- Page 1 Electric Bicycle Operating Instructions Under the law, the dealer is obliged to attach the LEADER FOX Electric Bicycle Operating Instructions to every product E – BIKE POWER RIDE Curtis...
- Page 2 Introduction Dear users, Please read carefully all the information regarding your E-LF product to ensure optimal functioning of your e-bike. The following text containing a comprehensive description will provide you with information on all aspects and details (including installation, setting up and general use of the display) regarding the use of our display.
- Page 3 Factors influencing the electric bicycle range 1. Rolling resistance of the tyres. Leader Fox e-bikes are fittet with tyres with low rolling resistance and increased resistance to puncture. It is also important that the tyres are inflated properly. Therefor, if the tyres of your electric bicycle are underinflated, the range will decrease.
- Page 4 Battery Riding safety: While riding, pay only as much attention to the bicycle settings and display as not to jeopardize your safety. Before riding, check that wheels have been securely fitted in the frame and fork, since their incorrect installation can cause serious injury. When riding the electric bicycle, you should be fully familiar with its behaviour and control, otherwise it could result in serious injury.
- Page 5 Description Battery charging and maintenance: Charge the battery in a dry enviroment to avoid short-circuit damage. Charge the battery to at least 60% of the capacity once every 3 months even when the bicycle is not used. Do not cover the battery or the charger. Do not leave the battery constantly connected to the power source.
- Page 6 If you feel your total battery capacity has dropped, it could be caused by charging or operation in suboptimal climatic conditions. Carry out 3 full charging cycles. Fully discharge the battery while riding and then charge to its full capacity at room temperature. If the charge indicator shows that the battery is discharged, there is still a minimum voltage level in it which protects it against damage but is not enough to power the electric bicycle.
- Page 7 KBY-DíSP The eBike Display Users Manual KD686...
-
Page 8: Product Name And Model
Product Name and Model Intelligent ebike color display; Model: KD686 ( UART ) Specification ●2.0" IPS color screen ●36V/48V/52V power supply power supply ●Meter rated operating current: 22mA ●Shutdown leakage current: <1uA Operating temperature: -10～ 60℃ ●Storage temperature: -20 to 70℃ Exterior Dimensions Physical drawing and dimensional drawing of the display (unit: mm) The KD686 model gauges offer a variety of features to meet your riding needs,... -
Page 9: Display Area
speed SPEED, maximum speed MAX, average speed AVG, riding time Time ●Motor output power display ●Assisted gear adjustment and display ●Backlight control and headlight display ●walk assistance ●Error code display. ●Type-C charging function ●Light-sensitive function ●Multiple parameter settings (e.g. single mileage clearing, backlighting, metric/imperial system, power setting, gear setting, wheel diameter speed limit setting, power-on password setting, etc.) ●Restore factory default settings... -
Page 10: General Operation
General operation ◆ Power on/off After long pressing the power button, the meter starts to work and provides the working power for the controller. In the power-on state, long press the power button to turn off the power of the EV. In the off state, the meter no longer uses the power from the battery and the leakage current of the meter is less than 1uA. - Page 11 Walk mode ◆ Light-sensitive function and manual on/off backlighting The display has a light-sensitive function, which can sense the light and darkness of external light and turn on/off the headlights automatically. When the external light is not enough or when driving at night, the backlight of the display will be dimmed, and at the same time notify the controller to turn on the headlights;...
- Page 12 Assist level Interface ◆Battery SOC Display battery voltage 36V; 36V voltage segments: 31.5V-34.5V-35.6V-37.4V-39.2V Battery SOC interface ◆Motor power indication The meter displays a progress bar of motor output power. The display is shown below. Motor power display interface Error Code Display ◆...
-
Page 13: General Parameter Settings
Error Code Display Screen When an error code is displayed, please troubleshoot the problem in time, the ■ electric car will not be able to run normally after a malfunction. General Parameter Settings In the power-on state, the vehicle is stationary, press and hold the "UP" and "DOWN"... - Page 14 Single Mileage Zero Setting ◆ units Short press "UP" or "DOWN" to select "Unit", short press "ON/OFF" to enter the Setting, press "UP" or "DOWN" to select "Metric" (kilometer)/"Imperial (mile)", press "ON/OFF" to enter the setting. Select "Metric"/"Imperial" by pressing "UP" or "DOWN", press "ON/OFF"...
- Page 15 ◆Battery percentage and voltage display Short press "UP" or "DOWN" to select "SOC View", short press "ON/OFF" to enter the setting. "Enter the setting, short press "UP" or "DOWN" to switch to: "Voltage (Voltage Display)"; the default meter is "Percent", press "ON/OFF" to save and exit to "SOC View".
- Page 16 and cannot be changed. Press and hold "ON/OFF" to return to the main screen or "BACK" to return to the main screen. Battery voltage setting interface ◆ Power-on password setting Short press "UP" or "DOWN" to select "Password", short press "ON/OFF" to enter setting.
- Page 17 Password Enable Confirmation Screen Power-on password change ◆ After opening the password, "Pass word" interface will add "Reset your code" option, short press "UP" or "DOWN" to select "Reset Password", short press "ON/OFF" again to make sure. Short press "UP" or "DOWN" to select "Reset Password", short press "ON/OFF"...
- Page 18 password is correctly input, the interface prompts you that the password function is successfully turned off. After the password is correctly entered, the interface prompts that the password function is closed successfully, and the interface automatically jumps to the original setting interface after 2S. Long press "ON/OFF"...
-
Page 19: Current Limit
the main screen. Wheel diameter setting interface ◆Speed Limit Short press "UP" or "DOWN" to select "Speed Limit" to see the speed limit value, default 25km/h, not adjustable. Press and hold "ON/OFF" to return to the main interface or "BACK" to return to the main interface. Speed limit interface ◆current limit Short press "UP"... - Page 20 Speed Sensor ◆Assistant Num Short press "UP" or "DOWN" to select "Assistant Num" to check the number of assistant magnets, the default value is "12", not adjustable. The default value is "12", not adjustable. Press and hold "ON/OFF" to return to the main interface or "BACK" to return to the main interface.
-
Page 21: Connector Pinout
"Czech", "French", "German", "English". Short press "UP" or "DOWN" to select "Czech", "French", "German", "English", short press "ON/OFF" to confirm, the default is English, long press "ON/OFF" to confirm, long press "ON/OFF" to confirm, the default is English. "Long press "ON/OFF" to exit to the main interface or "BACK" to exit to the setting interface. - Page 22 serial names functionality number display Power Cord Power control cable for controller Data receiving line of the display Data transmission line of the display Exhibit 1: Error Code Definition Table error code define current fault Throttle fault Motor phase is absent Motor Hall signal abnormality Brake abnormality Communication fault between...
- Page 23 Warnings Pay attention to the safety of use in the process, do not plug and unplug the meter under power. ◆Avoid bumping the meter as much as possible. ◆Regarding the background parameter settings of the meter, please do not change them arbitrarily, otherwise normal riding cannot be guaranteed. ◆When the meter is not working properly it should be sent for repair as soon as possible.
-
Page 24: Maintenance
Maintenance Regular maintenance: - maintain all components of the electric bicycle clean - use only the recommended and tested cleaning materials - regularly lubricate the chain with suitable oils - in winter, clean the electric bicycle after each ride and pay increased attention to removing salt from battery contacts and other connectors - while handling the electric bicycle, make sure the cables of the electric system are not damaged. -
Page 25: Possible Problems And Their Solutions
Possible problems and their solutions In case of system failure perform its diagnostics or contact your dealer. The control LCD display is not on: - always make sure the battery is charged - check whether the battery is inserted correctly, whether the battery switch is on - check the connections of the control unit and the display The motor does not start when the walk assistance button is pressed - check the connection of the motor cable (at the motor and the control unit) - Page 26 Warning Complaint procedure: Submit any complaints concerning the electric set or the battery to your dealer. When filing a complaint, submit a proof of purchase and a warranty certificate with the registered serial number of the battery and indicate the reason for the complaint and a description of the defect. Warranty conditions: 24 months for electric bicycle components –...
- Page 27 If you do not understand any of the points in these Operating Instructions, please contact the dealer for explanation. Please read the whole manual! Do not lend the e-bike to persons not briefed in its use and operation. Complaints resulting from improper handling will not be accepted.
- Page 28 Enjoy many pleasant and safe kilometres on your new electric bicycle. Your Leader Fox Team Czech brand of electric bicycles. BOHEMIA BIKE Address Pujmanové 1753/10a 140 00, Praha 4 - Nusle Development, design and manufacturing Okružní 697 České Budějovice 37001 Phone: 388 314 885 Email: info@leaderfox.cz...
