- Page 1 CFC6100MB Double cavity electric cooker with ceramic hob Installation, use and maintenance www.cda.co.uk www.cda.co.uk...
-
Page 2: Table Of Contents
Contents: Important information and pre-first use steps Important safety warnings Important notes for safety, use and care Saving energy Getting to know your cooker Accessories Operation of your oven Setting the time Using the minute minder Changing the beep tone Adjusting the display brightness Operation of the ceramic hob Choice of cookware... - Page 3 Appliance information: Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a fault with your appliance and to register your appliance for guarantee purposes. Appliance Model...
- Page 4 Disposing of a household appliance separately avoids possible negative consequences for the environment and health deriving from inappropriate disposal and enables the constituent materials to be recovered to obtain significant savings in energy and resources. As a reminder of the need to dispose of household appliances separately, the product is marked with a crossed-out wheeled dustbin IMPORTANT: This appliance is designed and manufactured solely for the cooking of domestic (household) food and is not suitable...
-
Page 5: Important Safety Warnings
Important safety warnings Warning: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age should be kept away unless continuously supervised. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if under supervision or instruction concerning use of the appliance in a... -
Page 6: Important Notes For Safety, Use And Care
Warning: Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since they can scratch the surface and may result in shattering of the glass. Warning: Ensure that the appliance is switched off before replacing the lamp to avoid the possibillity of electric shock. - Page 7 • Do not use pans with sharp edges that may damage the hob • Do not allow the hob to get soiled and prevent liquids from boiling over onto the surface of the hob, this refers in particular to sugar which can react with the ceramic hob and cause irreversible damage •...
-
Page 8: Saving Energy
Saving energy Using energy in a responsible way not only saves money but also helps the environment. The following will help you to save energy: • Use proper pans for cooking, pans with thick, flat bases can save up to 1/3 on electric energy. Remember to cover pans if possible otherwise you will use four times as much energy •... -
Page 9: Getting To Know Your Cooker
Getting to know your cooker 3, 4 5, 6 Temperature control knob - main oven Temperature control knob - top oven 3, 4, 5, 6 Heating zone control knobs Red thermostat light - main oven Red thermostat light - top oven Yellow operation light Top oven door Main oven door... -
Page 10: Accessories
Accessories Baking tray Wire shelf Grill rack Wire shelf Wire shelf (airfry) Sideracks *All images are for indication only; please refer to your individual unit for actual item. - Page 11 Operation of the oven Operate the control panel Button to select mode of operation > Plus button Minus button < Appliance on indicator Minute minder Duration Set the current time When the appliance is plugged into the electrical mains supply or when power is restored after a power outage, the digital display will show a flashing 0.00 •...
-
Page 12: Using The Minute Minder
Using the minute minder You can activate the minute minder at any time, regardless of the status of other functions. The minute minder can be set from 1 minute up to 23 hours and 59 minutes. To set the minute minder : •... -
Page 13: Changing The Beep Tone
The timer and timed operation settings may be cancelled at any time, to cancel the Duration, press < / > simultaneously The set duration will be memorised after about 7 seconds. The display will show the current time and the symbol. -
Page 14: Adjusting The Display Brightness
Adjusting the display brightness You can adjust the display brightness from 1 to 9, where 1 is the darkest and 9 is the brightest. The brightness setting applies to an inactive control panel, i.e. when none of controls are used 7 seconds. You can adjust display brightness as follows: •... -
Page 15: Operation Of The Ceramic Hob
Operation of the ceramic hob Choice of cookware Choose a pan with a diameter that is at least as large as the heating zone. Do not use pans with a concave or convex base. Always remember to put a proper cover on the pan. We recommend the use of pans with thick, even bases. -
Page 16: Zone Heating Indicator
Zone heating indicator If the temperature of a heating zone exceeds 50°C this is signalled by an indicator which lights up for that zone. When the heating indicator lights up it warns the person using the cooker against touching a hot heating zone. -
Page 17: Using Your Cooker
Using your cooker Cooking with natural convection (conventional) or automatic air circulation The top oven cavity can be warmed up conventionally using the bottom and top heaters, as well as the grill. The bottom oven cavity can be warmed up with air circulation using the ring heating element and rotating fan. - Page 18 Top cavity Top and bottom heaters on, the oven door is closed The thermostat enables the user to set the temperature within 100°C a range from 100°C to 250°C. Use for baking. This setting - 250°C is ideal for baking cakes, meat, fish, bread and pizza (it is necessary to preheat the oven and use a baking tray) on one oven level.
-
Page 19: Care And Maintenance
Warning! The door of the oven should be open while grilling. Accessible parts may become hot during use, young children should be kept away. Care and maintenance By ensuring proper cleaning and maintenance of your cooker you can have a significant influence on the continuing fault-free operation of your appliance. - Page 20 Caution! The sharp blade should always be protected by adjusting the cover (just push it with your thumb). Injuries are possible so be careful when using this instrument – keep out of reach of children. Important! Do not use any abrasive agents, harsh detergents or abrasive objects for cleaning.
- Page 21 Removing the inner panel 1. Using a flat screwdriver unhook the upper door slat, prying it gently on the sides (fig. B, see p27) 2. Pull the upper door slat loose. (fig. B - C, see p27) 3. Pull the inner glass panel from its eat (in the lower section of the door).
-
Page 22: Care Of Accessories
Care of accessories The oven is equipped with easily removable wire shelf supports. To remove them for washing, pull the front catch, then tilt the support and remove from the rear catch. Removing wire shelf supports Installing wire shelf supports Before you put the baking tray on the telescopic runners, they should be pulled out (if the oven is hot, pull out the telescopic runners by hooking the back edge of the baking tray on the bumpers in the front... - Page 23 The oven is equipped with liners covered with special self–cleaning enamel. The enamel removes fat stains or leftover food automatically, providing they are not dried on and burnt (food and fat remnants should be removed when they are not dried on and burnt to avoid a long self–cleaning process).
-
Page 24: Troubleshooting
Troubleshooting In the event of an emergency, you should: • Switch off all working units of the cooker • Disconnect the mains plug • Call the service centre • Some minor faults can be fixed by referring to the instructions given in the table below. - Page 25 In the event of your appliance requiring technical assistance and/or spare parts, please contact CDA Customer Care. For more information about the warranty of your product, including terms and conditions, please visit www.cda.co.uk/warranty...
-
Page 26: Installation
Installation • The kitchen should be dry and airy and have effective ventilation according to the existing technical provisions. • The room should be equipped with a ventilation system that pipes away exhaust fumes created during combustion. This system should consist of a ventilation grid or hood. Hoods should be installed according to the manufacturer’s instructions. - Page 27 Anti-tilt protection CAUTION! You must install the anti-tilt protection. If you do not install it, the appliance can tilt. The appliance must be secured by using the safety chain (supplied and mounted to cooker rear). Fasten hook to the kitchen wall and connect safety chain to the hook.
-
Page 28: Electrical Connection
Electrical connection Warning: This appliance must be earthed. The appliance must be installed by a competent electrician using a double pole control unit of 32 ampere minimum capacity with 3 mm minimum contact separation at all poles. We recommend that the appliance is connected by a qualified electrician who is member of the N.C.E.I.C. - Page 29 220-240V 1N~ L - Live (Red or Brown) N - Neutral (Black or Blue) PE - Earth (Green/Yellow or sleeving) Grounding lead must be connected to screw with symbol. The power supply cable must have these minimum requirements: • Type: HO5VV-F (PVC insulated and sheathed flexible cable) •...
-
Page 30: Technical Data
Technical data Model 6020DCE2.21TaKDpJSm / CFC6100MB Rated voltage 230V~ Rated frequency 50 Hz Power 10500 W Ceramic hob 6500 W Top oven 2000 W Top heater 500 W Bottom heater 1000 W Grill 2000 W 2000 W Main oven 2000 W... -
Page 31: Product Fiche
Directive of the European Parliament and of the Council 2010/30/EU with regard to energy labelling of household ovens and range hoods. Supplier name Model identifier CFC6100MB Energy efficiency index of top cavity (EEI cavity) 106,8 Energy efficiency index of main cavity (EEI cavity) -
Page 32: Product Information
(EU) No 66/2014 supplementing Directive of the European Parliament and Council Directive 2009/125/EC with regard to eco-design requirements for household ovens, hobs and range hoods Model identifier CFC6100MB Oven type (electricity or gas) - top Electricity Oven type (electricity or gas) - main... - Page 33 (EU) No 66/2014 supplementing Directive of the European Parliament and Council Directive 2009/125/EC with regard to eco-design requirements for household ovens, hobs and range hoods Model identifier CFC6100MB Hob type (electric / gas / gas-electric) Electricity Number of cooking zones...
- Page 34 For more information please contact: The Sales Department on 01949 862 010 or email sales@cda.co.uk Customer Care Department. The CDA Group Ltd, Harby Road, Langar, Nottinghamshire, NG13 9HY 01949 862 012 01949 862 003 customer.care@cda.co.uk www.cda.co.uk...
