Summary of Contents for CDA CFD600MB
- Page 1 CFD600MB Double cavity electric cooker with gas hob Installation, use and maintenance www.cda.co.uk www.cda.co.uk...
-
Page 2: Table Of Contents
Contents: Important information and pre-first use steps Important safety warnings Important notes for safety, use and care Saving energy Getting to know your cooker Accessories Operation of your oven Setting the time Using the minute minder Changing the beep tone Adjusting the display brightness Operation of the hob Choice of cookware... - Page 3 Appliance information: Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a fault with your appliance and to register your appliance for guarantee purposes. Appliance Model...
- Page 4 Disposing of a household appliance separately avoids possible negative consequences for the environment and health deriving from inappropriate disposal and enables the constituent materials to be recovered to obtain significant savings in energy and resources. As a reminder of the need to dispose of household appliances separately, the product is marked with a crossed-out wheeled dustbin IMPORTANT: This appliance is designed and manufactured solely for the cooking of domestic (household) food and is not suitable...
-
Page 5: Important Safety Warnings
Important safety warnings Warning: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age should be kept away unless continuously supervised. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if under supervision or instruction concerning use of the appliance in a... -
Page 6: Important Notes For Safety, Use And Care
Warning: Ensure that the appliance is switched off before replacing the lamp to avoid the possibillity of electric shock. You should not use steam cleaning devices to clean the appliance. Danger of burns! Hot steam may escape when you open the oven door. - Page 7 before checking that all burner knobs are closed. • Do not allow the burners to be soiled or liquids to spill on the burners. If soiled, clean and dry burners immediately after they have cooled down. • Do not put pans directly onto burners. •...
- Page 8 • IN CASE OF ANY SUSPICION OF GAS LEAKAGE YOU MUST NOT: Light matches, smoke cigarettes, switch electrical receivers (door bell or light switch) on and off, or use other electric and mechanical devices that create electrical or percussive sparks. In such a case, immediately close the cylinder valve or tap cutting off gas supply, air the room, and then call a person authorised to repair the source of the leakage.
- Page 9 • The appliance has been designed only for cooking. Any other use (for example for heating) does not comply with its operating profile and may cause danger. Gas and electrical connection Please refer to the installation instructions for the Gas & Electrical Safety Regulations and the Ventilation Requirements.
-
Page 10: Saving Energy
handles. Open the door and grasp the frame of the cooker, taking care that the door does not shut on your fingers. Take care to avoid damage to soft or uneven floor coverings when moving the appliance. Some cushioned vinyl floor coverings may not be designed to withstand sliding appliances without marking or damage. - Page 11 immediately • Do not install the cooker in the direct vicinity of refrigerators/ freezers, otherwise energy consumption increases unnecessarily Be sure to recycle all of the packaging. All packaging materials used are 100% recyclable.
-
Page 12: Getting To Know Your Cooker
Getting to know your cooker 3, 4 Electronic programmer Temperature control knob - main oven Temperature control knob - top oven 3, 4, 5, 6 Gas burner control knobs Red thermostat light - main oven Red thermostat light - top oven Yellow operation light Large burner Medium burner... -
Page 13: Accessories
Accessories Baking tray Wire shelf Grill rack Wire shelf Wire shelf (airfry) Sideracks *All images are for indication only; please refer to your individual unit for actual item. - Page 14 Operation of the oven Operate the control panel Button to select mode of operation > Plus button < Minus button Appliance on indicator Minute minder Duration Set the current time When the appliance is plugged into the electrical mains supply or when power is restored after a power outage, the digital display will show a flashing 0.00 •...
-
Page 15: Using The Minute Minder
Using the minute minder You can activate the minute minder at any time, regardless of the status of other functions. The minute minder can be set from 1 minute up to 23 hours and 59 minutes. To set the minute minder : •... -
Page 16: Changing The Beep Tone
The timer and timed operation settings may be cancelled at any time, to cancel the Duration, press < / > simultaneously The set duration will be memorised after about 7 seconds. The display will show the current time and the symbol. -
Page 17: Adjusting The Display Brightness
Adjusting the display brightness You can adjust the display brightness from 1 to 9, where 1 is the darkest and 9 is the brightest. The brightness setting applies to an inactive control panel, i.e. when none of controls are used 7 seconds. You can adjust display brightness as follows: •... -
Page 18: Operation Of The Hob
Operation of the hob Choice of cookware Mind that the diameter of a pan base is always larger than the burner flame crown and that the pan itself is covered. The recommended pan diameter is around 2.5 to 3 times larger than the burner diameter, that is, for: •... - Page 19 Knob ignition • Press in the knob to the end and turn it left to the “large flame” position • Hold until gas is lit • After the flame is lighted release the pressure on the knob and set a required flame Caution! The cooker is equipped with a surface burner safety valve, hold the knob pressed down to the end when igniting for 10 seconds at the “large flame”...
- Page 20 Selection of the appropriate flame A correctly adjusted burner has a light blue flame with a clearly visible internal cone. Selection of flame size depends on the position of the burner knob which has been set: large flame small flame (“economical flame”) burner switched off (gas supply is cut off) Depending on requirements, flame size can be set in a continuous manner.
-
Page 21: Using Your Cooker
Using your cooker Before first use Before you first use the cooker, you should pre-heat the oven for optimal cooking results. This will help remove any residues of fat and oil accumulated during the manufacturing process and dust accumulated during storage and transport. Pre-heating 1. - Page 22 Cooking with natural convection (conventional) or automatic air circulation The top oven cavity can be warmed up conventionally using the bottom and top heaters, as well as the grill. The bottom oven cavity can be warmed up with air circulation using the ring heating element and rotating fan.
- Page 23 Top cavity Top and bottom heaters on, the oven door is closed The thermostat enables the user to set the temperature within 100°C a range from 100°C to 250°C. Use for baking. This setting - 250°C is ideal for baking cakes, meat, fish, bread and pizza (it is necessary to preheat the oven and use a baking tray) on one oven level.
-
Page 24: Care And Maintenance
Warning! The door of the oven should be open while grilling. Accessible parts may become hot during use, young children should be kept away. Care and maintenance By ensuring proper cleaning and maintenance of your cooker you can have a significant influence on the continuing fault-free operation of your appliance. - Page 25 Important: The burner caps and leads must be repositioned correctly so that they sit squarely onto the hob as shown. correct incorrect incorrect • Wash enamel elements of the cooker with light washing products. • When cleaning do not use cleaning agents with a strong abbrasive effect, such as scouring powders containing an abrasive, abrasive compounds, abrasive stones, pumice stones, wire brushes and so •...
- Page 26 Oven • The oven should be cleaned after every use. When cleaning the oven the lighting should be switched on to enable you to see the surfaces better. • The oven chamber should only be washed with warm water and a small amount of washing-up liquid.
- Page 27 Replacing the halogen bulb in the oven Before replacing the halogen bulb, make sure the appliance is disconnected from the electric mains to avoid a possible electric shock. Oven lighting • Set all control knobs to the position “●”/“0” and ensure the power is disconnected •...
- Page 28 Removing the top oven door In order to obtain easier access to the oven chamber for cleaning, it is possible to remove the door. To do this, tilt the safety catch part of the hinge upwards (fig. A). Close the door lightly, lift and pull it out towards you.
- Page 29 3. Pull the inner glass panel from its seat (in the lower section of the door). Remove the inner panel (fig. D, D1). 4. Clean the panel with warm water with some cleaning agent added. Carry out the same in reverse order to reassemble the inner glass panel.
-
Page 30: Care Of Accessories
Care of accessories The oven is equipped with easily removable wire shelf supports. To remove them for washing, pull the front catch, then tilt the support and remove from the rear catch. Removing wire shelf supports Installing wire shelf supports Before you put the baking tray on the telescopic runners, they should be pulled out (if the oven is hot, pull out the telescopic runners by hooking the back edge of the baking tray on the bumpers in the front... - Page 31 The oven is equipped with liners covered with special self–cleaning enamel. The enamel removes fat stains or leftover food automatically, providing they are not dried on and burnt (food and fat remnants should be removed when they are not dried on and burnt to avoid a long self–cleaning process).
-
Page 32: Troubleshooting
Troubleshooting In the event of an emergency, you should: • Switch off all working units of the cooker • Disconnect the mains plug • Call the service centre • Some minor faults can be fixed by referring to the instructions given in the table below. - Page 33 In the event of your appliance requiring technical assistance and/or spare parts, please contact CDA Customer Care. For more information about the warranty of your product, including terms and conditions, please visit www.cda.co.uk/warranty...
-
Page 34: Installation
Installation Before you start: Please read the instructions. Planning your installation will save you time and effort. Prior to installation, ensure that the local distribution conditions (nature of the gas and gas pressure) and the adjustment of the appliance are compatible. The adjustment conditions are stated on the data badge. - Page 35 accordance with all local gas and electrical regulations. Ventilation Requirements The room containing the appliance should have an air supply in accordance with BS5440: Part 2: 1989: • All rooms require an openable window, or equivalent, and some rooms will require a permanent vent as well. •...
- Page 36 Important: Whilst every care is taken to eliminate burrs and raw edges from this product, please take care when handling - we recommend the use of protective gloves during installation. Please note that the weight of this appliance is approximately 40kg (unpacked).
- Page 37 Levelling Before you start using the cooker it should be leveled, which is particularly important for fat distribution in a frying pan. To this purpose, adjustable feet are accessible after removal of the drawer. The adjustment range is +/- 5mm. Anti-tilt protection CAUTION! You must install the anti-tilt protection.
-
Page 38: Electrical Connection
Mains electrical connection Warning: This appliance must be earthed. We recommend that the appliance is connected by a qualified electrician who is member of the N.C.E.I.C. and who will comply with the I.E.T. and local regulation. This appliance is intended to be connected to fixed wiring by a double pole switch, having a contact separation of at least 3mm in all poles and protected by a 13A fuse. - Page 39 Live L: BN - brown Neutral N: BU - blue Earth PE: GNYE - green/yellow Should the mains cable be damaged or need to be replaced, it should only be done so by a qualified electrician or engineer. The connections to the cooker are shown below.
-
Page 40: Connecting The Gas Supply
Connecting the gas supply The inlet to the cooker is 1/2” BSP internal situated at the rear corner. Fit the bayonet connection. This should be located so as to ensure that the flexible connector hose does not kink. Use a 900-1125mm length of flexible connector. - Page 41 Adapting the cooker to another type of gas. This operation may only be carried out by an appropriately authorised fitter. If the gas the cooker is to be supplied with differs from the gas provided for the cooker by the manufacturer, burner nozzles must be exchanged and the flame needs to be adjusted.
- Page 42 The procedure for changing the gas type Conversion from LPG Conversion from natural Burner Flame to natural gas gas to LPG 1. Replace burner nozzle 1. Replace burner nozzle Full with the appropriate nozzle with the appropriate nozzle flame according to the table. according to the table.
-
Page 43: Technical Data
Technical data Model CFD600MB Appliance category GB II2H3+ Rated voltage 230V~ Rated frequency 50 Hz Power 4000 W Top oven 2000 W Top heater 500 W Bottom heater 1000 W Grill 2000 W Main oven 2000 W Ring element 2000 W... - Page 44 Certificate of compliance CE and UKCA. The Manufacturer hereby declares that this product complies with the general requirements pursuant to the following European Directives and analogus UK requirements : • The Low Voltage Directive 2014/35/EC / Electrical Equipment (Safety) Regulations 2016.) •...
-
Page 45: Product Fiche
Directive of the European Parliament and of the Council 2010/30/EU with regard to energy labelling of household ovens and range hoods Supplier name Model identifier CFD600MB Energy efficiency index of top cavity (EEI cavity) 106,8 Energy efficiency index of main cavity (EEI cavity) -
Page 46: Product Information
(EU) No 66/2014 supplementing Directive of the European Parliament and Council Directive 2009/125/EC with regard to eco-design requirements for household ovens, hobs and range hoods Model identifier CFD600MB Oven type (electricity or gas) - top Electricity Oven type (electricity or gas) - main... - Page 47 (EU) No 66/2014 supplementing Directive of the European Parliament and Council Directive 2009/125/EC with regard to eco-design requirements for household ovens, hobs and range hoods Model identifier CFD600MB Hob type (electric / gas / gas-electric) Number of cooking zones Energy efficiency for each gas burner...
- Page 48 For more information please contact: The Sales Department on 01949 862 010 or email sales@cda.co.uk Customer Care Department. The CDA Group Ltd, Harby Road, Langar, Nottinghamshire, NG13 9HY 01949 862 012 F: 01949 862 003 E: customer.care@cda.co.uk www.cda.co.uk...
