Page 1
CAN/LIN HARDWARE USER MANUAL V2.7, July 2024 www.tasking.com...
Page 2
Use included power cord and power supply The enclosed power supply has been approved for use by TASKING. Please contact TASKING if you need to consider an alternative power.
Package content The standard CAN/LIN order is delivered with the following components: CAN/LIN 1m FNet Cable Grounding wire Ordering code: Ordering code: Ordering code: IC57040 BB-FNET-100 BB-WIRE www.tasking.com...
5% to 80% RH MECHANICAL Size 100 x 125 x 55 mm Weight ca. 440 g (without cables) ELECTRICAL Supply voltage Powered through the FNet CAN Channels 2 x Microchip MCP2562FD (galvanic isolation) DAP_RESET 2 x NXP TJA1027 (galvanic isolation) www.tasking.com...
BlueBox User Manuals for more details on this grounding. C – LIN1 and LIN2 connector The two connectors allow up to two target LIN bus networks to be monitored. Signal LIN_GND SHIELD LIN_VBAT* SHIELD * The target must always provide power to the LIN VBAT connection. www.tasking.com...
Page 7
Although it looks similar to the HDMI interface, the FNet Port is not compatible with HDMI or any HDMI accessories. Connecting TASKING hardware to the HDMI devices will damage the hardware and will render the TASKING hardware warranty void. www.tasking.com...
Getting started Tutorial - use the link isystem.com/start. 1. Make sure that the iC7max / iC5700 BlueBox is powered off. 2. Connect the FNet port of the iC7max / iC5700 to the FNet port of the CAN/LIN using the supplied FNet cable.
CAN message injection CAN message injection is physically disabled by default. To enable injection remove the cover on your powered-down CAN/LIN device and place jumpers* on J1 for CAN1 and J5 for CAN2. * Jumpers: Revision B1 - Soldered jumpers Revision B2 - Through hole jumpers For a more detailed guide on this subject refer to CAN message injection in winIDEA Help.
Ordering code IC57040-CAN-DB9 The IC57040-CAN-DB9 is used to connect the CAN/LIN to an existing CAN network through the DB9 connector. 120 Ohm termination is selected with the switch located on one of the DB9 connectors. The cable length is 1m.
Page 11
Ordering code IC57040-CAN-PIN The IC57040-CAN-PIN is used to connect the CAN/LIN Accessory to an existing CAN network to the pins typically found on a 2.54mm pitch header (0.63mm square pins). The 120 Ohm termination impedance is selected using the switch located on the cable DB9 connector. Cable length is 0.65m.
Page 12
Ordering code IC57040-CAN-T The IC57040-CAN-T is used to connect the CAN/LIN Accessory to a CAN bus by splitting the existing bus connection – position F on the diagram below. The existing CAN bus connection is split using the IC57040-CAN-T allowing the CAN/LIN Accessory to connect to it using an IC57040- CAN-DB9 cable (no termination required).
Page 13
Ordering code IC57040-LIN-PIN The IC57040-LIN-PIN cable is used to connect the CAN/LIN to an existing LIN network to the pins typically found on a 2.54mm pitch header (0.63mm square pins). The cable length is 0.65m. The cable connects to the LIN1 or LIN2.
If the CAN/LIN is connected at one of the ends of the network (node A or D in the diagram above) the 120 Ohm termination impedance can be enabled using the switch on the TASKING connector accessories.
