- Page 1 Electric Bicycle Operating Instructions Under the law, the dealer is obliged to attach the LEADER FOX Electric Bicycle Operating Instructions to every product E – BIKE POWER RIDE Swan...
- Page 2 Introduction Dear users, Please read carefully all the information regarding your E-LF product to ensure optimal functioning of your e-bike. The following text containing a comprehensive description will provide you with information on all aspects and details (including installation, setting up and general use of the display) regarding the use of our display.
- Page 3 Factors influencing the electric bicycle range 1. Rolling resistance of the tyres. Leader Fox e-bikes are fittet with tyres with low rolling resistance and increased resistance to puncture. It is also important that the tyres are inflated properly. Therefor, if the tyres of your electric bicycle are underinflated, the range will decrease.
- Page 4 Electric set Modest The system uses monitoring of torque, monitoring of speed of the pedal assist system and monitoring of real speed of wheels. The system uses a dual protection feedback for measuring the speed signal to ensure safety and reliabilityof the system.
- Page 5 Dimensions of the power unit:...
- Page 6 Safety instruction Battery: Do not throw the battery into fire. Do not throw the battery into water. Do not use the battery for other appliances. It has been made specifically for this model. Do not dismantle or modify the battery. Do not connect the positive and negative poles of the battery.
- Page 7 Battery Battery charging and maintenance: Charge the battery in a dry enviroment to avoid short-circuit damage. Charge the battery to at least 60% of the capacity once every 3 months even when the bicycle is not used. Do not cover the battery or the charger. Do not leave the battery constantly connected to the power source.
- Page 8 If the charge indicator shows that the battery is discharged, there is still a minimum voltage level in it which protects it against damage but is not enough to power the electric bicycle. Recharge the battery as soon as possible. Never leave the battery fully discharged, it could results in its damage. In the case, that the battery will be turned on more than 30 min and bike will not be used, the battery will be automatically switched off.
-
Page 9: Table Of Contents
7 DEALER MANUAL FOR DP C221.CAN CONTENT 7.1 Important Notice 7.7.2 Selection of Support Levels 7.2 Introduction of Display 7.7.3 Selection mode 7.3 Product Description 7.7.4 Headlights / backlighting 7.7.5 Walk Assistance 7.3.1 Specifications 7.7.6 SERVICE 7.3.2 Functions Overview 7.4 Display Installation 7.7.7 Battery capacity indication 7.5 Display 7.8 Settings... -
Page 10: Important Notice
7.1 IMPORTANT NOTICE • If the error information from the display • Please use this product with care. cannot be corrected according to the inst- • Do not use thinners or other solvents to ructions, please contact your retailer. clean the display. Such substances can •... -
Page 11: Product Description
7.3 PRODUCT DESCRIPTION 7.3.2 Functional Overview 7.3.1 Specifications • Speed display (including top speed and aver- • Operating temperature: -20℃~45℃ age speed, switching between km and miles) • Storage temperature: -20℃~50℃ • Battery capacity indicator • Waterproof: IPX5 • Lighting control •... -
Page 12: Display Installation
7.4 DISPLAY INSTALLATION Remove the holding bracket from the Now connect the Display connector to the display, and then place the display into EB-Bus connector, ensuring both connec- position on the handlebar. (suitable for tors are kept parallel when pushing firmly ∮22.2mm handlebar). -
Page 13: Display
7.5 DISPLAY Display of battery capacity in real time. Indicator of support level/walk assistance. The display shows this symbol , When the lights are turned on. Indicatior of bluetooth Unit of speed Digital speed display Trip: Daily kilometers (TRIP) - Total kilometers (ODO) - Top speed (MAX) - Average speed (AVG) - Rremaining distance (RANGE) - Ener- gy Consumption (CALORIES) - Output power... -
Page 14: Normal Operation
7.7 NORMAL OPERATION 7.7.1 Switching the System ON/OFF Press and hold (>2S) on the display to turn on the system. Press and hold (>2S) again to turn off the system. If the "automatic shutdown time" is set to 5 minutes (it can be reset with the "Auto Off" function, See "Auto Off"), the display will automatically be turned off within the desired time when it is not in operation.If the password function is enabled, you must enter the correct password to use the system. -
Page 15: Headlights / Backlighting
7.7.4 Headlights / backlighting Hold the button (>2S) to activate the headlight and taillights. Hold the button (>2S) again to turn off the headlight. The brightness of the backlight can be set in the display settings "Brightness". 7.7.5 Walk Assistance The Walk assistance can only be activated with a standing pedelec. -
Page 16: Service
7.7.6 SERVICE The display shows "SERVICE" as soon as a certain number of kilometers or battery charges has been reached. With a mileage of more than 5000 km (or 100 charge cycles), the “SERVICE" function is displayed on the display. Every 5000 km the display "SERVICE" is displayed every time. This function can be set in the display settings. -
Page 17: Settings
7.8 SETTINGS After the display is turned on, press and hold the buttons (at the same time) to enter into the setting menu, By pressing the button (<0.5S), you can highlight and select Display Setting, Information or Exit. Then press the button (<0.5S) to confirm your selected option. - Page 18 7.8.1.2 "Unit" Selections in km/Miles Press the button (<0.5S) to highlight “Unit” in the Display setting menu, and then press button (<0.5S) to select. Then with the button choose between “Metric” (kilometer) or “Imperial” (Miles). Once you have chosen your desired selection, press the button (<0.5S) to save and exit to the "Display setting".
-
Page 19: Information
7.8.1.5 "Service" Switching the notification on and off Press the button (<0.5S) to highlight “Service” in the Display setting menu, and then press button (<0.5S) to select. Then with the button choose between “NO” or “YES”. Once you have chosen your desired selection, press the button (<0.5S) to save and exit to the "Display setting". - Page 20 7.8.2.2 Speed Limit Press the button (<0.5S) to highlight “Speed Limit”, then press the button (<0.5S) to confirm and view the speed limit. To return, press the button (<0.5S) to exit back to the "Infor- mation". This information cannot be changed, this is only for information, about the pedelec. 7.8.2.3 Battery Information Press the button (<0.5S) to highlight “Battery Info”, then press the...
- Page 21 Code Code definition unit Code Code definition unit Hardware ver Hardware version Absolute SOC Software ver Software version Cycle times Maximum not Current temperature Hour ℃ charging time Recently not char- Total voltage Hour ging time Number of battery Average current cell Remaining capacity Voltage of cell 1...
- Page 22 7.8.2.5 Display Information Press the button (<0.5S) to highlight “Display Info”, then press the button (<0.5S) to confirm. Now press the button (<0.5S) to view Hardware Version or Software Version. To return, press the button (<0.5S) to exit back to the "Information". 7.8.2.6 Torque Information Press the button (<0.5S) to highlight “Torque Info”, then press the...
-
Page 23: Error Code Definition
7.9 ERROR CODE DEFINITION The HMI can show the faults of Pedelec. When a fault is detected, one of the following error codes will be indicated too. Note: Please read carefully the description of the error code. When the error code appears, please first restart the system. - Page 24 Error Declaration Troubleshooting 1. Check all connectors from the battery are correctly connected to the motor. Error with the temperature sensor inside of the battery 2. If the problem still occurs, please change the Battery. 1. Allow the pedelec to cool down and restart the The protection temperature system.
- Page 25 Error Declaration Troubleshooting 1. Check that all connections are connected correctly. 2. Please connect the pedelec to the BESST system to see if speed signal can be read by the BESST tool. Speed signal of the torque 3. Change the Display to see if the problem is solved. sensor has an error 4.
- Page 26 Error Declaration Troubleshooting Using the BESST tool update the controller to see if WDT circuit is faulty this resolves the problem. If not, please change the controller or contact your supplier. Total voltage from the battery is Please change the battery. too high Total voltage from the battery is Please Charge the battery.
- Page 27 Maintenance Regular maintenance: - maintain all components of the electric bicycle clean - use only the recommended and tested cleaning materials - regularly lubricate the chain with suitable oils - in winter, clean the electric bicycle after each ride and pay increased attention to removing salt from battery contacts and other connectors - while handling the electric bicycle, make sure the cables of the electric system are not damaged.
- Page 28 Electric set warranty Complaint procedure: Submit any complaints concerning the electric set or the battery to your dealer. When filing a complaint, submit a proof of purchase and a warranty certificate with the registered serial number of the battery and indicate the reason for the complaint and a description of the defect. Wrranty conditions: 24 months for electric bicycle components –...
- Page 29 Warning If you do not understand any of the points in these Operating Instructions, please contact the dealer for explanation. Please read the whole manual! Do not lend the e-bike to persons not briefed in its use and operation. Complaints resulting from improper handling will not be accepted.
- Page 30 Enjoy many pleasant and safe kilometres on your new electric bicycle. Your Leader Fox Team Czech brand of electric bicycles. BOHEMIA BIKE Address Na Pankráci 1724 14000 Praha 4 - Pankrác Development, design and manufacturing Okružní 697 České Budějovice 37001 Phone: 388 314 885 Email: info@leaderfox.cz...
