No.
Name
OUT port
7
(1~8)
8
OPTICAL
L/R
9
10
DC 12V
*EDID setting list:
[DIP] = 1111: Copy OUT1 port sink EDID
[DIP] = 1110: FRL12G_8K_HDR, 2.0CH
[DIP] = 1101: FRL12G_8K_HDR, 5.1CH
[DIP] = 1100: FRL12G_8K_HDR, 7.1CH
[DIP] = 1011: FRL10G_8K_HDR, 2.0CH
[DIP] = 1010: FRL10G_8K_HDR, 5.1CH
[DIP] = 1001: FRL10G_8K_HDR, 7.1CH
[DIP] = 1000: 4K120(420)_HDR, 2.0CH
[DIP] = 0111: 4K120(420)_HDR, 5.1CH
[DIP] = 0110: 4K120(420)_HDR, 7.1CH
[DIP] = 0101: 4K60(444)_HDR, 2.0CH
[DIP] = 0100: 4K60(444)_HDR, 5.1CH
[DIP] = 0011: 4K60(444)_HDR, 7.1CH
[DIP] = 0010: 1080P120(444)_HDR, 2.0CH
[DIP] = 0001: 1080P60(444), 2.0CH
[DIP] = 0000: Custom EDID Upload (Default： 1080P60(4:4:4), 2.0CH)
HDMI signal output port, connecting to HDMI display device such
as TV or Monitor with an HDMI cable.
Optical fiber audio output port.
Analog audio output port.
12V/2.5A power input port.
Function Description
4/7
