04/10/2010
Ins-30004 PROXIMITY KP series keypad
Technical Support
01273 811011
Technical help is available:
Documentation on all Paxton products can be found on our website - http://www.paxton.co.uk/
Fitting
K75 Screw connector option
The unit should be mounted in conjunction with
an electrical backbox to achieve the required
clearance for the connector.
If an adaptor plate (310-750) is fitted, the
mountings on the backbox can also be used.
Cable extensions
Readers can be extended using Belden CR9540 10-core overall screened cable to a maximum of 100 metres.
support@paxton.co.uk
Monday - Friday from 07:00 - 19:00 (GMT)
Saturday from 09:00 - 13:00 (GMT)
Paxton
Advertisement
Related Manuals for Paxton PROXIMITY KP Series
Summary of Contents for Paxton PROXIMITY KP Series
- Page 1 Technical help is available: Monday - Friday from 07:00 - 19:00 (GMT) Saturday from 09:00 - 13:00 (GMT) Documentation on all Paxton products can be found on our website - http://www.paxton.co.uk/ Fitting K75 Screw connector option The unit should be mounted in conjunction with an electrical backbox to achieve the required clearance for the connector.
- Page 2 RJ45 plug and stripping back the wires in the cable. Further information on how to purchase Installer Tools is available at: http://paxton.info/841...
- Page 3 Technical Help Here is the list of topics about this product that receive the most technical support enquiries. We list them here to help you speed up the installation and trouble shooting process. 1 - Readers/Keypads not working. Q- Software settings - Confirm that the settings of the reader or keypad are correct. Q- Connections - Check the wiring and integrity of the connectors.
- Page 4 Additional bezels are available in black, white, grey, blue and silver. Registered installers can order these free of charge by logging onto the secure installer extranet: http://paxton.info/1035. If you are not a registered installer please call us on: 01273 811011 for more information.
