Accessories

The following accessories are available to connect the CAN/LIN Accessory to the target CAN, CAN-
FD or LIN interface(s).
Description
1m CAN cable DB9
CAN cable banana jacks
CAN cable pin wires
CAN BUS T adapter
LIN cable banana jacks
LIN cable pin wires
1 m FNet Cable (for use with AOM accessories) BB-FNET-100
3 m FNet Cable (for use with AOM accessories) BB-FNET-300
5 m FNet Cable (for use with AOM accessories) BB-FNET-500
The topology of a CAN network is shown in the CAN BUS T adapter section. The ends of the
network require termination using a 120 Ohm impedance, connected between the CAN_H and
CAN_L signals.
TASKING accessories provide the termination impedance via a switch on the DB9 connector. In the
default switch position the termination impedance is not connected.
If the CAN/LIN is connected at one of the ends of the network (node A or D in the diagram above)
the 120 Ohm termination impedance can be enabled using the switch on the TASKING connector
accessories. If connected to the CAN bus at the position of nodes B and C, no termination is
required.
More information about our products via sales@tasking.com.
Ordering Code
IC57040-CAN-DB9
IC57040-CAN-JACK
IC57040-CAN-PIN
IC57040-CAN-T
IC57040-LIN-JACK
IC57040-LIN-PIN
