Truflo — TKM Series
®
In-Line Paddle Wheel Flow Meter Sensor

Technical Specifications

General
Operating Range
Pipe Size Range
Linearity
Repeatability
Accuracy
Flow Velocity
Low Cut
Rangeability
Response Time
Display Range
Units
Fluid
Wetted Materials
Sensor Body
O-Rings
Rotor Pin | Bushings
Paddle | Rotor
Electrical
Frequency
Supply Voltage
Supply Current
Max. Temperature/Pressure Rating - Standard and Integral Sensor | Non-Shock **
PVC
PP
PVDF
Operating Temperature
PVC
PP
PVDF
Outputs
TKM Series
Standards and Approvals
CE | FCC | RoHS Compliant
*Optional
**See Temperature and Pressure Graphs for more information
24-0317 © Icon Process Controls Ltd.
0.3 to 33 ft/s
½ to 4"
±0.5% of F.S @ 25°C | 77°F
±0.5% of F.S @ 25°C | 77°F
± 0.5% of F.S. @ 25°C
32.8 ft/s max | 10 m/s max
0.3 ft/s min | 0.1 m/s min
100 : 1
Real Time
0~999999
Gallon (G) or Liter (L) or Kiloliter (KL)
Water or Chemical Liquid-Viscosity Range: 0.5-20 centistokes
PVC (Dark) | PP (Pigmented) | PVDF (Natural) | 316SS
FKM | EPDM* | FFKM*
Zirconium Ceramic | ZrO2
ETFE Tefzel®
49 Hz per m/s Nominal
5 ~ 24 VDC ± 10% Regulated
<1.5mA @ 3.3 to 6 VDC
180 psi @ 68°F | 40 Psi @ 140°F
180 psi @ 68°F | 40 psi @ 190°F
200 psi @ 68°F | 40 psi @ 240°F
32°F to 140°F
-4°F to 190°F
-40°F to 240°F
4-20mA | NPN Pulse | 0-5V*
0.1 to 10 m/s
DN15 to DN100
12.5 bar @ 20°C | 2.7 bar @ 60°C
12.5 bar @ 20°C | 2.7 bar @ 88°C
14 bar @ 20°C | 2.7 bar @ 115°C
0°C to 60°C
-20°C to 88°C
-40°C to 115°C
4
