2 It is strictly forbidden to install and disassemble the energized product. 6.3 Please replace the battery regularly to avoid insufficient battery power, resulting in unclear display or no display.
- Page 6 Unpacking and Inspection Open the outer carton and check that there is the Operation Instruction in the packing box. Ordering Notice Please specify the model and specification of the product when ordering. For Any special requirement. please contact the manufacturer. Company Commitment Under the condition that users follow the use and storage conditions and the product are well sealed.
- Page 7 Name: Time Switch Model: KG316T This product passes the inspection and is allowed to be shipped. Certificate Standard: GB/T 14048.4 Inspector: Check 01 DELIXI ELECTRIC LTD Production date: See label on inner box www.cn-delixi.com The second edition of this manual was issued on Aug., 2021.
