Truflo — TKM Series
®
In-Line Paddle Wheel Flow Meter Sensor

Exploded View

1
2
4
2"

Wiring Diagram

TKM
Flow
Meter
Output
Circuit
24-0317 © Icon Process Controls Ltd.
3
Brown
Totalizer
Black
Pulse (NPN)
Load
Flow Rate
White
Pulse (NPN)
Load
+ +
Yellow
or
A
V
4-20
Grey
Blue
5
1
2
3
4
5
6
7
8
Same Controller | Rotor Assembly for all sizes
1/2"
Wire Color
Brown
+VDC
Brown + 10~30 VDC
Black
White
Blue - VDC
Yellow
5V DC
Flow Rate
White
Grey
Pulse Output
-VDC
Blue
7
6
8
PC Cover
TKM Controller
Rotor Assembly
Body - PVC | PP | PVDF
Rotor Pin
Rotor Bushing
ShearPro Paddle Wheel
®
Reinforced Inserts
Descritpiton
+ 10~30VDC
+ (4-20mA) or (0-5V)
Yellow
Totalizer Pulse Output (OP2)
Flow Rate Pulse Output (OP1)
- (4-20mA) or (0-5V)
Grey
+ 4-20mA | 0-5V*
Totalizer Pulse Output
Black - 4-20mA | 0-5V*
-VDC
* Optional
